Elements DGC500DTT Assembly Instructions

Caution: Please read instructions thoroughly before unpacking assembly parts. Sharp, exposed staple tips can
cause injury, therefore, for your protection, please remove any exposed staples used in packing.
1. We recommend that you should assemble this product with the assistance of another person; this will make
assembly easier, and will help to eliminate damage to the product or injury to persons during assembly.
2. Be sure to check all packing materials carefully for small parts that may have come loose inside the carton
during shipment.
3. Please do not over tighten screws or bolts.
4. Please put all parts on a non-abrasive floor before assembly, and follow the assembly steps to assemble your
newly purchased product correctly and efficiently.

PART LIST FOR TABLE

No. PART DESC.
A
Dining Table Top
B Dining Table Top - Leaf support Rail
C Dining Table Top - Top Mending plate
D
Dining Table Base - Post
E Dining Table Base - Foot
F
Dining Table Base - Bottom Stretcher

STEP:1

D

STEP:3

DATE: 28-Aug-2019
Assembly Instructions for
DINING TABLE
DGC500DTT & DGC500DTB
Q'TY
CODE.
1
PDGC500DTTLEA 2
PDGC500DTTCON 2
2
PDGC500DTBPOS
PDGC500DTBLEG 2
PDGC500DTBSTR 1

HARDWARE LIST PACKED INSIDE BOX

No.
HARDWARE DESC
Allen Bolt (5/16" x 50mm)
1
Allen Bolt (5/16" x 110mm)
2
Spring washer (5/16")
3
4 Flat washer (5/16")
Bolt (5/16" x 76mm)
5
Half-moon washer
6
Hex nut (5/16")
7
Wrench (5/16")
8
Allen key M4
9

STEP:2

A

STEP:4

Q'TY
CODE.
28
8
36
36
PDGC500DTTHW
4
4
4
1
1
Page: 1/2
