- Page 1 SC24QPRO/SC50QPRO 24 LITRE BRUSHLESS OIL-LESS AIR COMPRESSOR OWNER’S MANUAL FOR YOUR SAFETY PLEASE READ THESE INSTRUCTIONS CAREFULLY AND RETAIN THEM FOR FUTURE USE.
-
Page 2: General View
(10) Check valve (11) Tank (12) Crash pad (13) Drain valve (14) Solenoid valve (15) Main compressor (16) Wheel TECHNICAL SPECIFICATIONS SC24QPRO SC50QPRO Model Power 825W 1100W 825W 1100W 4) When the air compressor needs to be turned on, it is necessary to insert the... -
Page 3: Care And Maintenance
fixing screws on the controller and the fixing screws on the cylinder sure (Fig.4). head, and also check the loosening of the connecting pipe nut. If there is loosening, tighten it in time. WWW.SGS-ENGINEERING.COM PAGE 4 PAGE 5... -
Page 4: Troubleshooting Chart
Pressure insufficient Check and repair Sealing gasket damaged or discharge capacity Check and replace Valve plate damaged, carbon decreased Replace and clean buildup or stuck Repair or replace Piston ring and cylinder worn or damaged WWW.SGS-ENGINEERING.COM PAGE 6 PAGE 7... -
Page 5: Parts List
SGS Engineering (UK) Ltd PARTS LIST Unit 1 West Side Park Raynesway Part Part No Part Part No Derby, DE21 7AZ Motor cover 908182 Cooling wind leaf 908214 Pan head bolts M5*8 908183 Crankcase cover 908215 EC Declaration of Conformity... - Page 6 Specification Table for Tightening Force and Destructive Torque of Screws Scope of application: 1、 The general specification 3-10mm in outer diameter and meets the strength grade of ISO898-1 4.8/8.8; 2、 Screws that are shorter than 3 times in outer diameter are not suitable for the destructive torque tests.
- Page 7 Standard Component Specification: Min. Tightening Force Description Specification (N.m) Quick connector 1∕4 ≥6 High pressure pipe G3/8 ≥18 （ nut ） Back cover of ≥12 check valve(48) Back cover of ≥15 check valve (55) Note: 1. The fixed head and foot pad screws (M8) shall be controlled according to a strength level of 6.8, and their Min.
