  • Page 1: Table Of Contents

    _Steam locomotive BR50.0____ with 2‘2‘T26 Digital technology Index 1. Introduction page 2 2. Installation of decoder, speaker- and electrical couplers 2.1 Decoder installation page 3 2.2 Sound installation page 4 2.3 Installation of electrical couplers page 6 3. Function output mapping page 7 3.1 NEXT18 –...
  • Page 2: Introduction

    _Steam locomotive BR50.0____ with 2‘2‘T26 1. Introduction Congratulations for the purchase of a TILLIG quality modell. We are giving you all the information you need to convert your loco to digital and adjust all the features, as you want. • Driving direction-dependent front light •...
  • Page 3: Installation Of Decoder, Speaker- And Electrical Couplers

    _Steam locomotive BR50.0____ with 2‘2‘T26 2. Installation of decoder, speaker- and electrical couplers 2.1 Decoder installation The decoder will be installed at the tender. Step 1: The first thing you need to do is remove the coal insert of the tender. This is locked and only needs to be removed.
  • Page 4: Sound Installation

    _Steam locomotive BR50.0____ with 2‘2‘T26 2.2 Speaker installation There is a Micro-SUSI interface on the locomotive's connecting circuit board. This is used to connect a SUSI sound module. This can be installed in our speaker box item no. 66055. For example, the Uhlenbrock IntelliSound 6-micro module 32610 fits in.
  • Page 5 _Steam locomotive BR50.0____ with 2‘2‘T26 Step 4: The last dismantling step is to remove runaround with kinematic including spring. Note: The spring is slightly preloaded and can jump away. Please proceed with caution. Step 5: Now the sound module with speaker can be installed.
  • Page 6: Installation Of Electrical Couplers

    _Steam locomotive BR50.0____ with 2‘2‘T26 2.3 Installation of electrical couplers The tender is prepared for the installation of a digital coupling. For installation, the top part must be removed to expose the solder pads. Step 1: The top part is fixed with the tread in the tender end wall and the toolbox.
  • Page 7: Function Output Mapping

    _Steam locomotive BR50.0____ with 2‘2‘T26 3. Function output mapping When using a third-party NEXT18 decoder, the function key assignment and the SUSI communication must be programmed by yourself (see 3.1.2). If you use a diffrent NEXT18 decoder of your own choice, you will have to program the function button mapping (assignement) and turn on the SUSI interface bus by yourself.
  • Page 8: Ecu (Electronic Controll Unit / Slave Decoder)

    _Steam locomotive BR50.0____ with 2‘2‘T26 3.2 ECU (Electronic Controll Unit / slave decoder) Some functions are controlled by the ECU, which is a function decoder integrated on the locomotive main circuit board. The ECU is communicating with the Next18 decoder on the standard SUSI bus on the AUX3 and AUX4 outputs of the decoder.
  • Page 9: Ecu Function Button Attribution

    _Steam locomotive BR50.0____ with 2‘2‘T26 3.2.2 ECU function button attribution light sitch-off 1 shunting light down right AUX8 AUX9 AUX10 AUX11 Electical coupling (driving direction-dependent) AUX14 (not available) HW01SW01 04.02.2025...
  • Page 10: Ecu Cv - Programming

    _Steam locomotive BR50.0____ with 2‘2‘T26 4. ECU CV – programming According to the SUSI standard (RCN-600) the CV-s (Configuration Variables) of the ECU are organized in groups of 40 CVs. The 40 CVs are addressable in one Bank. The Bank contains the group of 40 CVs present 3 times numerated continuously.
  • Page 11: Function Mapping (Aspects)

    _Steam locomotive BR50.0____ with 2‘2‘T26 4.1 Function mapping (Aspects) The F0-F28 function buttons mapping to the outputs AUX7-14 is made in a double level scheme. The group of outputs is controlled in the same time by a function is called Aspect. The ECU has a total 8 configurable Aspects.
  • Page 12: Default Factory Configured Aspect Overview

    _Steam locomotive BR50.0____ with 2‘2‘T26 4.1.4 Default factory configured Aspect overview Aspect1: F5 controls AUX9. for Driving direction FWD AUX7-14 „AUX9“ defined in CV1004.0=4 AUX7-14 for Driving direction BWD „AUX9“ defined in CV1005.0=4 Function button „F5“ defined in CV995.0=5 Aspect2: F6 controls AUX10.
  • Page 13: Example Of Function Mapping Settings

    _Steam locomotive BR50.0____ with 2‘2‘T26 4.1.5 Example of function mapping settings To configure Function F9 to turn on AUX9 together with AUX11 in forward direction, and AUX10 together with AUX14 in reverse direction using Aspect8 (available for user configuration) the following is to be done: Write in CV1002.0 the value 9 - this means that the Function F9 will control the Aspect8.
  • Page 14: Electrical Couplers (Aux12/13)

    _Steam locomotive BR50.0____ with 2‘2‘T26 4.3 Electrical Couplers (AUX12/13) 4.3.1 Programming The special outputs dedicated for the usage of electrical couplers (AUX12/AUX13) are accessible to the user as solder pads (AUX12 in the front, AUX13 in the rear). The operation of these outputs requires special settings.
  • Page 15: Spp Installation

    _Steam locomotive BR50.0____ with 2‘2‘T26 4.4 SPP installation Sadly it was not successful to integrate an SPP at this loco. But if you find a place to assemble one, you’ll find the needed solder pads (VCC, GND and SPP) at the decoder pcb. The operating is using the ECU like at the integrated SPP.
  • Page 16: Cv Table

    _Steam locomotive BR50.0____ with 2‘2‘T26 4.7 CV table In the table on the following pages are listed all the CV’s of the ECU. The CV’s are divided into 3 columns, one for each slave address (see also: Introduction Chapter 4). The CV’s relevant to you are marked in bold.
  • Page 17 _Steam locomotive BR50.0____ with 2‘2‘T26 904.0 944.0 984.0 1-127 Time for Fade Out Effect in 8ms Steps 904.1 944.1 984.1 0-255 Time of Turn Off Delay in 8ms Steps 984.2 0-255 Outputs Turn Off Delay (AUX7-14) 904.2 944.2 bit0 – AUX7… bit7 – AUX14 (see 4.1.1) Bit Value = 0, instant Turn Off Bit Value = 1, Turn Off Delay is used 905.0...
  • Page 18 _Steam locomotive BR50.0____ with 2‘2‘T26 921.0 961.0 1001.0 0-63 Function button which is mapped at Aspect 7 921.1 961.1 1001.1 reserved 921.2 961.2 1001.2 reserved 922.0 962.0 1002.0 0-63 Function button which is mapped at Aspect 8 922.1 962.1 1002.1 reserved 922.2 962.2...
  • Page 19 _Steam locomotive BR50.0____ with 2‘2‘T26 937.0 977.0 1017.0 0-255 Output Aspect 7 (AUX7-14), backward (see 4.1.1) 937.1 977.1 1017.1 reserved 937.2 977.2 1017.2 0-255 Buffering time SPP turn off delay, after losing track power 938.0 978.0 1018.0 0-255 Output Aspect 8 (AUX7-14), forward (see 4.1.1) 938.1 978.1...
