Elements B-3690-3-KH Assembly Instruction

Caution: Please read instructions thoroughly before unpacking assembly parts. Sharp, exposed staple tips can cause injury,
therefore, for your protection, please remove any exposed staples used in packing.
1. We recommend that you should assemble this product with the assistance of another person; this will make
assembly easier, and will help to eliminate damage to the product or injury to persons during assembly.
2. Be sure to check all packing materials carefully for small parts that may have come loose inside the carton during
shipment.
3. Please do not over tighten screws or bolts.
4. Please put all parts on a non-abrasive floor before assembly, and follow the assembly steps to assemble your newly
purchased product correctly and efficiently.
PART LIST FOR HEADBOARD
No. Part Description
A
Headboard
Left & Right
B
Headboard Leg
Headboard
C
Bottom Stretcher
! Only tighten all bolts when all bolts aligned with bolt inserts.
STEP 1 STEP 1
ASSEMBLY INSTRUCTION FOR
B-3690-3-KH/B-3690-3-KF1/B-3690-3-QKR
B-3690-8-KH/B-3690-8-KF1/B-3690-8-QKR
Code. Q'ty
1
PB-3690-3-HBLEG
2
PB-3690-8-HBLEG
PB-3690-3-KHSTR
1
PB-3690-8-KHSTR
A A
1 1
3 3
2 2
4 4
MADE IN VIETNAM
KING BED
HARDWARE LIST FOR HEADBOARD
Hardware Description
No.
1 Flat washer 5/16"
2
Spring washer 5/16"
3
Allen Bolt 5/16"*2"
4 Allen key 5/32"
Headboard Hardware Packed with Headboard
B B
Right Right
4 4
Code.
PB-3690-
KBHW
B B
C C
Left Left
1 1
3 3
2 2
STEP 2 STEP 2
Q'ty
8
8
8
1
PAGE 1 OF 2
