25 Watt VHF/FM Marine Transceiver
PHANTOM Series PS1000
SERVICE MANUAL
EM015N90A
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PHANTOM PS1000 and is the answer not in the manual?

Questions and answers

Related Manuals for Standard Horizon PHANTOM PS1000

Summary of Contents for Standard Horizon PHANTOM PS1000

  • Page 1 25 Watt VHF/FM Marine Transceiver PHANTOM Series PS1000 SERVICE MANUAL EM015N90A...

  • Page 2: Specifications

    Specifications GENERAL Channels: All USA, International and Canadian Input Voltage: 13.8 VDC ±20% Current Drain: Standby 0.3 A Receive 0.5 A Transmit 5.5 A (Hi); 1.5 A (Lo) Dimensions: 2-1/2” H x 6-5/16” W x 6-5/16” D (64 H x 160 W x 160 D mm) Flush-Mount Dimensions: 2”...

  • Page 3: Exploded View & Miscellaneous Parts

    Exploded View & Miscellaneous Parts RA045870B (BLACK) SLEEVE ASSY BK RA0422700 RUBBER PACKING FRONT RA0421500 (x 2pcs) O RING (SCREW) P1091158 MR-S AM001N RA0422900 O RING M CONECT RA0423000 HOLDER PLATE PWR RA0558400 CHASSIS T9207185 WIRE ASSY AM015N RA0423100 O RING BOTTOM RA0292100 SHEET (MICROTEX C010) G1093695...
  • Page 4 Note...

  • Page 5: Connection Diagram

    Connection Diagram...

  • Page 6: Block Diagram

    Block Diagram...

  • Page 7: Circuit Description

    Circuit Description Reception and transmission are switched by a shift regis- PLL Synthesizer ter IC Q1020 (BU4094BCFV) which is controlled by seri- The 1st LO maintains stability from the PLL synthesizer al data lines from the CNTL Unit. The receiver uses dou- by using a 21.850 MHz reference signal from crystal X1001.
  • Page 8 Circuit Description The RF energy then passes through antenna switch D1003 Decoder (XB15A308) and a low-pass filter circuit and finally to The receiving DCS code is demodulated by the FM IC Q1037 (TA31136FN), then fed through the low-pass filter the antenna connector. Q1039 (2SC4154E) to the DCS Decoder IC Q1043 RF output power from the final amplifier is sampled by (NJM2211M) which the receiving DCS code is decoded.

  • Page 9: Required Test Equipment

    Alignment The Phantom PS1000 has been carefully aligned at the Required Test Equipment factory for the specified performance across the marine RF Signal Generator with calibrated output level at band. 200 MHz Deviation Meter (linear detector) Realignment should therefore not be necessary except in AF Millivoltmeter the event of a component failure.

  • Page 10: Deviation Adjustment

    Alignment Reference Frequency Adjustment Deviation Adjustment Setup the test equipment as shown below. Setup the test equipment as shown below. Sampling Sampling Coupler Coupler 50-ohm 50-ohm AF Signal PS1000 CMP25 PS2000 Dummy Load Dummy Load J1001 Generator Pin 2 Deviation Frequency CMP25 Meter...

  • Page 11: Receiver Front-End Adjustment

    Alignment Receiver Front-end Adjustment Software Alignment (Squelch Adjustment) Setup the test equipment as shown below. Set the channel to CH16. Turn the transceiver’s power off. Tracking Spectrum PS1000 Short the TEST points (JP1001). Generator Analizer TP1013 Press and hold the PWR switch on the CMP25 RAM+ Microphone until the transceiver turns on while press and holding the [ DISTRESS ] and [ H/L ] keys on the CMP25...
  • Page 12 Alignment Note...

  • Page 13: Main Unit

    MAIN Unit Circuit Diagram RX: +6.0 dBµ (21.4 MHz) RX: +4.0 dBµ RX: 7.6 V RX: –7.0 dBµ (21.4 MHz) RX: 7.5 V RX: 1.0 V RX: 0 V RX: 1.9 V RX: –11 dBµ RX: 0 V TX: 0.7 V RX: 2.1 V RX: 7.8 V RX: 1.7 V (@–10.0 dBµ)
  • Page 14 MAIN Unit MAIN Unit Note...
  • Page 15 MAIN Unit Parts Layout (Side A) RA35H1516 NJM78M05DL1A NJM7808FA (Q1012) (Q1011) (Q1006) BU4053BCFV BU4066BCFV NJM2904V (Q1041) (Q1036) (Q1001, 1003) BU4094BCFV NJM12902V (Q1020) (Q1002) MB15A02PFV1 (Q1028) TA31136FN (Q 1037) 2SK520 (K41) 3SK320 (U7) (Q1030) (Q1031) 2SA1602A (MF) 2SB1301 (ZQ) (Q1014) (Q1004) 2SC3357 (MF) 2SC4154 (LE) DTA144EE (16)
  • Page 16 MAIN Unit Parts Layout (Side B) NJM2212M 2SA1162GR (SG) 2SB1301 (ZQ) (Q1043) (Q1032) (Q1005) 2SC2712GR (LG) RT1N441U (M3) MC2850 (A7) (Q1033) (Q1010, 1023) (D1016, 1017) 2SC4154 (LE) (Q1021, 1038, 1039, 1042) 2SC4400 (RT4) (Q1035) 2SC5006 (24) (Q1019) 1SS302 (C3) 1SS321 (F9) (D1008) (D1002) DAN235U (M)
  • Page 17 MAIN Unit Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR PCB with Components CB3085001 Printed Circuit Board FR011110D C 1001 CERAMIC CAP. 15pF CHU5 150J6 K02179104 C 1003 CHIP CAP. GRM39CH040C50PT K22174205 C 1005 CERAMIC CAP.
  • Page 18 MAIN Unit Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR C 1113 CHIP CAP. 0.001uF GRM39B102K50PT K22174821 C 1114 CHIP CAP. GRM39CK020C50PT K22174203 C 1115 CHIP CAP. GRM39CH050C50PT K22174206 C 1116 CHIP CAP. 22pF GRM39CH220J50PT K22174219 C 1117...
  • Page 19 MAIN Unit Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR C 1204 CHIP CAP. 39pF GRM39CH390J50PT K22174225 C 1205 CHIP CAP. 0.1uF GRM39B104K16PT K22124805 C 1206 CHIP CAP. 0.01uF GRM39B103M50PT K22174823 C 1207 CHIP CAP. GRM39CK010C50PT K22174202 C 1208...
  • Page 20 MAIN Unit Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR D 1014 DIODE HVC306B TRU G2070918 D 1015 DIODE UDZS TE-17 5.6B G2070910 D 1016 DIODE MC2850-T11-1 G2070704 D 1017 DIODE MC2850-T11-1 G2070704 D 1018 SURGE ABSORBER DSP-141N-S00B Q9000586...
  • Page 21 MAIN Unit Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR R 1004 CHIP RES. 1/16W RMC1/16 683JATP J24185683 R 1005 CHIP RES. 100k 1/16W RMC1/16 104JATP J24185104 R 1006 CHIP RES. 1/16W RMC1/16 000JATP J24185000 R 1007 CHIP RES.
  • Page 22 MAIN Unit Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR R 1087 CHIP RES. 1/16W RMC1/16 681JATP J24185681 R 1088 CHIP RES. 4.7k 1/16W RMC1/16 472JATP J24185472 R 1089 CHIP RES. 1/16W RMC1/16 101JATP J24185101 R 1090 CHIP RES.
  • Page 23 MAIN Unit Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR R 1175 CHIP RES. 1/16W RMC1/16 103JATP J24185103 R 1176 CHIP RES. 1/16W RMC1/16 103JATP J24185103 R 1177 CHIP RES. 100k 1/16W RMC1/16 104JATP J24185104 R 1178 CHIP RES.

  • Page 24: Parts List

    MAIN Unit Parts List Note DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR...
  • Page 25 CNTL Unit Circuit Diagram CPU5V RESET 90 msec POWER “ON”: 5.0 V POWER “OFF”: 0 V 1.9 Vp-p 4.1 Vp-p @ STANDARD DEV. 5.0 V @ STANDARD DEV. 3.3 Vp-p 5.0 V 5.0 V DSC SCAN “OFF”: 5.0 V 5.1 V 5.1 V 4.9 V POWER “ON”: 0 V...
  • Page 26 CNTL Unit Note...
  • Page 27 CNTL Unit Parts Layout (Side A) Side A...
  • Page 28 CNTL Unit Parts Layout (Side B) HD64F2266TF13 BR24L64F TC7W14FU (Q2001) (Q2009) (Q2002) 2SA1602A (MF) DTA144EE (16) 2SC4154 (LE) (Q2007, 2011) (Q2018) (Q2008, 2012, 2013) NJM78L05UA (8C) PST597CNR (7C) RT1N441U (N3) (Q2003) (Q2005) (Q2004, 2006, 2014, 2019) Side B HZM27WA (27A) (D2001, 2002)
  • Page 29 RMC1/16 101JATP J24185101 R 2017 CHIP RES. 1/16W RMC1/16 103JATP J24185103 R 2018 CHIP RES. 1/16W RMC1/16 471JATP J24185471 R 2019 CHIP RES. 1/4W RMC1/4 121JATP J24245121 R 2020 CHIP RES. 1/16W RMC1/16 473JATP J24185473 : Please contact Standard Horizon...
  • Page 30 CNTL Unit Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR R 2021 CHIP RES. 1/16W RMC1/16 471JATP J24185471 R 2022 CHIP RES. 1/16W RMC1/16 220JATP J24185220 R 2023 CHIP RES. 1/16W RMC1/16 471JATP J24185471 R 2024 CHIP RES.
  • Page 31 CMP25 RAM+ MIC Exploded View & Miscellaneous Parts RA0522000 RUBBER KNOB (TOP) RA0522400 RA0522700 LIGHT GUIDE (TOP) LOCK PLATE (PTT) RA0433200 HOOK RA0522600 RA0524500 SPACER (PTT) WEIGHT RA0522500 LOCK PLATE RA0522100 RA0528600 (TOP) PTT KNOB SHEET (PCB) RA0524100 REFLECTOR SHEET(LCD) RA0519600 REAR CASE ASSY (WHITE) RA0524200...
  • Page 32 CMP25 RAM+ MIC Circuit Diagram...

  • Page 33: Parts Layout (Side A)

    CMP25 RAM+ MIC Parts Layout (Side A) 1SS300 (A3) 2SA1745 (ES) (D1) (Q1) 1SS302 (C3) 2SB1123 (BF) (D2, 3, 4) (Q3) TC7W53FU 2SC4555 (UT) (IC01, 03) (Q4, 5) TC7W14FU (IC07) TA75S01F (SA) 2SD1801S (IC04, 05) (Q6) TA78L05F (AE) LA4627 (IC06) (IC08) M62429FP PST597CN (7C)

  • Page 34: Parts Layout (Side B)

    CMP25 RAM+ MIC Parts Layout (Side B) COMMON SEGMENT LCD (LCD1)
  • Page 35 CMP25 RAM+ MIC Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR PCB with Components S8101542 Chip Tantal 4.7uF ESVP1A4R7M K48120031 Chip Cap 1000P GRM39B102K50PT K22174821 Chip Cap 1000P GRM39B102K50PT K22174821 Chip Cap 1000P GRM39B102K50PT K22174821 Chip Cap GRM39CH150J 50PT...
  • Page 36 CMP25 RAM+ MIC Parts List DESCRIPTION VALUE TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR Power Switching/Power Drive 2SB1188 2SB1123 S8101525 Low Frequ. Amp 2SC4097 2SC4555 S8101527 Low Frequ. Amp 2SC4097 2SC4555 S8101527 Power Switching 2SD1758 2SD1801S G3418018S Chip Resister 1/16W CR1/16-102KJV...
