CORNING Gold 000301T4180002M Quick Manual

Corning Cable Systems
Corning Cable Systems
Fiber Optic Cable Assembly
When
Performance
Counts
Corning recommends cleaning both single and
multi- ber connectors with the Universal Connector
Cleaning Cassette (p/n 2104359-01). Follow the
instructions in Corning Cable Systems SRP-006-093
and check the results with an inspection microscope.
Corning Cable Systems recommends using this
procedure every time a connector is unmated.
For customer support and service, call
1-800-743-2671 in Canada/USA
Freephone: 00800 26764641 in Austria/Belgium
France/Germany/Ireland/ Italy/Luxembourg
Netherlands/Spain/Switzerland/United Kingdom
+49 30 5303 2224 in Czech/Estonia/Hungary/Poland
Slovakia
+49 30 5303 2214 in Denmark/Iceland/Finland
Norway/Sweden
+49 30 5303 2244 in Cyprus/Greece/Malta/Portugal
Slovenia
Corning Cable Systems LLC
Box 489
Hickory, NC 28603-0489 USA
GOLD
GOLD
Connector Cleaning and Care
Step 1:
MT-RJ with pins
MT-RJ (pin-less), FC, SC,
LC, MTP (pin-less), D4
ST-®compatible
MTP with pins
Remove the connector's dust cap and make two passes on the appropriate area
of the cassette cleaning strip.
Step 3:
Step 2:
Always keep a clean dust cap on unused
Check the connector
connectors. Do not allow the connector
endface with the microscope. Repeat
endface to come in contact with the inside
Step 1 if necessary. If a connector still shows
of the dust cap.
contaminants after repeating Step 1, refer to
Section 5 of SRP-006-094.
™
™
MT-RJ
With
Pins
Pin-
less
Corning Cable Systems
SRP-006-056
Issue 9 August 2010
Page 1 of 2
