- Page 1 Installation Guide Model: DL30 Series Lock Body: American Standard Single Latch Version: 2.0 Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between the actual product and the written information in this manual.
-
Page 2: Table Of Contents
Important Notes Please read this Installation Guide carefully or contact the Customer Care for any queries regarding installation. Installation is recommended to be performed by a professional to avoid any additional service charges that may cause due to improper product installation. We constantly revise the contents of this Installation Guide and update our products to improve the quality and performance without any prior notice. -
Page 3: What's In The Box
What's in the Box Mounting Plate Outdoor Unit Indoor Unit Gasket Keys Latch Strike Plate and Box MF Cards Hex wrench Screw A Screw B Screw C Screw D Spindle Spindle Spindle B Door Thickness Screw C 30 to 38 mm 56 mm 20 mm 25 mm... -
Page 4: Installation Diagram
Installation Diagram Outdoor Unit Keys Gasket Door Gasket Mounting Spindle Plate Latch Indoor Unit Screw A Battery (not included) Screw C Screw B Strike Plate and Box Screw D Battery Cover Installation Procedure Door Properties Measure the door thickness Measure the door thickness and select the proper Spindle and Screw length. For details, please refer to the table contents of Page 1. - Page 5 Latch StrikePlate StrikePlate Latch Right Inward Left Inward Latch StrikePlate StrikePlate Latch Left Outward Right Outward User Location Change the handle direction (if needed) Use the hex wrench to remove the screw of handle. Take the handle out from the lock. Change the handle direction and replace.
-
Page 6: Drilling Holes On The Door
Drilling Holes on the Door Place the Installation Template at the desired handle height. Mark for the holes to be drilled and drill the marked places. Center line of handle Desired handle height Installing Latch Adjust the backset of the lock. (if needed) Secure the Latch with the Screw A. -
Page 7: Installing Outdoor Unit
Installing Outdoor Unit Attach the Gasket to the Outdoor Unit. Insert Spindle into the clutch. Make sure the triangle mark points towards the door opening direction. Attach the Outdoor unit to the door by inserting the cable through the drilled holes. Clutch c orrect p osition: T he triangle must be vertically centered. -
Page 8: Installing Indoor Unit
Installing Indoor Unit Connect the cable to the port on the Indoor Unit. Place the Indoor Unit properly on the Mounting Plate. Then use Screw C & Screw D to secure the Indoor Unit. Screws Note: Push the excess cable into the hole. Installing Battery and Cover Insert four Alkaline AA batteries and cover them with a battery cover. -
Page 9: Installing Strike Plate And Box
Installing Strike Plate and Box Make sure that the Strike Box is aligned with the latch bolt. Then, use the Installation Template to drill holes. Align the Strike Plate and Box with the drilled holes and secure them with Screw A. Screws A (5/64") depth... - Page 10 Warning: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
