revision history |
Issue
Date
1
February 2009
Related literature |
SRP-005-065 Corning Cable Systems ClearCurve™ Rugged/Compact Drop Cable
Handling Practices
Precautions |
CAUTION: Use care when using scissors to avoid personal injury. The use of safety gloves
and safety glasses is recommended.
WARNING: Laser light can damage your eyes. Laser light is invisible. Viewing it directly
does not cause pain. The iris of the eye will not close involuntarily as when viewing a
bright light. Consequently, serious damage to the retina of the eye is possible. NEVER
LOOK INTO A FIBER WHICH MAY HAVE A LASER COUPLED TO IT.
Should accidental eye exposure to laser light be suspected, arrange for an eye
examination immediately.
1.
General
This procedure describes a general method for the ClearCurve Drop Cable Pulling Grip Kit
(TKT-CCPG) and its use with both ClearCurve Rugged Drop cable assemblies and ClearCurve
Compact Drop cable assemblies. This pulling grip kit is for use only with the ClearCurve Drop
cable assembly and not a regular single fiber cable assembly. ClearCurve Drop cable construction
is different than regular jumper cable construction and allows for the use of this pulling grip kit.
As with any fiber optic cable installation, proper planning is of paramount importance. Fiber optic
cable installers must always follow the four basic cable placement considerations. First, ensure
there is sufficient slack in the system. Second, monitor the tension and be sure when using the
pulling grip kit to install ClearCurve assemblies to not exceed 50 lbs of tension. Third, do not
exceed the bend radius and refer to the specification sheet or contact Corning Cable Systems for
the minimum bend radius. Last, protect exposed cable using the proper housing and strain relief
for the cable.
STANDARD RECOMMENDED PROCEDURE 004-120 | ISSUE 1 | FEBRUARY 2009 | PAGE 1 OF 4
ClearCurve™ Drop Cable
Pulling Grip Kit
cat. number 004-120, Issue 1
Reason for Change
Initial release
Advertisement
Table of Contents
Related Manuals for CORNING ClearCurve SRP-005-065
Summary of Contents for CORNING ClearCurve SRP-005-065
- Page 1 ClearCurve assemblies to not exceed 50 lbs of tension. Third, do not exceed the bend radius and refer to the specification sheet or contact Corning Cable Systems for the minimum bend radius. Last, protect exposed cable using the proper housing and strain relief for the cable.
- Page 2 Carton Contents The ClearCurve™Drop Cable Pulling Grip Kit (p/n TKT-CCPG) contains the following items • Twenty 2-foot pieces of 1/4-inch flame retardant mesh grip • One roll of electrical tape Tools and Materials The following tools and materials are also required to complete this procedure •...
- Page 3 Step 3: Apply the mesh grip as follows: a) Take a 2-foot piece of the 1/4-inch flame- retardant mesh grip and press an end inward so that it expands (Figure 4). b) Maintain the mesh end expanded and place the connector in the mesh (Figure 5).
- Page 4 800-743-2675 • FAX: 828-901-5973 • International + 1-828-901-5000 • www.corning.com/cablesystems Corning Cable Systems reserves the right to improve, enhance, and modify the features and specifications of Corning Cable Systems products without prior notification. ClearCurve Drop is a trademark of Corning Cable Systems Brands, Inc. All other trademarks are the property of their respective holders. Corning Cable Systems is ISO 9001 certified.
