SRP-004-067 Installation Guide for SST-Drop Cables
1.

General

This document describes the use of the SST-Drop Cable Access Tool, Corning Cable Systems
catalog part number FDST-000 (Figure 1).
2.

Carton Contents

• SST-Drop Cable Access Tool
• Spare blade set
3.

Tools and Materials

• Tape measure
• Electrical tape
• Phillips-head screwdriver
• Cable knife (for toneable cables only)
• Scissors
4.

Cable-end Access

Step 1: Measure the strip length required for your
application, marking the length with a wrap
of electrical tape.
Step 2: If applicable, separate the toning wire from
the cable as described in SRP-004-067,
section 6 (Figure 2). Remove any web
remnants on the optical cable jacket as
described in that procedure.
STANDARD RECOMMENDED PROCEDURE 005-066 | ISSUE 4 | JULY 2010 | PAGE 1 OF 4
CAUTION: This tool contains sharp blades. Use caution when using the tool and
when replacing its blades. The use of safety gloves is recommended. Properly
dispose of used blades.
Access Tool for SST-Drop™
Cables
p/n 005-066, Issue 4
Figure 2 — Toning wire removal
KPA-2455
Figure 1 — FDST-000
KPA-2456
