Elements DDV100DTT Assembly Instruction

Caution: Please read instructions thoroughly before unpacking assembly parts. Sharp, exposed staple tips can
cause injury, therefore, for your protection, please remove any exposed staples used in packing.
1. We recommend that you should assemble this product with the assistance of another person; this will make
assembly easier, and will help to eliminate damage to the product or injury to persons during assembly.
2. Be sure to check all packing materials carefully for small parts that may have come loose inside the carton
during shipment.
3. Please do not over tighten screws or bolts.
4. Please put all parts on a non-abrasive floor before assembly, and follow the assembly steps to assemble your
newly purchased product correctly and efficiently.
PART LIST FOR DINING TABLE
PART DESC
No.
A
Dining Table Top Dark - Top
B
Dining Table Top Dark - Leaf
C
Dining Table Top Dark - Base
D
Dining Table Top Dark - Top Connecting Panel
E Dining Table Top Dark - Leaf Support Rail
Only tighten all bolts when all bolts aligned with bolt inserts.
STEP:1
4
1
2
3
STEP:3
Assembly Instruction for
DINING TABLE
DDV100DTT / DDV100DTB
Q'TY
CODE.
1
1
PDDV100DTTTOP 2
PDDV100DTTLEA
2
A
E
MADE IN VIETNAM
HARDWARE LIST
No. HARDWARE DESC
ALLEN BOLT (Ø5/16"*1-3/4")
1
SPRING WASHER (Ø5/16")
2
FLAT WASHER (Ø5/16")
3
ALLEN KEY (Ø1/8")
4
STEP:2
D
4
1
2
3
Q'TY
CODE.
PDDV100DTTHW
4
1
2
3
C
PAGE 1 OF 2
