TECNAM P2010tdi
M
ANUFACTURER
A
IRCRAFT MODEL
S
ERIAL NUMBER
: ...............................................
B
UILD YEAR
R
EGISTRATION MARKINGS
This manual must be carried in the airplane at all times.
The airplane has to be operated in compliance with procedures and limitations
contained herein.
This manual also constitutes the FAA Approved Airplane Flight Manual for
U.S. operations in accordance with FAR 21.29.
Costruzioni Aeronautiche TECNAM S.p.A.
Via Maiorise
CAPUA (CE) – Italy
Tel. +39 0823 99.75.38
WEB:
www.tecnam.com
Thisdocument and the information thereon is the property of Costruzioni Aeronautiche Tecnam S.p.A., and may only be used
for the purpose for which Tecnam products are supplied, and/or use and maintenance of Tecnam Aircraft.
Reproduction or use of the data, information, drawings thereon, in whole or in part, is strictly Prohibited without
the express written permission of Costruzioni Aeronautiche Tecnam S.p.A.
P2010tdi – Aircraft Flight Manual
Aircraft Flight Manual
Doc. No. 2010/552
Ed.2 Rev.4
2022, November 21
: COSTRUZIONI AERONAUTICHE TECNAM
: P2010tdi
:.....................................
: ........................
S.p.A.
