Elements DL600TV Assembly Instructions

Cautions: Please read instructions thoroughly before unpacking assembly parts. Sharp, exposed staple tips can cause injury,
therefore, for your protection, please remove any exposed staples used in parking.
1. We recommend that you should assemble this product with the assistance of another person; this will make assembly easier,
and will help to eliminate damage to the product or injury to persons during assembly.
2. Be sure to check all packing materials carefully for small parts that may have come loose inside the carton druring shipment.
3. Please do not over tighten screws or bolts.
4. Please put all parts on a non-abrasive floor before assembly, and follow the assembly steps to assemble your newly
purchased product correctly and efficiently.
PART LIST
No.
Part Description
A TV CHEST
CASEGOOD'S FRONT LEG
B
CASEGOOD'S BACK LEFT LEG
C
CASEGOOD'S BACK RIGHT LEG
D
Remark : Please be noted that the
safety bracket set with instruction
is attached at the right first drawer.
Tipping Restraint
5
ASSEMBLY INSTRUCTIONS FOR
DESCRIPTION : MEDIA CHEST
ITEM NO : DL600TV
Q'ty
Code.
1
CFLEG
2
1
CBLGL
1
CBLGR
A
B
The legs inside the bottom drawer
HARDWARE LIST
No.
Hardware Description
Flat washer (Ø1/4" x 5/8")
1
Spring washer (Ø1/4" x 3/8")
2
3
Bolt (Ø1/4"x 2 1/2")
4 Allen key (4 x 59mm)
Tipping Restraint
5
1
2
3
4
Q'ty
Code.
LGHW
ATKT
B
D
8
8
8
1
1
C
