PHANTOM Series PS1000
25 Watt VHF/FM
Marine Transceiver
Owner's Manual
Hide away black box VHF specifically designed for vessels with
limited mounting space
Supplied with a enhanced RAM+ remote control microphone
RTCM SC-101 DSC Distress call with your exact position
DSC position request/send function and NMEA data input/output
to connect to GPS Plotter
DSC Group call feature included
Channel Name, GPS Time or GPS Position Repeating shown on
the display
One-button access to Channel 16 and 9
NOAA Weather Alert
Versatile User-programmable Scan, Priority Scan and Dual Watch
Access to all US, Canadian and International Channels
3 year waterproof warranty
with GPS connected
Phantom PS1000
Page 1
Advertisement
Table of Contents
Related Manuals for Standard Horizon PHANTOM PS1000
Summary of Contents for Standard Horizon PHANTOM PS1000
- Page 1 Channel Name, GPS Time or GPS Position Repeating shown on the display One-button access to Channel 16 and 9 NOAA Weather Alert Versatile User-programmable Scan, Priority Scan and Dual Watch Access to all US, Canadian and International Channels 3 year waterproof warranty with GPS connected Phantom PS1000 Page 1...
-
Page 2: Table Of Contents
8.9 CHANGING GPS INFORMATION TO VESSEL POSITION OR COG ... 15 8.10 OPTIONAL MMB-84 FLUSH MOUNT INSTALLATION ... 16 CONTROLS AND INDICATORS ... 18 9.1 PHANTOM PS1000 TRANSCEIVER ... 18 9.2 CMP25 RAM+ MICROPHONE ... 20 10 BASIC OPERATION ... 22 10.1 RECEPTION ... - Page 3 12.10 EXTERNAL SPEAKER SELECTION ... 53 13 MAINTENANCE ... 54 13.1 REPLACEMENT PARTS ... 54 13.2 FACTORY SERVICE ... 54 14.3 TROUBLESHOOTING CHART ... 55 14 CHANNEL ASSIGNMENTS ... 56 15 WARRANTY ... 62 16 SPECIFICATIONS ... 65 Phantom PS1000 Page 3...
-
Page 4: General Information
1 GENERAL INFORMATION The Phantom PS1000 is an RTCM SC-101 DSC Hide away black box VHF specifically designed for vessels with limited mounting space. It is supplied with a RAM+ microphone that can control all radio, DSC (including Distress), from any remote location aboard, at the Nav station, cockpit, tower or lower helm station. -
Page 5: Safety / Warning Information
FCC RF exposure requirements. ON-LINE WARRANTY REGISTRATION Please visit www.standardhorizon.com to register the Phantom PS1000 Marine VHF. It should be noted that visiting the Web site from time to time may be beneficial to you, as new products are released they will appear on the Marine Division of Vertex Standard Web site. -
Page 6: Fcc Radio License Information
Type Acceptance ... FCC Part 80 Output Power ... 1 Watt (low) and 25 Watts (high) Emission ... 16K0G3E, 16K0G2B Frequency Range ... 156.025 to 163.275 MHz FCC Type Number ... K6630053X30 Industry Canada Type Approval ... 511B-30053X30 Page 6 Phantom PS1000... -
Page 7: Fcc Notice
- Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Phantom PS1000 NOTICE NOTICE Page 7... -
Page 8: Getting Started
Typically a 3 foot 3dB gain stainless steel whip is used on a sailboat mast. The longer 8 foot 6dB fiberglass whip is primarily used on power boats that require the additional gain. Page 8 Phantom PS1000... -
Page 9: Coaxial Cable
To get your coax cable through a fitting and into your boat’s interior, you may have to cut off the end plug and reattach it later. You can do this if you follow the directions that come with the connector. Be sure to make good soldered connections. Phantom PS1000 1/16'' 3/4'' 1 1/8''... -
Page 10: Installation
• allows connection to a power source and an antenna • It is recommended not to mount the antenna closer than three feet from the Phantom PS1000. Note: To insure the radio does not affect the compass or radios performance is... -
Page 11: Cmp25 Ram+ Microphone Installation
1. Connect the RAM+ MIC Cable to the RAM MIC CONNECTOR on the rear panel of the Phantom PS1000, then tighten the Cable Nut (See Figure 2). 2. Referring to Figure 3, make a 1.2” (30 mm) hole in the wall, then insert the RAM+ MIC Cable into this hole. -
Page 12: Accessory Cable
Brown NMEA IN Connection Examples Connect to NMEA (+) output of GPS Connect to NMEA (–) output of GPS Connect to NMEA ( + ) input of GPS Connect to NMEA (–) input of GPS .” GPS Receiver Phantom PS1000... -
Page 13: Connection Of Gps With Nmea Output
8.6 CHECKING GPS CONNECTIONS After battery, GPS and the RAM+ microphone(s) have been connected, press the power switch on the Phantom PS1000 and press and hold the power key on a RAM+ mic, a small satellite icon will apper on the top right corner of the LCD display. -
Page 14: Changing The Gps Time
Time Coordinated or GMT Greenwich Mean Time). 5. Press the [ CALL ( SET ) MENU ] key to store the time offset. 6. Press the [ 16/9 ] key to return to radio operation. Page 14 ” menu. Phantom PS1000... -
Page 15: Changing Cog To True Or Magnetic
5. Press the [ CALL ( SET ) MENU ] key to store the selected set- ting. 6. Press the [ 16/9 ] key to return to radio operation. Phantom PS1000 ” menu. ] key to select “ (Magnetic)” or “... -
Page 16: Optional Mmb-84 Flush Mount Installation
(see Figure 4). 5. Turn the adjusting screw to adjust the tension so that the transceiver is tight against the mounting surface. Bracket Lock-washer nut combination Figure 4. MMB-84 Flush Mount Installation Page 16 Adjusting Screw Phantom PS1000... - Page 17 MEMO Phantom PS1000 Page 17...
-
Page 18: Controls And Indicators
9 CONTROLS AND INDICATORS This section defines each control, switch, and connector of the Phan- tom PS1000 Transceiver and CMP25 RAM+ Microphone. For detailed operating instructions refer to section “10. BASIC OPERATION.” 9.1 PHANTOM PS1000 TRANSCEIVER Page 18 NOTE Phantom PS1000... -
Page 19: Antenna Jack
RAM+ MIC CONNECTOR Connects the Phantom PS1000 to the CMP25 RAM+ Microphone. ACCESSORY CONNECTION CABLE Connects the Phantom PS1000 to a GPS. See section “3. OPTION” for a list of speakers STANDARD HORIZON offers. DC INPUT CABLE Connects the radio to a DC power supply capable of delivering 12V DC. -
Page 20: Cmp25 Ram+ Microphone
9. Pressing the [ 16/9 ] key reverts to the previous selected working channel. Secondary use Press and hold the [ 16/9 ] key then press the [ WX ] key to switch the USA, International or Canadian channels. Page 20 SCAN CALL Phantom PS1000... - Page 21 Holding down the [16/9] key while pressing the [WX] key switch the Chan- nel Group. [ DISTRESS ] KEY Used to send a DSC Distress Call. To send the distress call refer to section “11.4.1. Transmitting a DSC Distress Call.” Phantom PS1000 Page 21...
-
Page 22: Basic Operation
2. Press and hold the [ PWR ] key on the RAM+ mic or on the front panel of the Phantom PS1000 until the radio turns on. 3. Press the [ SQL ] key, then press the [ ] key until the “... -
Page 23: Simplex/Duplex Channel Use
Follow the same procedure as for regular channels under section “10.12 SCANNING.” 2. Press the [ SCAN ] key once to start memory scanning or hold down the [ SCAN ] key during memory scanning to start priority scanning. Phantom PS1000 NOTE NOTE Page 23... -
Page 24: Noaa Weather Alert Testing
10.6.2 NOAA Weather Alert Testing NOAA tests the alert system ever Wednesday between 11AM and 1PM. To test the Phantom PS1000’s NOAA Weather feature, on Wednesday between 11AM and 1PM, setup as in previous section and confirm the alert is heard. -
Page 25: Calling Another Vessel (Channel 16 Or 9)
Call Sign with each transmission, only at the begin- ning and end of the contact. Remember to return to Channel 16 when not using another channel. Some radios automatically monitor Channel 16 even when set to other channels or when scanning. Phantom PS1000 Page 25... -
Page 26: Making Telephone Calls
2. If a transmission is received on the channel selected in step 2, the Phantom PS1000 will dual watch between the work- ing channel and the Channel 16. 4. To stop Dual Watch, press the [ DW ] key again. -
Page 27: Scanning
7. To stop scanning, press the [ SCAN ] , [ CALL ( SET ) MENU ] , [ WX ] , [ 16/9 ] , [ DIS- TRESS ] , or PTT key. Phantom PS1000 ” menu appears. ” menu. -
Page 28: Priority Scanning P-Scan
10.12.3 Priority Scanning P-SCAN The Phantom PS1000 is set to Channel 16 as the priority channel. 1. Set the squelch level to the “squelch threshold” (the background noise is disappeared). 2. Select a desired channel to be scanned using the [ ] or [ ] key, then press and hold the [ SCAN ] key. -
Page 29: Navigation Indication
You may display the COG (Course Over Ground) data in the LCD instead of your vessel position (LAT/LON) by the Radio Setup Mode, refer to section “12.4 CHANGING GPS INFOR- MATION TO VESSEL POSITION OR COG.” Phantom PS1000 NO POS ” ( Time ) -
Page 30: Digital Selective Calling
This new system allows mariners to instantly send a distress call with GPS posi- tion (when connected to the transceiver) to the Coast Guard and other vessels within range of the transmission. Phantom PS1000 will allow mariners to initiate Individual Routine, Group Routine, All Ship Urgency, All Ship Safety, Position Re-... -
Page 31: Dsc Scan
5. Press the [ CALL ( SET ) MENU ] key to store the se- lected setting. 6. To exit this menu and return to radio operation mode press the [ 16/9 ] key. Phantom PS1000 ” menu appears. ” menu. ” or “... -
Page 32: Maritime Mobile Service Identity (Mmsi)
Digital Selective Calling (DSC). This number is used like a telephone number to selectively call other vessels. THIS NUMBER MUST BE PROGRAMMED INTO THE RADIO TO OPERATE THE PHANTOM PS1000 DSC FUCTIONS. How can I obtain an MMSI assignment? Boat US offers online registration of a MMSI. Visit www.boatus.com/mmsi 11.3.2 Programming the MMSI... -
Page 33: Dsc Distress Call
11.4 DSC DISTRESS CALL The Phantom PS1000 is capable of transmitting and receiving DSC Distress messages to all DSC radios. The Phantom PS1000 may be connected to a GPS to also transmit the Latitude, Longitude of the vessel in a distress. -
Page 34: Cancel A Dsc Distress Call
11.4.2 Cancel a DSC Distress Call If a DSC Distress call was sent by error the Phantom PS1000 allows you to send a message to other vessels to cancel the Distress Call that was made in error. 1. Press the [ DISTRESS ] key momentarily. The “... -
Page 35: All Ships Call
3. Press the [ ] or [ vessel transmitting the All Ships Call. 4. Monitor channel 16 or traffic channel until the UR- GENCY voice communication is completed. Phantom PS1000 ALL SHIPS ”). ] key to see the MMSI of the ”... -
Page 36: Individual Call
11.6.1 Setting up the Individual / Position Call Directory The Phantom PS1000 has a DSC directory that allows you to store a vessel or person’s name and the MMSI number associated with vessels you wish to transmit Individual calls, Position Requests and Position Send transmissions. -
Page 37: Setting Up Individual Ringer
” menu, then press the [ CALL ( SET ) MENU ] RINGER key. 4. Press the [ ] or [ ] key to select ringing time of a Individual/Group Call. : 3 minutes continuously Phantom PS1000 ” menu appears. DSC SETUP ” menu, INDIVIDUAL RE- ( Automatic ) ”... -
Page 38: Transmitting An Individual Call
5. Press the [ CALL ( SET ) MENU ] key to store the selected setting. 6. To exit this menu and return to radio operation mode press the [ 16/9 ] key. The Phantom PS1000 has the capability to turn off the Individual or Group call ringer. -
Page 39: Receiving An Individual Call
] or [ [ CALL ( SET ) MENU ] key to transmit the individual DSC signal. 4. Press the PTT on the microphone and talk to the calling ship. Phantom PS1000 NO REPLY ” notition SEND ,” then press the... -
Page 40: Setting Up The Call Waiting Function
11.6.6 Setting Up the Call Waiting Function Allows the Phantom PS1000 to be setup to reply (ABLE) or set the radio so it transmits a call that advises the calling vessel the person is UNABLE to reply to the call at this time. This function is similar to an answering machine. When set up in UNABLE and a individual call is received the Individual call from the other vessel is logged in the CALL WAITING directory for you to review and call back at a later time. -
Page 41: Transmitting A Group Call
6. Listen to the channel to make sure it is not busy, then key the microphone and call the other vessels you desire to com- municate with. Phantom PS1000 GROUP ” menu, Page 41... -
Page 42: Receiving A Group Call
PS1000. Standard Horizon has taken this feature one step further, if any Stan- dard Horizon GPS is connected to the Phantom PS1000, the polled position of the vessel is shown on the display of the GPS chart plotter making it easy to navigate to the location of the polled vessel. -
Page 43: Transmitting A Position Request To Another Vessel
3. Press the [ ] or [ ] key to select the “name” you want to contact. 4. Press the [ CALL ( SET ) MENU ] key to transmit the Phantom PS1000 ” menu appears. DSC SETUP ” menu, POS REQUEST ”... -
Page 44: Receiving A Position Request
LCD. 7. Press the [ ] or [ ] key to see the name and posi- tion (LAT/LOG) of the vessel polled vessel. 8. If the Phantom PS1000 does not receive a reply, the LCD will display “ SEND and select “... -
Page 45: Position Send
Your vessel must have an operating GPS receiver connected for the Phantom PS1000 to send the position. 11.9.1 Setting up a Position Send Ringer The PS1000 has the capability to turn off the Position Send ringer. -
Page 46: Receiving A Dsc Position Send Call
2. Press any key to stop ringing. 3. Press the [ ] or [ ] key to see the name and posi- tion (LAT/LOG) of the of the vessel transmitting the Position Send Call. Page 46 RECEIVED POS Phantom PS1000... - Page 47 MEMO Phantom PS1000 Page 47...
-
Page 48: Radio Setup Mode
5. Press the [ CALL ( SET ) MENU ] key to store the selected level. 6. Press the [ 16/9 ] key to return to radio operation. Page 48 ” menu. (off)” to “ .” ” menu. ” to “ .” Phantom PS1000... -
Page 49: Time Offset
Time Coordinated or GMT Greenwich Mean Time). 5. Press the [ CALL ( SET ) MENU ] key to store the time offset. 6. Press the [ 16/9 ] key to return to radio operation. Phantom PS1000 ” menu. Page 49... -
Page 50: Changing Gps Information To Vessel Position Or Cog
“ Page 50 ” menu. (Your Vessel’s Cur- (Course Over Ground).” ” menu. ] key to select “ (Magnetic)” or “ ” in the “Magnetic” mode. “True” mode “Magnetic” mode .” Mean- Phantom PS1000... -
Page 51: Scan Type
5. Press the [ CALL ( SET ) MENU ] key to set the beep condi- tion. 6. Press the [ 16/9 ] key to return to radio operation. Emergency alarm cannot be turned OFF. Phantom PS1000 ” menu. MEMORY ” or “... -
Page 52: Wx Alert (On/Off)
9. If you want to enter the name of another channel, repeat steps 3 through 8. 10. To exit this menu and return to radio operation mode press the [ 16/9 ] key. Page 52 ” menu. ” or “ (off).” ” menu. Phantom PS1000... -
Page 53: External Speaker Selection
”: EXT. speaker “off,” CMP25 RAM+ internal speaker “on” 5. Press the [ CALL ( SET ) MENU ] key to store the selected set- ting. 6. Press the [ 16/9 ] key to return to radio operation. Phantom PS1000 ” menu. ” or “ (off).”... -
Page 54: Maintenance
11 VDC. • Use only STANDARD HORIZON-approved accessories and replacement parts. In the unlikely event of serious problems, please contact your Dealer or our repair facility. Address and phone numbers for this facility, as well as warranty informa- tion, are contained in section “16 WARRANTY.”... -
Page 55: Troubleshooting Chart
Your position is not dis- Accessory cable. played. Setting of the GPS navigation receiver. Phantom PS1000 REMEDY a. Check the 12VDC battery connections and the fuse. b. The PWR key needs to be pressed and held to turn the radio on. -
Page 56: Channel Assignments
5. Channels normally used by recreational boaters are those that include the term “non-commercial” in the Channel Use column of the chart. Some of these are shared with other users and some are used only in certain geo- graphic regions. Page 56 Phantom PS1000... - Page 57 D 156.950 161.550 Port operation, ship movement D 157.000 161.600 Canadian Coast Guard Only, D 157.050 161.650 Port operation, ship movement D 157.100 161.700 Port operation, ship movement Phantom PS1000 VHF MARINE CHANNEL CHART CHANNEL USE 156.050 Port Operation and Commercial.
- Page 58 International: Port opertions and Ship movement 156.625 Non-commercial (Inter-ship only) 156.675 US: Port Operations, Canada: Commercial fish ing only, International: Inter-ship, Port opertions and Ship movement 156.725 US: Port Operations, Canada: Commercial fishing only, International: Inter-ship, Port opertions and Ship movement Phantom PS1000...
- Page 59 D 157.375 161.975 Public Correspondence (Marine Operator) D 157.425 162.025 Public Correspondence (ship-to-coast) The above channels are not for use of the general public in U.S. waters, unless proper authorization is given. Phantom PS1000 VHF MARINE CHANNEL CHART CHANNEL USE 156.775 Port Operations (Inter-ship only) (1W) 156.825...
- Page 60 G u a r d a n d a t Lake Mead, Nev., ship and coast stations of the N a t i o n a l P a r k S e r v i c e , U . S . Department of the Interior. Phantom PS1000...
- Page 61 16: The frequency 156.450 MHz is available for intership, ship and coast general purpose calling by noncommercial vessels, such as recreational boats and private coast stations. 17: The frequency 156.425 MHz is assigned by rule to private coast stations in Alaska for facsimile transmissions as well as voice communications. Phantom PS1000 Page 61...
-
Page 62: Warranty
In the event of a defect, malfunction or failure of the Product during the war- ranty period, STANDARD HORIZON’s liability for any breach of contract or any breach of express or implied warranties in connection with the sale of Products... - Page 63 This warranty only extends to Products sold within the 50 States of the United States of America and the District of Columbia. STANDARD HORIZON will pay all labor to repair the product and replacement parts charges incurred in providing the warranty service except where purchaser abuse or other qualifying exceptions exist.
-
Page 64: On-Line Warranty Registration
If you wish to obtain the flat rate price for out-of-war- ranty repair, you must include the information on the Owner’s Record with the unit when you return it to your Dealer or to STANDARD HORIZON. Lifetime Flat Rate Service Program: For the original Owner only, for the lifetime of the unit, STANDARD HORIZON will repair the unit to original specifications. -
Page 65: Specifications
Channel Spacing ... 25 kHz DSC Format ... RTCMSC101 NMEA Input/Output ... Output - DSC, DSE Phantom PS1000 (64 H x 160 W x 160 D mm) (50 H x 136 W x 130 D mm) pre-emphasis characteristic at 300 to 3000 Hz... - Page 66 MEMO Page 66 Phantom PS1000...
