Elements DS600KH Assembly Instructions

Caution : Please read instructions thoroughly before unpackig assembly parts. Sharp, exposed staple tips can cause
injury, therefore, for your protection, please remove any exposed staples used in packing.
1. We recommend that you should assemble this product with the product with the assistance of another person; this
will make assembly easier, and will help to eliminate damage to the product or injury to persons during assembly.
2. Be sure to check all packing materials carefully for small parts that may have come loose inside the carton during
shipment.
3. Please do not over tighten screw or bolts.
4. Please put all parts on non-abrasive floor before assembly, and follow the assembly steps to assemble your newly
purchased product correctly and efficiently.
PART LIST
NO. PART DESCRIPTION
A KING / QUEEN RAIL
B KING HEADBOARD PANEL
C KING HEADBOARD LEFT LEG
D KING HEADBOARD RIGHT LEG
E KING FOOTBOARD
F KING SLATS
G KING SLAT SUPPORT LEG WITH LEVELER
Hardware List (Packed Inside Headboard)
Description
NO.
JCBC Screw 1/4" x 40mm
1
2 Spring Washer 1/4"
3 Flat Washer 1/4" x 19mm
4 Allen Key

ASSEMBLY STEP HEADBOARD

D
Date: 2018-05-10
Assembly instructions for
KING HEADBOARD
KING FOOTBOARD/ SLATS
QUEEN/ KING RAILS
DS600KH/ DS600KF/ DS600QKR
CODE QTY.
2 PCS
1 PC
1 PC
PDS600HBLGL
1 PC
PDS600HBLGR
1 PC
4 PCS
PDS600KBSLT
8 PCS
PDS600KBSPL
CODE Qty.
6 Pcs
6 Pcs
PDS600BHW
6 Pcs
1 Pc
B
1
2
3
4
MADE IN VIET NAM
Hardware List (Packed Inside Footboard)
Description
NO.
Screw M4 x 32mm
5
Hardware List (Packed Inside Rail)
Description
NO.
6
Hanger bolt 5/16" x 3 1/2"
7 Hexagon nut 5/16"
8
Spring Washer 5/16"
Flat Washer 5/16" x 14mm
9
10 Wrench 5/16"
4
3
2
1
STEP:1.1
CODE
8 Pcs
PDS600BHW
CODE
8 Pcs
8 Pcs
PDS600BHW
8 Pcs
8 Pcs
1 Pc
C
Page 01 of 02
Qty.
Qty.
