PHANTOM Series PS2000
25 Watt VHF/FM
ITU Class D DSC Marine Transceiver
Owner's Manual
Space saving remote control design
Waterproof construction
Commercial grade ITU Class D DSC VHF
Independant Channel 70 reciever built-in for continuous DSC watch-
ing
Capable of connecting up to 2 optional enhanced RAM+ type mi-
crophones or VH-310 handsets.
2 station interncom between RAM+ or VH-310.
30W Loud Hailer with Listenback. 4 Fog Horns, Bells and Whistles
DSC Position Request and Send Functions, compatible with STAN-
DARD HORIZON GPS Chart Plotters.
Versatile User-Programmable Scanning, Programmable Scan and
Dual Watch Capability
NOAA Weather Alert Channels and Alert
One button access to Channel 16 and 9
Phantom PS2000
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PHANTOM Series PS2000 and is the answer not in the manual?

Questions and answers

Related Manuals for Standard Horizon PHANTOM Series PS2000

Summary of Contents for Standard Horizon PHANTOM Series PS2000

  • Page 1 PHANTOM Series PS2000 25 Watt VHF/FM ITU Class D DSC Marine Transceiver Owner's Manual Space saving remote control design Waterproof construction Commercial grade ITU Class D DSC VHF Independant Channel 70 reciever built-in for continuous DSC watch- Capable of connecting up to 2 optional enhanced RAM+ type mi- crophones or VH-310 handsets.

  • Page 2: Table Of Contents

    8.10 CHANGING GPS INFORMATION TO VESSEL POSITION OR COG ... 16 8.11 OPTIONAL MMB-84 FLUSH MOUNT INSTALLATION ... 17 CONTROLS AND INDICATORS ... 18 9.1 PS2000 TRANSCEIVER ... 18 9.2 OPTIONAL CMP25 RAM+ MICROPHONE ... 20 9.3 OPTIONAL VH-310 HANDSET ... 22 10 BASIC OPERATION ...
  • Page 3 13 MAINTENANCE ... 70 13.1 REPLACEMENT PARTS ... 70 13.2 FACTORY SERVICE ... 70 13.3 TROUBLESHOOTING CHART ... 71 14 CHANNEL ASSIGNMENTS ... 72 15 WARRANTY ... 78 16 SPECIFICATIONS ... 81 17 APPENDIX ... 82 Phantom PS2000 Page 3...

  • Page 4: General Information

    VHF. The Phantom PS2000 is capable of using up to 2 enhanced full function RAM+ type microphones or VH-310 Handsets which are supplied seperately.

  • Page 5: Safety / Warning Information

    PRODUCT SUPPORT INQUIRIES If you have any questions or comments regarding the use of the Phan- tom PS2000, you can visit the Marine Division of Vertex Standard Web site to send an E-Mail or contact the Product Support team at 800-767- 2450 M-F 7:00-5:00PST.

  • Page 6: Fcc Radio License Information

    5 FCC RADIO LICENSE INFORMATION STANDARD HORIZON Marine Divison of Vertex Standard radios comply with the Federal Communication Commission (FCC) requirements that regulate the Maritime Radio Service. STATION LICENSE An FCC ship station license is no longer required for any vessel traveling in U.S.

  • Page 7: Fcc Notice

    Unauthorized changes or modifications to this equipment may void com- pliance with FCC Rules. Any change or modification must be approved in writing by STANDARD HORIZON Marine Division of Vertex Standard. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 8: Getting Started

    Typically a 3 foot 3dB gain stainless steel whip is used on a sailboat mast. The longer 8 foot 6dB fiberglass whip is primarily used on power boats that require the additional gain. Page 8 Phantom PS2000...

  • Page 9: Coaxial Cable

    To get your coax cable through a fitting and into your boat’s interior, you may have to cut off the end plug and reattach it later. You can do this if you follow the directions that come with the connector. Be sure to make good soldered connections. Phantom PS2000 1/16'' 3/4'' 1 1/8''...

  • Page 10: Installation

    • allows connection to a power source and an antenna • It is recommended not to mount the antenna closer than three feet from the Phantom PS2000. Note: To insure the radio, RAM+ or VH-310 handset do not affect the compass...

  • Page 11: Cmp25 Ram+ Microphone Installation

    1. Connect the RAM+ MIC Cable to the RAM MIC CONNECTOR on the rear panel of the Phantom PS2000, then tighten the Cable Nut (See Figure 2). 2. Referring to Figure 3, make a 1.2” (30 mm) hole in the wall, then insert the RAM+ MIC Cable into this hole.

  • Page 12: Accessory Cable

    Connect to external 4 Ohm PA speaker Connect to NMEA (+) output of GPS Connect to NMEA (–) output of GPS Connect to NMEA ( + ) input of GPS No connection .” PA Speaker GPS Receiver NMEA OUT NMEA OUT NMEA IN Phantom PS2000...

  • Page 13: Connection Of Gps With Nmea Output

    For further information on interfacing /setting up your GPS. Please contact the manufacturer of the GPS receiver. • Phantom PS2000 can read NMEA-0183 version 2.0 or higher. • The NMEA supported sentences are: Input: GLL, GGA, RMC and GNS (RMC sentence is recommended)

  • Page 14: Checking Gps Connections

    After battery, GPS and the RAM+ microphone(s) have been connected, press the power switch on the Phantom PS2000 and press and hold the power key on a RAM+ mic, a small satellite icon will apper on the top right corner of the LCD display.

  • Page 15: Changing The Time Location

    5. Press the [ CALL ( SET ) MENU ] key (CMP25 RAM+ mic) or [ ENT ] key (VH- 310 Handset) to store the time offset. 6. Press the [ 16/9 ] key to return to radio operation. Phantom PS2000 Page 15...

  • Page 16: Changing Cog To True Or Magnetic

    [ ENT ] key (VH-310 Handset) to store the selected setting. 6. Press the [ 16/9 ] key to return to radio operation. Page 16 ” menu. (Magnetic)” or “ ” menu. (Your Vessel’s Cur- (Course Over Ground).” Phantom PS2000...

  • Page 17: Optional Mmb-84 Flush Mount Installation

    (see Figure 4). 5. Turn the adjusting screw to adjust the tension so that the transceiver is tight against the mounting surface. Bracket Lock-washer nut combination Figure 4. MMB-84 Flush Mount Installation Phantom PS2000 Adjusting Screw Page 17...

  • Page 18: Controls And Indicators

    9 CONTROLS AND INDICATORS This section defines each control, switch, and connector of the Phan- tom PS2000 Transceiver, CMP25 RAM+ Microphone, and VH-310 Hand- set. For detailed operating instructions refer to section “10. BASIC OP- ERATION.” 9.1 PHANTOM PS2000 TRANSCEIVER...

  • Page 19: Antenna Jack

    Power may be also turned on or off with the [ PWR ] key on the RAM+ mic or VH-310 handset. ACCESSORY CONNECTION CABLE Connects the Phantom PS2000 to a GPS and a PA speaker. See section “3. OPTION” for a list of speakers STANDARD HORIZON offers. DC INPUT CABLE Connects the radio to a DC power supply capable of delivering 6Amps at 12V DC.

  • Page 20: Optional Cmp25 Ram+ Microphone

    9. Pressing the [ 16/9 ] key reverts to the previous selected working channel. Secondary use Press and hold the [ 16/9 ] key then press the [ WX ] key to switch the USA, International or Canadian channels. Page 20 SCAN CALL Phantom PS2000...
  • Page 21 Holding down the [16/9] key while pressing the [WX] key switch the Chan- nel Group. [ DISTRESS ] KEY Used to send a DSC Distress Call. To send the distress call refer to section “11.3.1. Transmitting a DSC Distress Call.” Phantom PS2000 Page 21...

  • Page 22: Optional Vh-310 Handset

    When the VH-310 is in the cradle the speaker audio will increase so communications can be heard. [ SQL ] key Activates the squelch adjusting mode. Press this key to activate the squelch adjusting mode. Press the [ ] or [ ] key to adjust the squelch. Page 22 NOTE Phantom PS2000...
  • Page 23 When in radio mode, this key is used to directly select channel digit “1” in a channel number. Secondary use Press the [ F ] key first then press the [ 1 ( DIM )] key, access the LCD Dim- mer menu. Refer to section “12.1 LCD DIMMER” for details. Phantom PS2000 Page 23...
  • Page 24 Press the [ F ] key first then press the [ 6 ( NAV )] key, the LCD displays NAV GPS Data, Time, SOG (Speed Over Ground), and COG (Course Over Ground) when a GPS is connected to the accessory cable of the PS2000. See section “8.5 CONNECTION OF GPS WITH NMEA OUTPUT” for details.
  • Page 25 2. Press the [ 2 ( MEM )] key 3. Press and hold the [ 0 ( A )] key until “A” is shown to the right of the channel number. 4. Press the [ ENT ] key. Phantom PS2000 Page 25...

  • Page 26: Basic Operation

    2. Press and hold the [ PWR ] key on the RAM+ mic, VH-310 Handset, or on the front panel of the Phantom PS2000 until the radio turns on. 3. Press the [ SQL ] key, then press the [ ] key until the “...

  • Page 27: Transmit Time-Out Timer (Tot)

    NOAA (National Oceanic and Atmospheric Administration) sends a weather alert accompanied by a 1050 Hz tone and subsequent weather report on one of the NOAA weather channels. When the Weather Alert feature is enabled (see Phantom PS2000 NOTE NOTE...

  • Page 28: Noaa Weather Alert Testing

    10.6.2 NOAA Weather Alert Testing NOAA tests the alert system ever Wednesday between 11AM and 1PM. To test the Phantom PS2000’s NOAA Weather feature, on Wednesday between 11AM and 1PM, setup as in previous section and confirm the alert is heard.

  • Page 29: Calling Another Vessel (Channel 16 Or 9)

    Call Sign with each transmission, only at the begin- ning and end of the contact. Remember to return to Channel 16 when not using another channel. Some radios automatically monitor Channel 16 even when set to other channels or when scanning. Phantom PS2000 Page 29...

  • Page 30: Making Telephone Calls

    The Phantom PS2000 will scan between Priority channel and the channel that was selected in step 2. If a transmis- sion is received on the channel selected in step 2, the Phantom PS2000 will dual watch between the working channel and the Priority channel.

  • Page 31: Scanning

    [ F ] key, followed by the [ 2 ( MEM )] key on the VH-310 Handset. “MEM” will appear on the LCD which indicates the channel has been programmed into the transceivers memory. 3. Repeat step 2 for all the desired channels to be scanned. Phantom PS2000 ” menu appears. ” menu. PRIORITY PRIORITY ”...

  • Page 32: Priority Scanning P-Scan

    You may change the scan resume time by the Radio Setup Mode, refer to section “12.9 SCAN RESUME TIME.” Page 32 M-SCAN ” appears on the LCD. Scan- P-SCAN ” appears on the LCD). Scan- MEM CH. CH. 16 ] key, then MEM CH. CH. 16 Phantom PS2000...

  • Page 33: Pa/Fog Operation

    HAIL/PA speaker which provides two-way communications through the HAIL/ PA speaker. When in PA or FOG mode the PS2000 will receive the last selected VHF channel before entering into the PA or FOG mode and receive DSC calls. PA HAIL mode:...

  • Page 34: Operating The Pa Fog Horn Mode

    HAIL/PA speaker. 5. On the “Horn” and “Siren” modes, Listen-back the Page 34 PUBLIC ” menu, then press ] key to select the one of the ] key to select the one of the Phantom PS2000...

  • Page 35: Navigation Indication

    You may display the COG (Course Over Ground) data in the LCD instead of your vessel position (LAT/LOG) by the Radio Setup Mode, refer to section “12.5 CHANGING GPS INFORMATION TO VESSEL POSITION OR COG.” Phantom PS2000 ( Time ) ( Latitude )

  • Page 36: Intercom Operation

    “ On the VH-310 Handset, press the [ F ] key, followed by the [ 5 ( IC )] key. The Phantom PS2000 is changed to “INTERCOM” mode from the “Radio” operation mode. 2. Press the PTT switch. “...

  • Page 37: Digital Selective Calling

    20 nautical miles. A DSC Warning sticker is included with the Phantom PS2000. To com- ply with FCC regulations this sticker must be mounted in a location that can...

  • Page 38: Maritime Mobile Service Identity (Mmsi)

    Digital Selective Calling (DSC). This number is used like a telephone number to selectively call other vessels. THIS NUMBER MUST BE PROGRAMMED INTO THE RADIO TO OPERATE THE PHANTOM PS2000 DSC FUCTIONS. How can I obtain an MMSI assignment? Boat US offers online registration of a MMSI. Visit www.boatus.com/mmsi 11.2.2 Programming the MMSI...

  • Page 39: Dsc Distress Call

    11.3 DSC DISTRESS CALL The Phantom PS2000 is capable of transmitting and receiving DSC Distress messages to all DSC radios. The Phantom PS2000 may be connected to a GPS to also transmit the Latitude, Longitude of the vessel in a distress.
  • Page 40 8. To cancel the DSC distress alarm signal from the speaker, press any key. Transmitting a DSC Distress Call with Nature of Distress The Phantom PS2000 is capable of transmitting a DSC Distress Call with the following “Nature of Distress” categories:...

  • Page 41: Receiving A Dsc Distress Call

    Cancel a DSC Distress Call If a DSC Distress call was sent by error the Phantom PS2000 allows you to send a message to other vessels to cancel the Distress Call that was made in error. 1. Press the [ 16/9 ] key.

  • Page 42: All Ships Call

    3. Press the [ ] or [ ] key to select the call type (“ GENCY ” or “ SAFETY 4. Press the [ ENT ] key to transmit the selected type of Page 42 ALL SHIPS ”). ALL SHIPS ”). ” menu, ” menu, Phantom PS2000...

  • Page 43: Receiving An All Ships Call

    3. Press the [ ] or [ vessel transmitting the All Ships Call. 4. Monitor channel 16 or traffic channel until the UR- GENCY voice communication is completed. Phantom PS2000 ] key to see the MMSI of the Page 43...

  • Page 44: Individual Call

    11.5.1 Setting up the Individual / Position Call Directory The Phantom PS2000 has a DSC directory that allows you to store a vessel or person’s name and the MMSI number associated with vessels you wish to transmit Individual calls, Position Requests and Position Send transmissions.
  • Page 45 11. Press and hold the [ ENT ] key to store the individual address. 12. To enter another individual address, repeat steps 5 through 13. To exit this menu and return to radio operation mode press the [ 16/9 ] key. Phantom PS2000 DSC SETUP ” menu, INDIVIDUAL DIR ”...

  • Page 46: Setting Up Individual Reply

    6. To exit this menu and return to radio operation mode press the [ 16/9 ] key. Page 46 ” menu appears. DSC SETUP ” menu, INDIVIDUAL RE- ( Automatic ) ” DSC SETUP ” menu, INDIVIDUAL RE- ( Automatic ) ” Phantom PS2000...

  • Page 47: Setting Up Individual / Group Call Ringer

    : 5 times 5. Press the [ ENT ] key to store the selected setting. 6. To exit this menu and return to radio operation mode press the [ 16/9 ] key. Phantom PS2000 ” menu appears. DSC SETUP ” menu, ] key to select “...
  • Page 48 The Phantom PS2000 has the capability to turn off the Individual or Group call ringer. CMP25 RAM+ mic: 1. Press and hold down the [ CALL ( SET ) MENU ] key until “ RADIO SETUP 2. Press the [ ] key to select “...

  • Page 49: Transmitting An Individual Call

    3. Press the [ ] or [ ] key to select the “Individual” you want to contact. 4. Press the [ CALL ( SET ) MENU ] key to transmit the individual DSC signal. Phantom PS2000 ] key to select “ INDIVIDUAL NO REPLY ”...

  • Page 50: Receiving An Individual Call

    VH-310 Handset to transmit the individual DSC signal. Page 50 NO REPLY RECEIVED INDI- ] key to see the MMSI of the RECEIVED INDI- ABLE ” or “ UNABLE ] key, then press the ” will ” Phantom PS2000...

  • Page 51: Setting Up The Call Waiting Function

    11.5.6 Setting Up the Call Waiting Function Allows the Phantom PS2000 to be setup to reply (ABLE) or set the radio so it transmits a call that advises the calling vessel the person is UNABLE to reply to the call at this time.

  • Page 52: Group Call

    If a mistake was made entering in the num- ber, press the [ H/L ] key to delete the wrong digit. Page 52 ” menu appears. DSC SETUP ” menu, ] key to select “ GROUP DIR .” ” Phantom PS2000...
  • Page 53 11 Press and hold the [ ENT ] key to store the group address. 12. To enter another group address, repeat steps 5 through 10. 13. To exit this menu and return to radio operation mode press the [ 16/9 ] key. Phantom PS2000 DSC SETUP ” menu, ] key to select “...

  • Page 54: Transmitting A Group Call

    6. Listen to the channel to make sure it is not busy, then key the microphone and call the other vessels you desire to com- municate with. Page 54 GROUP ” menu, GROUP ” menu, Phantom PS2000...

  • Page 55: Receiving A Group Call

    Phantom PS2000. Standard Horizon has taken this feature one step further, if any Stan- dard Horizon GPS is connected to the Phantom PS2000, the polled position of the vessel is shown on the display of the GPS chart plotter making it easy to navigate to the location of the polled vessel.
  • Page 56 6. To exit this menu and return to radio operation mode press the [ 16/9 ] key. Page 56 ” menu appears. DSC SETUP ” menu, POS REQUEST ” or “ DSC SETUP ” menu, POS REQUEST ” or “ ” .” ” .” Phantom PS2000...
  • Page 57 The PS2000 has the capability to turn off the Position Request ringer. CMP25 RAM+ mic: 1. Press and hold down the [ CALL ( SET ) MENU ] key until “ RADIO SETUP 2. Press the [ ] key to select “...

  • Page 58: Transmitting A Position Request To Another Vessel

    LCD. 7. Press the [ ] or [ ] key to see the name and posi- tion (LAT/LOG) of the vessel polled vessel. 8. If the Phantom PS2000 does not receive a reply, the NO REPLY LCD will display “...

  • Page 59: Receiving A Position Request

    RAM+ or VH-310 handset. 7. Press the [ ] or [ ] key to see the name and posi- tion (LAT/LOG) of the vessel polled vessel. 8. If the Phantom PS2000 does not receive a reply, the LCD will display “ SEND and select “...

  • Page 60: Position Send

    Phantom PS2000 to send the position. 11.8.1 Setting up a Position Send Ringer The PS2000 has the capability to turn off the Position Send ringer. CMP25 RAM+ mic: 1. Press and hold down the [ CALL ( SET ) MENU ] key until “...

  • Page 61: Transmitting A Dsc Position Send Call

    4. Press the [ ENT ] key to send your position to the se- lected vessel. 11.8.3 Receiving a DSC Position Send Call When another vessel transmits their vessels location to the PS2000 the follow- ing will happen: 1. When the Position Send Call is received, “...

  • Page 62: Radio Setup Mode

    5. Press the [ CALL ( SET ) MENU ] key (CMP25 RAM+ mic) or [ ENT ] key (VH- 310 Handset) to store the selected level. 6. Press the [ 16/9 ] key to return to radio operation. Page 62 ” menu. (off)” to “ .” (off)” to “ .” ” menu. ” to “ .” Phantom PS2000...

  • Page 63: Time Offset

    5. Press the [ CALL ( SET ) MENU ] key (CMP25 RAM+ mic) or [ ENT ] key (VH- 310 Handset) to store the time offset. 6. Press the [ 16/9 ] key to return to radio operation. Phantom PS2000 Page 63...

  • Page 64: Time Location

    [ ENT ] key (VH-310 Handset) to store the selected setting. 6. Press the [ 16/9 ] key to return to radio operation. Page 64 ” menu. (local time)” or “ ” menu. (Your Vessel’s Cur- (Course Over Ground).” Phantom PS2000...

  • Page 65: Changing Cog To True Or Magnetic

    5. Press the [ CALL ( SET ) MENU ] key (CMP25 RAM+ mic) or [ ENT ] key (VH-310 Handset) to store the selected setting. 6. Press the [ 16/9 ] key to return to radio operation. Phantom PS2000 ” menu. ] key to select “...

  • Page 66: Scan Type

    6. Press the [ 16/9 ] key to return to radio operation. 12.9 SCAN RESUME TIME This selection is used to select the time the PS2000 waits after a transmission ends before starting scanning. 1. Press and hold down the [ CALL ( SET ) MENU ] key (CMP25...

  • Page 67: Key Beep (On/Off)

    5. Press the [ CALL ( SET ) MENU ] key (CMP25 RAM+ mic) or [ ENT ] key (VH- 310 Handset) to store the selected setting. 6. Press the [ 16/9 ] key to return to radio operation. Phantom PS2000 ” menu. ” or “...

  • Page 68: Channel Name Change

    (VH-310 Handset) to store the new name. 9. If you want to enter the name of another channel, repeat steps 3 through 8. 10. To exit this menu and return to radio operation mode press the [ 16/9 ] key. Page 68 ” menu. Phantom PS2000...

  • Page 69: Fog Alert Tone Frequency

    5. Press the [ CALL ( SET ) MENU ] key (CMP25 RAM+ mic) or [ ENT ] key (VH- 310 Handset) to store the selected setting. 6. Press the [ 16/9 ] key to return to radio operation. Phantom PS2000 ” menu. ” menu.

  • Page 70: Maintenance

    11 VDC. • Use only STANDARD HORIZON-approved accessories and replacement parts. In the unlikely event of serious problems, please contact your Dealer or our repair facility. Address and phone numbers for this facility, as well as warranty informa- tion, are contained in section “16 WARRANTY.”...

  • Page 71: Troubleshooting Chart

    Your position is not dis- Accessory cable. played. Setting of the GPS navigation receiver. Phantom PS2000 REMEDY a. Check the 12VDC battery connections and the fuse. b. The PWR key needs to be pressed and held to turn the radio on.

  • Page 72: Channel Assignments

    5. Channels normally used by recreational boaters are those that include the term “non-commercial” in the Channel Use column of the chart. Some of these are shared with other users and some are used only in certain geo- graphic regions. Page 72 Phantom PS2000...
  • Page 73 D 156.950 161.550 Port operation, ship movement D 157.000 161.600 Canadian Coast Guard Only, D 157.050 161.650 Port operation, ship movement D 157.100 161.700 Port operation, ship movement Phantom PS2000 VHF MARINE CHANNEL CHART CHANNEL USE 156.050 Port Operation and Commercial.
  • Page 74 International: Port opertions and Ship movement 156.625 Non-commercial (Inter-ship only) 156.675 US: Port Operations, Canada: Commercial fish ing only, International: Inter-ship, Port opertions and Ship movement 156.725 US: Port Operations, Canada: Commercial fishing only, International: Inter-ship, Port opertions and Ship movement Phantom PS2000...
  • Page 75 D 157.375 161.975 Public Correspondence (Marine Operator) D 157.425 162.025 Public Correspondence (ship-to-coast) The above channels are not for use of the general public in U.S. waters, unless proper authorization is given. Phantom PS2000 VHF MARINE CHANNEL CHART CHANNEL USE 156.775 Port Operations (Inter-ship only) (1W) 156.825...
  • Page 76 G u a r d a n d a t Lake Mead, Nev., ship and coast stations of the N a t i o n a l P a r k S e r v i c e , U . S . Department of the Interior. Phantom PS2000...
  • Page 77 16: The frequency 156.450 MHz is available for intership, ship and coast general purpose calling by noncommercial vessels, such as recreational boats and private coast stations. 17: The frequency 156.425 MHz is assigned by rule to private coast stations in Alaska for facsimile transmissions as well as voice communications. Phantom PS2000 Page 77...

  • Page 78: Warranty

    In the event of a defect, malfunction or failure of the Product during the war- ranty period, STANDARD HORIZON’s liability for any breach of contract or any breach of express or implied warranties in connection with the sale of Products...
  • Page 79 This warranty only extends to Products sold within the 50 States of the United States of America and the District of Columbia. STANDARD HORIZON will pay all labor to repair the product and replacement parts charges incurred in providing the warranty service except where purchaser abuse or other qualifying exceptions exist.

  • Page 80: On-Line Warranty Registration

    Please visit PS2000 Marine VHF. It should be noted that visiting the Web site from time to time may be beneficial to you, as new products are released they will appear on the STANDARD HORIZON Web site. Also a statement regarding product support should be added to the manual.

  • Page 81: Specifications

    16.4 PUBLIC ADDRESS / FOG Impedance ... 4 Ohms Power Output ... 30 Watts max Phantom PS2000 (90 H x 230 W x 150 D mm) (69 H x 169 W x 130 D mm) pre-emphasis characteristic at 300 to 3000 Hz...

  • Page 82: Appendix

    (un- derway or at anchor), or a vessel towing or pushing an- other ahead. Vessel under tow (manned). Vessel is aground. Vessel is at anchor. Phantom PS2000...
  • Page 83 MEMO Phantom PS2000 Page 83...
  • Page 84 Marine Division of VERTEX STANDARD US Headquarters 10900 Walker Street, Cypress, CA 90630, U.S.A. www.standardhorizon.com Page 84 Copyright 2005 VERTEX STANDARD CO., LTD. All rights reserved. No portion of this manual may be reproduced without the permission of VERTEX STANDARD CO., LTD. Phantom PS2000...
