P2012
AIRCRAFT MAINTENANCE MANUAL
PUBLISHED BY
COSTRUZIONI AERONAUTICHE TECNAM S.p.A.
VIA MAIORISE - 81043 CAPUA (CE)
ITALY
th
5
Edition - Rev. 0
2022, Jan 14

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P2012 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tecnam P2012

Summary of Contents for Tecnam P2012

  • Page 1 P2012 AIRCRAFT MAINTENANCE MANUAL PUBLISHED BY COSTRUZIONI AERONAUTICHE TECNAM S.p.A. VIA MAIORISE - 81043 CAPUA (CE) ITALY Edition - Rev. 0 2022, Jan 14...

  • Page 3: Record Of Revisions

    P2012 AIRCRAFT MAINTENANCE MANUAL RECORD OF REVISIONS The Manual issue is identified by Edition and Revision codes reported on each page, lower right side. The revision code is numerical and consists of the number "0"; subsequent revisions are identified by the change of the code from "0" to "1" for the first revision to the basic publication, "2"...
  • Page 4 P2012 AIRCRAFT MAINTENANCE MANUAL Revision Revised chapter / Description of Revision Reference page ALL PAGES Amended to include links to referenced procedure ALL PAGES Updated to remove typos 02-00/1 to 4 Amended to include further details about preparation, management and...
  • Page 5 P2012 AIRCRAFT MAINTENANCE MANUAL Revision Revised chapter / Description of Revision Reference page 21-40/206 Added procedure ‘’Windshield FAN and Heater Test Procedure’’ 21-40/207 Added procedure ‘’Pilot Cabin Floor FAN and Heater Procedure’’ 23-30/2 to 5 Added description ‘’ Audio Integrating’’ and related figures (Mod...
  • Page 6 P2012 AIRCRAFT MAINTENANCE MANUAL Revision Revised chapter / Description of Revision Reference page 27-10/5 Updated point 1 in ‘’Operation’’ chapter 27-10/201 to 212 Added procedures ‘’Aileron Control Line Pulleys Removal/Installation’’ and related figures 27-10/213 to 222 Added procedures‘’Aileron Control Line cables Removal/Installation’’ and...
  • Page 7 P2012 AIRCRAFT MAINTENANCE MANUAL Revision Revised chapter / Description of Revision Reference page 27-10/279 to 284 Updated procedures ‘’Aileron Trim Electrical Actuator Removal/Installation’’ and related figures (Mod 2012/169, JC 1446 and TR-AMM-212-012) 27-10/285 Added procedure ‘’Aileron Trim Control System Travel Test’’...
  • Page 8 P2012 AIRCRAFT MAINTENANCE MANUAL Revision Revised chapter / Description of Revision Reference page 27-30/245, 246 Added procedure ‘’Elevator trim Control Cables Tension Adjustment’’ and related figure 27-30/247 to 249 Added procedure ‘’Trim Tab Control Rod Removal/Installation’’ and related figure 27-30/252, 253 Updated procedure ‘’Elevator trim...
  • Page 9 P2012 AIRCRAFT MAINTENANCE MANUAL Revision Revised chapter / Description of Revision Reference page 31-10/2, 4 Updated point 2 (B) in ‘’Component Description’’ chapter and added figure (Mod 2012/150) 31-10/204, 205 Added procedure ‘’Aileron Trim Switch protection Removal’’ and related figure (Mod 2012/150) 31-10/206, 207 Added procedure ‘’Flight Hour Meter...
  • Page 10 P2012 AIRCRAFT MAINTENANCE MANUAL Revision Revised chapter / Description of Revision Reference page resistance’’ Revision Revised chapter / Description of Revision Reference page 52-10/201 to 206 Added procedures ‘’Crew Doors electrical Contacts’’ and related figures 52-10/212, 213 Updated procedures ‘’Electrical Contacts Crew Doors Locking System’’...
  • Page 11 P2012 AIRCRAFT MAINTENANCE MANUAL Revision Revised chapter / Description of Revision Reference page procedure’’ and related figure (Mod 2012/157 and JC 1338) 55-20/223 Updated Figure 56-10/207 Added procedure ‘’Windows and windshield leak/rain test’’ 57-00/1 Updated point A in ‘’General’’ chapter (Mod 2012/127 and Mod...
  • Page 12 P2012 AIRCRAFT MAINTENANCE MANUAL Revision Revised chapter / Description of Revision Reference page separator Removal/Installation’’ and related figure (Mod 2012/140 and JC 1436) 79-20/212 Added procedure ‘’ Oil separator filter Cleaning/Inspection’’ (Mod 2012/140 and JC 1436) 79-20/212 Added procedure ‘’ Oil separator filter cleaning/inspection’’...
  • Page 13 P2012 AIRCRAFT MAINTENANCE MANUAL LIST OF EFFECTIVE PAGES TITLE PAGE DATE TITLE PAGE DATE TITLE PAGE RECORD OF REVISION LIST OF EFFECTIVE 2 2022, Jan 14 PAGES ENDORSED 2 2022, Jan 14 TEMPORARY REVISIONS SERVICE BULLETIN LIST 2 2022, Jan 14...

  • Page 14: List Of Effective Pages

    P2012 AIRCRAFT MAINTENANCE MANUAL INTENTIONALLY LEFT BLANK LIST OF EFFECTIVE PAGES Page 2 Edition - Rev. 0 2022, Jan 14...
  • Page 15 P2012 AIRCRAFT MAINTENANCE MANUAL ENDORSED TEMPORARY REVISION TR No. DESCRIPTION MOD No. APPROVAL DATE TR-AMM-212-001 Flap relay box relocation 2012/161 26/01/2021 TR-AMM-212-002 Application of sealant on flap actuator 2012/152 18/01/2021 microswitch TR-AMM-212-003 Support reinforcement for combustion heater 2012/160 25/01/2021 blower...
  • Page 16 P2012 AIRCRAFT MAINTENANCE MANUAL INTENTIONALLY LEFT BLANK ENDORSED TEMPORARY REVISION Page 2 Edition - Rev. 0 2022, Jan 14...

  • Page 17: Service Bulletin List

    P2012 AIRCRAFT MAINTENANCE MANUAL SERVICE BULLETIN LIST DESCRIPTION OF REVISION APPROVAL SERVICE BULLETIN LIST Page 1 Edition - Rev. 0 2022, Jan 14...
  • Page 18 P2012 AIRCRAFT MAINTENANCE MANUAL INTENTIONALLY LEFT BLANK SERVICE BULLETIN LIST Page 2 Edition - Rev. 0 2022, Jan 14...
  • Page 19 P2012 AIRCRAFT MAINTENANCE MANUAL TABLE OF CONTENTS SUBJECT PAGE INTRODUCTION 1. General 2. Warning, Cautions and Notes 3. Manual Configuration 4. Page Numbering System 5. Figures 6. Record of Revisions 7. Record of Temporary Revisions 8. List of Effective Pages 9.
  • Page 20 P2012 AIRCRAFT MAINTENANCE MANUAL INTENTIONALLY LEFT BLANK TABLE OF CONTENTS Page 2 Edition - Rev. 0 2022, Jan 14...
  • Page 21 1. General This Aircraft Maintenance Manual (AMM) gives instructions for maintenance personnel to service and maintain the TECNAM P2012 aircraft. The AMM provides sufficient information to inspect, fault isolate and to complete the removal/installation and test/adjustment of equipment as well as the repair of certain systems. To provide a coverage as complete as possible, optional equipment has been included in the manual.
  • Page 22 P2012 AIRCRAFT MAINTENANCE MANUAL The first pair of numbers shows the system. System 57 is the wings. Chapter 57 contains the data for the wings. The second pair of numbers shows the sub-system. Sub-system 50 is the Trailing Edge Flaps. Chapter 57, section 50 contains the data for the trailing edge flaps installation.
  • Page 23 P2012 AIRCRAFT MAINTENANCE MANUAL A separation sheet divides each chapter. The separation sheet shows the number of the chapter and the title. The main contents of each group of chapters are given below: Group A - Introduction Chapter 1 describes about the AMM and Chapter 2 describes how to use the AMM.
  • Page 24 P2012 AIRCRAFT MAINTENANCE MANUAL Adjustment/Tests Checking/Testing Cleaning/Painting 4. Page Numbering System This manual uses the ATA 100 page block-numbering system. The page number is at the bottom of the page at the outer edge. It is adjacent to the chapter/section number.

  • Page 25: Engine Control Unit

    P2012 AIRCRAFT MAINTENANCE MANUAL ABBREVIATION DESCRIPTION AMPERE AIRCRAFT A/COLL ANTI-COLLISION AUTOPILOT AIR DATA COMPUTER AUTOMATIC DIRECTION FINDING ADVISORY AIRCRAFT FLIGHT MANUAL AMPERE HOURS AHRS ATTITUDE AND HEADING REFERENCE SYSTEM ALTM ALTIMITER AIRCRAFT MAINTENANCE MANUAL ANNUNCIATOR AS REQUIRED ARINC AERONAUTICAL RADIO INC.
  • Page 26 P2012 AIRCRAFT MAINTENANCE MANUAL ABBREVIATION DESCRIPTION ENGINE INFORMATION SYSTEM EMER EMERGENCY ENGINE FEDERAL AVIATION ADMINISTRATION FUNCTIONAL OPERATIONAL TEST FUSELAGE STATION FORWARD GARMIN DATA COMPUTER (OR ADC) GARMIN DISPLAY UNIT (OR PFD/MFD) GARMIN ENGINE & AIRFRAME (OR EIS) GENERATOR GARMIN INTEGRATED AVIONICS (OR IAU) GARMIN MARKET BEACON &...
  • Page 27 P2012 AIRCRAFT MAINTENANCE MANUAL ABBREVIATION DESCRIPTION LIGHTS LEVER LOWER MANUAL MULTI FUNCTION DISPLAY MARKER MAIN LANDING GEAR NAVIGATION NEXT HIGHER ASSY NOSE LANDING GEAR OUTSIDE AIR TEMPERATURE OPERATIONAL CHECK OPERATOR OPTION / OPTIONAL OUTB OUTBOARD OVSP OVERSPEED OVERVOLTAGE PART NUMBER...
  • Page 28 P2012 AIRCRAFT MAINTENANCE MANUAL INTENTIONALLY LEFT BLANK ABBREVIATION Page 4 Edition - Rev. 0 2022, Jan 14...

  • Page 29: Effective Date

    P2012 AIRCRAFT MAINTENANCE MANUAL LIST OF CHAPTER CHAPTER TITLE EFFECTIVE DATE(*) TIME LIMITS AND MAINTENANCE CHECKS 2022, Jan 14 TIME LIMITS AND MAINTENANCE CHECKS 2022, Jan 14 TIME LIMITS AND MAINTENANCE CHECKS 2022, Jan 14 (*) Represents date on the first page of each chapter's List of Effective Pages.
  • Page 30 P2012 AIRCRAFT MAINTENANCE MANUAL INTENTIONALLY LEFT BLANK LIST OF CHAPTER Page 2 Edition - Rev. 0 2022, Jan 14...

  • Page 31: Time Limits And Maintenance Checks

    P2012 AIRCRAFT MAINTENANCE MANUAL CHAPTER 05 TIME LIMITS AND MAINTENANCE CHECKS...
  • Page 33 P2012 AIRCRAFT MAINTENANCE MANUAL CHAPTER 05 TIME LIMITS AND MAINTENANCE CHECKS LIST OF EFFECTIVE PAGES CH-SEC-SUB PAGE DATE CH-SEC-SUB PAGE DATE LIST OF EFFECTIVE PAGES 2022, Jan 14 05-30-00 2022, Jan 14 LIST OF EFFECTIVE PAGES 05-30-00 2022, Jan 14...
  • Page 34 P2012 AIRCRAFT MAINTENANCE MANUAL INTENTIONALLY LEFT BLANK 05 - LIST OF EFFECTIVE PAGES Page 2 Edition - Rev. 0 2022, Jan 14...

  • Page 35: Table Of Contents

    P2012 AIRCRAFT MAINTENANCE MANUAL CHAPTER 05 TIME LIMITS AND MAINTENANCE CHECKS TABLE OF CONTENTS SUBJECT CH-SEC-SUB PAGE EFFECTIVITY SCHEDULED MAINTENANCE CHECKS 05-20-00 SCHEDULED MAINTENANCE CHECKS - DESCRIPTION 05-20-00 AND OPERATION SCHEDULED MAINTANANCE INSPECTIONS SCHEDULED MAINTANANCE CHECKS LUBRICATION CHARTS 05-30-00 LUBRICATION CHARTS - DESCRIPTION AND...
  • Page 36 P2012 AIRCRAFT MAINTENANCE MANUAL INTENTIONALLY LEFT BLANK 05 - TABLE OF CONTENTS Page 2 Edition - Rev. 0 2022, Jan 14...

  • Page 37: Scheduled Maintenance Checks

    P2012 AIRCRAFT MAINTENANCE MANUAL SCHEDULED MAINTENANCE CHECKS 05-20-00 TITLE PAGE Edition - Rev. 0...

  • Page 39: Scheduled Maintenance Checks - Description

    P2012 AIRCRAFT MAINTENANCE MANUAL SCHEDULED MAINTENANCE CHECKS - DESCRIPTION AND OPERATION SCHEDULED MAINTANANCE INSPECTIONS 1. General The following Table shows the maintenance tasks performed at defined intervals to retain an item in a serviceable condition by systematic inspection, detection, replacement of wear out items, adjustment, calibration, cleaning, etc.
  • Page 40 FILTERS and FLUID for cleanliness, contamination and/or replacement if required. NOTE: Make sure that all Airworthiness Directives and Service Bulletins are implemented as required. Tecnam can change the time between checks publishing the change as a revision of this Maintenance Manual. NOTE: Inspections must be accomplished by qualified maintenance personnel.
  • Page 41 P2012 AIRCRAFT MAINTENANCE MANUAL 05-20-00 Page 3 Edition - Rev. 0 2022, Jan 14...

  • Page 42: Lubrication Chart

    P2012 AIRCRAFT MAINTENANCE MANUAL Table 2 - Scheduled Maintenance Tasks NOTE: (*) This inspection task must be applied each 100FH/1 year for compliance to 14 CFR 43 - Appendix D (**) the inspection tasks reported in this interval must be applied each 100FH/1 year...
  • Page 43 P2012 AIRCRAFT MAINTENANCE MANUAL 32-20 procedure included in ATA 32-10-00 and ) 32-10 Landing gear Check MLG and NLG for excessive plays 32-20 32-10 Landing gear Visually inspection and cleaning MLG Assy 32-20 32-10 Landing gear Visually inspection and cleaning NLG Assy...
  • Page 44 P2012 AIRCRAFT MAINTENANCE MANUAL distortion and faulty bearings. Clean, check and repack wheel 5 years (wof) bearings with grease. Refer to Maintenance manual (see Cleveland Manual AWBCMM0001-21). 32-00 Landing gear Visually inspect the wheel axes. Look especially for corrosion and 800 FH or 5 years cracks (Refer to ).
  • Page 45 P2012 AIRCRAFT MAINTENANCE MANUAL Wheel System hole elongation, corrosion and warpage. Remove corrosion and Cleveland Manual blend out small nicks using fine (400 grit) sandpaper. Replace AWBCMM0001 brake disc if worn below wear limits detailed in ClevelandManual latest issue AWBCMM0001 latest issue. Coning of disc in excess of 0.015 inch (0.381 mm) is cause of replacement.

  • Page 46: Flight Control

    P2012 AIRCRAFT MAINTENANCE MANUAL 55-00 Vertical Rudder trim actuator operational check. Active trim motor by knob Tail in cabin and verify the surface movement in accordance with selected position. 55-00 Horizontal Inspect the horizontal stabilizer attachment fitting to fuselage for Tail structural integrity and holes for elongation.
  • Page 47 P2012 AIRCRAFT MAINTENANCE MANUAL 27-00 Cabin/Tail Inspect elevator control rods, cables and attaching parts for security, routing, chafing, deterioration, wear and correct installation. Check stops for looseness and effectiveness. 27-00 Cabin/Tail Check Aileron control system. Move control and verify interference and smothness.

  • Page 48: Fire Protection

    P2012 AIRCRAFT MAINTENANCE MANUAL Zone FUSELAGE (**) 53-00 Cabin Visual inspect external skins, bulkheads, frames and rivets for damage and sealing. Inspect drainage holes for obstructions, corrosion and security. 53-00 Cabin Visual inspect both the front and rear wing attachments fittings on fuselage frames structure for integrity, corrosion, condition and security.
  • Page 49 P2012 AIRCRAFT MAINTENANCE MANUAL Protection Operate fire detector push-to-test. 26-00 Fire Inspect portable fire extinguishers, weigh and follow service instruction Protection written on the bottle (if necessary replace). Inspect for condition and ease of access. weight according the CMM latest issue.
  • Page 50 P2012 AIRCRAFT MAINTENANCE MANUAL tension, or other conditions which may lead to a failure. Inspect engine parameters sensors and fire detector sensor for general condition and security of installation. 71-00 Powerplant Inspect engine buffles for proper sealing, condition and security .
  • Page 51 P2012 AIRCRAFT MAINTENANCE MANUAL 61-00 Propeller Governor overhaul according to Maintenance Manual. Refer to CMM (see MT Propeller Doc.No. E-1049) Aircraft Maintenance Task Frequency Zone WINGS 57-00 Wings Visually inspect wing surfaces (including leading edge and fuel tank) and tips for damage and loose rivets. Check wing lower skin drain holes free obstructions.

  • Page 52: Oil System

    P2012 AIRCRAFT MAINTENANCE MANUAL proiper installation. Check actuator and position indicator for proper electrical connections. 57-00 Wings Inspect ailerons control rods for condition and security. Inspect ailerons bellcranks for condition and security of installation. Check the torque seal. Check stops for looseness and effectiveness.

  • Page 53: Fuel System

    P2012 AIRCRAFT MAINTENANCE MANUAL NOTE: (***) The ispection tasks, is superseded by those in ATA 5, Supplement S22, if MOD2012/097 is installed. Aircraft Zone Maintenance Task Frequency FUEL SYSTEM 28-00 Fuel System Inspect fuel tank vent valves free from obstruction.

  • Page 54: Communication System

    P2012 AIRCRAFT MAINTENANCE MANUAL 28-20-00 "Pressure Switch Test" ) Aircraft Maintenance Task Frequency Zone HEATING AND VANTILATION 21-00 Heating and Inspect cockpit and cabin ventilation system. Check NACA inlet, ventilation heating and blowers, air ducts and air scoops for obstruction and damage operation.

  • Page 55: Equipment And Furnishing

    P2012 AIRCRAFT MAINTENANCE MANUAL 24-00 Electrical Inspect circuit breakers panel and switches for general condition System 24-00 Electrical Inspect Connector Assembly LH and RH for condition and proper System installation. Aircraft Maintenance Task Frequency Zone C D E ELECTRICAL POWER...

  • Page 56: Indicating System

    P2012 AIRCRAFT MAINTENANCE MANUAL ATA Aircraft Zone Maintenance Task Frequency INDICATING SYSTEM 31-00 Indicating Inspect the individual instruments and switch panels for general system condition and security of installation. 31-00 Indicating Inspect all istrumental panel markings and placards for readability.
  • Page 57 P2012 AIRCRAFT MAINTENANCE MANUAL NOTE: If ''Weight on wheel'' is installed as for MOD2012/030 or MOD2012/49 refer to Supplement 16. A. Vendor Equipment Inspections. Engine Inspection Refer to Lycoming TEO-540-C1A Maintenance Manual for engine inspections and maintenance with related schedule. Consult also applicable service bulletins and instruction books regarding the repair and overhaul, inspection and installation of engines.
  • Page 58 P2012 AIRCRAFT MAINTENANCE MANUAL Table 5 - Component Maintenance Manual List Component Battery True Blue Power Installation Manual and Operating Instructions - No 9018047 Brake and Wheel Cleveland CMM (AWBCMM0001-21) Air Filter Brackett Aero Filters Doc No I-194 Engine Lycomyng MM-TEO-540-C1A...

  • Page 59: Scheduled Maintanance Checks

    P2012 AIRCRAFT MAINTENANCE MANUAL SCHEDULED MAINTANANCE CHECKS 1. General The following Table shows the maintenance tasks performed at defined intervals to retain an item in a serviceable condition by systematic inspection, detection, replacement of wear out items, adjustment, calibration, cleaning, etc. as applicable.
  • Page 60 FILTERS and FLUID for cleanliness, contamination and/or replacement if required. NOTE: Make sure that all Airworthiness Directives and Service Bulletins are implemented as required. Tecnam can change the time between checks publishing the change as a revision of this Maintenance Manual. NOTE: Inspections must be accomplished by qualified maintenance personnel.
  • Page 61 P2012 AIRCRAFT MAINTENANCE MANUAL 05-20-00 Page 23 Edition - Rev. 0 2022, Jan 14...
  • Page 62 P2012 AIRCRAFT MAINTENANCE MANUAL Table 2 - Scheduled Maintenance Tasks NOTE: (*) This inspection task must be applied each 100FH/1 year for compliance to 14 CFR 43 - Appendix D (**) the inspection tasks reported in this interval must be applied each 100FH/1 year for...
  • Page 63 P2012 AIRCRAFT MAINTENANCE MANUAL 32-10 Landing gear Visually inspection and cleaning NLG 32-20 32-10 Landing gear MLG removal, check the MLG and MLG fitting contact surfaces 32-20 for corrosion, cleaning, MLG installation, sealing the joint. 32-10 Landing gear NLG removal, check the NLG and NLG fitting contact surfaces 32-20 for corrosion, cleaning, NLG installation.
  • Page 64 P2012 AIRCRAFT MAINTENANCE MANUAL 32-20 Landing gear NLG overhaul (Ref. ATA 32-20) 10000 landings 32-10 Landing gear MLG overhaul (Ref. ATA 32-10) 10000 landings 32-40 Brake and Visually inspect for corrosion cracks or other visible damage. Every 1 years Wheel Check inlet fitting bosses and anchor bolt lugs for cracks.
  • Page 65 P2012 AIRCRAFT MAINTENANCE MANUAL Wheel not worked loose. Bolt threads should be flush to 1-1/2 threads see Cleveland System extending beyond the nut. Nuts should be on the side of wheel Manual (Main Wheel opposite the brake disc (outboard side of wheel), except in those...
  • Page 66 P2012 AIRCRAFT MAINTENANCE MANUAL cracks, distortion, dents, corrosion) refer to ATA 51-30 ATA 51-70. Check for hinges loosening, travel limits and correct operation. Hinges allowable wear is the following: -Axial ± 1.00 mm (± 0.04 in) -Radial ± 0.25 mm (± 0.01 in)
  • Page 67 P2012 AIRCRAFT MAINTENANCE MANUAL elevator trim tab control system. Item Maintenance Task Frequency FLIGHT CONTROL 27-00 Cabin/Tail Inspect control wheel, column and pulleys for smooth and free operation. (**) 27-00 Cabin/Tail Check rods, bellcranks, cables and turn -buckles removing floor inspection panels/cabin covers.
  • Page 68 P2012 AIRCRAFT MAINTENANCE MANUAL 27-00 Cabin/Tail Check Flap control line. 27-00 Cabin/Tail Check Elevator line. Move control and verify interference and smothness. Item Maintenance Task Frequency A B C D E WINDOWS 56-00 Windows Visually inspect the windshield and fuselage windows for cracks, discoloration and evidence of damages influencing the pilots and passengers visibility and safety refer to ATA 51-30 e ATA 51-70.
  • Page 69 P2012 AIRCRAFT MAINTENANCE MANUAL Item Maintenance Task Frequency C D E PLACARDS 11-00 Placards Inspect inertial placards, check for their presence, readability and wear. markings 11-00 Placards Inspect external placards and ID board: check for presence, readability and wear. markings...
  • Page 70 P2012 AIRCRAFT MAINTENANCE MANUAL corrosion, cracked or buckled tubes and engine mount isolators attachments. Check engine mount bolts and engine electrical bonding. 71-00 Powerplant Engine electrical harness and equipment : check for condition and security of installation 71-00 Powerplant Visually inspect air induction system for integrity. Check the alternate static air source valve for integrity and correct operation.
  • Page 71 P2012 AIRCRAFT MAINTENANCE MANUAL Item Maintenance Task Frequency PROPELLER 61-00 Propeller Remove front cowling and inspect propeller attaching bolts lockwire and lubber lines. Check bolts proper torquing (refer to CMM MT Propeller E-124). 61-00 Propeller Check for free movement of propeller levers. Check propeller control cables full travel and correct operation.
  • Page 72 P2012 AIRCRAFT MAINTENANCE MANUAL 51-30. 57-00 Wings Visually inspect the interior structure of the wing. 57-00 Wings Inspect wing forward and aft attachment bolts for condition and security (removing the closest part of the wing leading edge with the fuselage and interior roof panel).
  • Page 73 P2012 AIRCRAFT MAINTENANCE MANUAL Item Maintenance Task Frequency B C D E OIL SYSTEM 79-00 Oil System Check oil lines: there should be no indication of leakages 79-00 Oil System Visually inspect oil radiator and hoses for condition and security of installation...
  • Page 74 P2012 AIRCRAFT MAINTENANCE MANUAL 28-00 Fuel Inspect fuel valves for leaks, general condition and security of System installation 28-00 Fuel Inspect operation of fuel selector valve control levers. Check System for selector valve and bowden cable restricted movement, interference or unusual play.
  • Page 75 P2012 AIRCRAFT MAINTENANCE MANUAL 23-00 Communicatio Check communication equipment (including tranponder) according to local rules. Item Maintenance Task Frequency ELECTRICAL POWER 24-00 Electrical Check batteries installation. Inspect battery cables and System housing. Check vent lines free of obstructions. 24-00 Electrical...
  • Page 76 P2012 AIRCRAFT MAINTENANCE MANUAL Item Maintenance Task Frequency EQUIPMENT AND FURNISHING 25-0 Equipment Inspect seats, check condition and regulations, check the seat guide and seat guide attachments for unusual furnishings wear. furnishing 25-0 Equipment Check safety belts for condition and operation. Inspect safety belts attachments.
  • Page 77 P2012 AIRCRAFT MAINTENANCE MANUAL installation and damage. Check related dimmers devices for proper operation. 33-00 Lights Perform a light operational test (external and internal lights). Item Maintenance Task Frequency NAVIGATION 34-00 Navigation Inspect Navigation equipment for general condition, operation and security of installation according to local rules.
  • Page 78 P2012 AIRCRAFT MAINTENANCE MANUAL NOTE: If ''Weight on wheel'' is installed as for MOD 2012/030 or MOD 2012/49 refer to Supplement NOTE: (***) The maintenance tasks, are replaced by the ones of Supplement S22, if MOD2012/097 is installed. A. Vendor Equipment Inspections.
  • Page 79 P2012 AIRCRAFT MAINTENANCE MANUAL Table 5 - Component Maintenance Manual List Component Battery True Blue Power Installation Manual and Operating Instructions - No 9018047 Brake and Wheel Cleveland CMM (AWBCMM0001-21) Air Filter Brackett Aero Filters Doc No I-194 Engine Lycomyng MM-TEO-540-C1A...
  • Page 80 P2012 AIRCRAFT MAINTENANCE MANUAL INTENTIONALLY LEFT BLANK 05-20-00 Page 42 Edition - Rev. 0 2022, Jan 14...

  • Page 81: Lubrication Charts

    P2012 AIRCRAFT MAINTENANCE MANUAL LUBRICATION CHARTS 05-30-00 TITLE PAGE Edition - Rev. 0...

  • Page 83: Lubrication Charts

    P2012 AIRCRAFT MAINTENANCE MANUAL LUBRICATION CHARTS - DESCRIPTION AND OPERATION LUBRICATION CHARTS 1. General Proper lubrication procedures allow for A/C service life extension and for reducing the frequency of repairs. In addition, periodic application of recommended lubricants, as detailed in the following paragraphs, and observance of parts cleanliness will insure the maximum efficiency of all moving parts.
  • Page 84 P2012 AIRCRAFT MAINTENANCE MANUAL NOTE: Remove all excess lubricants from components in order to prevent the collection of dirt and sand in abrasive quantities capable of causing excessive wear or damage to bearing surfaces. WARNING: Do not apply lubricant to rubber parts.
  • Page 85 P2012 AIRCRAFT MAINTENANCE MANUAL 2. Lubrication Charts and Schedule Table 2 - Lubrication Charts Description Reference Grease, item Pedals bushing Refer to Fig.1 10 or equivalent Rudder Steering Bellcrank bearing Refer to Fig.1 8, 9 or equivalent Pedal tube attachments Refer to Fig.1...
  • Page 86 P2012 AIRCRAFT MAINTENANCE MANUAL NOTE: Before to perform greasing put the Trim tab surface in full nose UP position (trim actuator full retracted), grease the Trim Actuator, set the Trim tab surface in full nose down position (trim actuator extended) and than in neutral position.
  • Page 87 P2012 AIRCRAFT MAINTENANCE MANUAL Pilot and Copilot Pedals Figure 1 05-30-00 Page 5 Edition - Rev. 0 2022, Jan 14...
  • Page 88 P2012 AIRCRAFT MAINTENANCE MANUAL Rudder Flight Control - Pulley and Cable Terminal Figure 2 05-30-00 Page 6 Edition - Rev. 0 2022, Jan 14...
  • Page 89 P2012 AIRCRAFT MAINTENANCE MANUAL Aileron Flight Control Figure 3 05-30-00 Page 7 Edition - Rev. 0 2022, Jan 14...
  • Page 90 P2012 AIRCRAFT MAINTENANCE MANUAL Aileron Flight Control - Control Column Figure 4 05-30-00 Page 8 Edition - Rev. 0 2022, Jan 14...
  • Page 91 P2012 AIRCRAFT MAINTENANCE MANUAL Aileron Flight Control - Pulley and Rod Figure 5 05-30-00 Page 9 Edition - Rev. 0 2022, Jan 14...
  • Page 92 P2012 AIRCRAFT MAINTENANCE MANUAL Elevator Flight Control Figure 6 (Sheet 1 of 2) 05-30-00 Page 10 Edition - Rev. 0 2022, Jan 14...
  • Page 93 P2012 AIRCRAFT MAINTENANCE MANUAL Elevator Flight Control Figure 6 (Sheet 2 of 2) 05-30-00 Page 11 Edition - Rev. 0 2022, Jan 14...
  • Page 94 P2012 AIRCRAFT MAINTENANCE MANUAL Elevator Hinge Figure 7 05-30-00 Page 12 Edition - Rev. 0 2022, Jan 14...
  • Page 95 P2012 AIRCRAFT MAINTENANCE MANUAL Rudder Figure 8 05-30-00 Page 13 Edition - Rev. 0 2022, Jan 14...
  • Page 96 P2012 AIRCRAFT MAINTENANCE MANUAL Flap Flight Control Figure 9 (Sheet 1 of 2) 05-30-00 Page 14 Edition - Rev. 0 2022, Jan 14...
  • Page 97 P2012 AIRCRAFT MAINTENANCE MANUAL Flap Flight Control Figure 9 (Sheet 2 of 2) 05-30-00 Page 15 Edition - Rev. 0 2022, Jan 14...
  • Page 98 P2012 AIRCRAFT MAINTENANCE MANUAL Flap Hinge Figure 10 05-30-00 Page 16 Edition - Rev. 0 2022, Jan 14...
  • Page 99 P2012 AIRCRAFT MAINTENANCE MANUAL Nose Landing Gear Figure 11 05-30-00 Page 17 Edition - Rev. 0 2022, Jan 14...
  • Page 100 P2012 AIRCRAFT MAINTENANCE MANUAL Main Landing Gear Figure 12 05-30-00 Page 18 Edition - Rev. 0 2022, Jan 14...
  • Page 101 P2012 AIRCRAFT MAINTENANCE MANUAL Elevator Trim Hinge Bushings Figure 13 05-30-00 Page 19 Edition - Rev. 0 2022, Jan 14...
  • Page 102 P2012 AIRCRAFT MAINTENANCE MANUAL Aileron Hinge Bushings Figure 14 05-30-00 Page 20 Edition - Rev. 0 2022, Jan 14...
  • Page 103 P2012 AIRCRAFT MAINTENANCE MANUAL Main Door Foot Board Hinge Figure 15 05-30-00 Page 21 Edition - Rev. 0 2022, Jan 14...
  • Page 104 P2012 AIRCRAFT MAINTENANCE MANUAL Crew Door Hinge Figure 16 05-30-00 Page 22 Edition - Rev. 0 2022, Jan 14...
  • Page 105 P2012 AIRCRAFT MAINTENANCE MANUAL Cargo Door Hinge Figure 17 05-30-00 Page 23 Edition - Rev. 0 2022, Jan 14...
  • Page 106 P2012 AIRCRAFT MAINTENANCE MANUAL Rod End Upper Main Door Figure 18 05-30-00 Page 24 Edition - Rev. 0 2022, Jan 14...
  • Page 107 P2012 AIRCRAFT MAINTENANCE MANUAL Crew Door Foot Board Figure 19 05-30-00 Page 25 Edition - Rev. 0 2022, Jan 14...
  • Page 108 P2012 AIRCRAFT MAINTENANCE MANUAL RH Emergency Door Figure 20 05-30-00 Page 26 Edition - Rev. 0 2022, Jan 14...
