Honeywell FF-SPS4 Series Manual

Type 4 self-contained single beam
For access control
FEATURES
• Meets applicable parts of US OSHA
1910.212, ANSI B11.19 and RIA 15.06
for Control Reliability
• Active optoelectronic protective
equipment, Type 4 according to the
norm IEC/EN 61496 - parts 1 & 2
• Protection against mutual interference
by selection of the emission frequency
• Through scan device with permanent
self-checking ensuring the highest level
of safety
• Power supplies: 120 Vac, 240 Vac and
24 Vdc
• Response time: 0.020 sec
• Scanning range:
0.5 to 40 m / 1.6 to 131.2 ft (standard)
0.5 to 20 m / 1.6 to 65.6 ft (lens heating)
30 to 75 m / 98.4 to 246 ft (long range)
• Beam aperture angle: ±2° in compliance
with the norm IEC/EN 61496 - 2
• Connection: terminal strips or
connectors
• Outputs: 2 safety relays with guided
contacts
• Sealing: IP 67/NEMA 6 (terminal) or
IP 65/NEMA 4 (connector)
• Available restart modes:
. automatic restart
. start interlock (at power up only)
. start & restart interlock (at power up
and after any beam interruption)
• Final Switching Devices monitoring input
• Test input
• Numerous LED status indicators
• Accessories: individual and adjustable
beam deflection mirror, floor mounting
deflection mirrors for 2, 3 or 4 beams
• Alignment aid kit: compact and self-
contained laser pen, signal margin LED
indicator
APPLICATIONS
Access control: perimetric protection
around a robot zone, trip device at the
entrance and the exit of a paint shop, etc.
FF-SPS4 Series
®
NRTL/C
The FF-SPS4 Active Optoelectronic Protective Device is a single through scan infra-
red beam designed to detect the body of an operator on approach to a dangerous
zone.
The interruption of the beam de-energizes the output contacts which in turn de-
energizes the machine stop circuitry.
The emission source is modulated infrared which makes the operation almost com-
pletely independent of ambient light conditions. Moreover, the device is equipped
with an emission frequency selector to avoid possible mutual interference between
sets.
The processing is a permanent dynamic self-checking principle meeting the require-
ments of the norm IEC/EN 61496 - parts 1 & 2 for Type 4 Electrosensitive Protective
Equipment. Any internal failure will be immediately detected and disable the output
relays.
The Canadian CSA (NRTL/C) gave an approval to this device which meets applicable
parts of US ANSI, RIA 15.06 standards and OSHA 29 CFR and 1910.212 regulations
for Control Reliability.
The FF-SPS4 is preset with the start and restart interlock mode on delivery. The start
and restart interlock guarantees that the equipment remains in alarm at power up or
after an interruption of the beam. The operator must press a push-button to restart
the protective equipment. However, an automatic restart can be easily programmed
by internal switches.
!
WARNING
MISUSE OF DOCUMENTATION
• The information presented in this product sheet (or catalogue) is for reference only. DO NOT USE this document as system
installation information.
• Complete installation, operation and maintenance information is provided in the instructions supplied with each product.
Failure to comply with these instructions could result in death or serious injury.
