U-Line H-3934 Manual

H-3934, H-3935
ELECTRIC LIFT TABLE
SPECIFICATIONS
Weight Capacity
Min. Table Height
Max. Table Height
Travel
Platform Width
Platform Length
Base Frame Width
Base Frame Length
Weight
Sound Pressure Level
Operating Environment
WARNING! Do not operate this lift table unless
you have been trained to use it, authorized
to do so and have checked that it is in good
condition. The operator should read all of the
warning signs and instructions here and on the
lift table before using it.
• DO NOT concentrate the load at one point on the
platform or pallet. ALWAYS uniformly distribute each
layer of load over the supporting surface.
• DO NOT use the lift for any purpose other than its
intended use.
• DO NOT install the lift table on an unlevel or soft
surface. The lift base frame must be supported
along its entire length and width. Failure to
completely support the base frame could result in
damage to the lift.
• DO NOT use the lift table with an unstable,
unbalanced or loosely stacked load. Unbalanced
loads may become unstable and fall. SEVERE
PERSONAL INJURY and PROPERTY DAMAGE may
result.
PAGE 1 OF 21
1-800-295-5510
uline.com
TECHNICAL INFORMATION
H-3934 H-3935
2,000 lbs. 2,000 lbs.
8⁄" 8⁄"
38⁄" 38⁄"
30" 30"
28" 36"
48" 48"
24⁄" 24⁄"
49" 49"
402 lbs. 416 lbs.
<70dB(a) <70dB(a)
Indoors Indoors
SAFETY
• DO NOT overload the lift table. ALWAYS stay within
• SHEARING HAZARD. ALWAYS keep hands and feet
• CRUSHING HAZARD. ALWAYS keep hands and feet
• PINCH POINT HAZARD. ALWAYS keep feet, hands and
• DO NOT change the relief valve setting. The relief
Pour le français, consulter les pages 15-21.
Platform Length
Base Length
the designated capacity ratings. SEVERE PERSONAL
INJURY and PROPERTY DAMAGE could result.
clear of the scissor mechanism and all moving
components. DO NOT put hands or fingers under
the platform when in use. SEVERE PERSONAL INJURY
could result.
clear of all moving components. DO NOT put feet
on the base frame when in use. SEVERE PERSONAL
INJURY could result.
fingers away from the underside of the platform
and all moving components. SEVERE PERSONAL
INJURY could result.
valve is installed to protect the operator and the
lift table. Changing the relief valve setting may
compromise the performance and safety of the lift.
SEVERE PERSONAL INJURY and PROPERTY DAMAGE
could result.
Para Español, vea páginas 8-14.
Platform
Width
Base
Width
Travel
Raised
Height
Lowered
Height
0525 IH-3934
