CORNING LANscape Solutions TKT-UNICAM Quick Start Manual

• Refer to Installation Guide 006-150 for complete instructions.
• Visit www.corning.com/cablesystems/unicam for additional information.
• Visit www.corning.com/cablesystems/safety for full safety precautions.
Crimp handle
Slider - supports front of connector.
Selectable positions: CTS or non-CTS.
TPA-2655
Slider handle -
Pull back to allow connector to be
inserted into wrench. Use to change
slider from CTS to non-CTS position.
Date
Code
Cam
Key
SC
TPA-2652
Non-CTS
ST Compatible
TPA-2632
STANDARD RECOMMENDED PROCEDURE 006-150-QSG | ISSUE 1 | July 2010 | PAGE 1 OF 4
Wrench handle - turns wrench that
rotates connector cam to align fibers.
Crimp platform - supports back of connector. Critical
to position connector in crimp platform correctly.
Index rollers - hold fibers during insertion into
connector. Provide pressure to keep
fiber stubs butted during cam step.
Release button - opens index rollers when loading
or unloading fiber.
Tool and Connector Preparation
Latch
Central
Groove
Cam
Key
LC
"UP" label on
load adapter
ST
®
Compatible
LC SC
TKT-uNICAM Quick
Start Guide for
900 Micron Fiber Only
p/n 006-150-QSG, Issue 1
Non-CTS
CTS TPA-2654
TPA-2653
CTS
LC
TPA-2631
NOTE:
TPA-2633
1. SC Coupler
2. ST Compatible Coupler
®
3. LC Coupler
4. Installation Tool (TL-UC01)
5. ST Compatible-LC Jumper
6. VFL-350
3
5
6
LC
LC
NOTE: leave black load adapters
on for non-CTS installations.
ST Compatible
ST Compatible
TPA-2633
ST Compatible
Make sure SC coupler is connected to the
TPA-2633
jumper prior to plugging in the uniCam
SC
1
2
4
KPA-0921
SC
SC
.
®
