- Page 1 Alnor 8585 CompuFlow Thermo-Anemometer In Stock Qty Available: 1 Used and in Excellent Condition Open Web Page https://www.artisantg.com/43817-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
- Page 2 OWNER’S MANUAL ® CompuFlow Thermo-anemometer Model 8585/8586...
-
Page 3: Warranty
TSI Incorporated / July 2002 / All rights reserved Address TSI Incorporated, Alnor Products, 500 Cardigan Road, Shoreview, MN 55126 USA Toll-free: (800) 424-7427 Phone: (651) 490-2811 Fax: (651) 490-3824 LIMITATION OF WARRANTY AND LIABILITY. Seller warrants the goods sold hereunder, under... -
Page 4: Table Of Contents
TABLE OF CONTENTS 1. General Description ............2 2. Theory of Operation: Thermo-anemometers ....2 3. Safety ................3 4. About the Instrument .............3 5. Getting Started ...............4 6. Detailed Operation ............6 7. Troubleshooting ............12 8. Maintenance..............12 9. Service Information .............12... -
Page 5: General Description
SECTION 1 General Description The CompuFlow Model 8585/8586 thermo-anemometer is a hand-held, battery powered, microprocessor based instrument capable of measuring air velocity, temperature, and relative humidity. It can also calculate the volumetric flow rate, dew point temperature, and wet bulb temperature. This digital instrument measures velocities from 0 to 9999 ft/min (0 to 50 m/s). -
Page 6: Safety
SECTION 3 Safety When using the CompuFlow to check air flow and/or temperature, make certain that you can safely raise and hold the instrument while making measurements. Be especially careful when working on a ladder. Observe all necessary precautions so that the unit does not become caught in moving machinery or touch any exposed electrical wiring. -
Page 7: Getting Started
Figure 2: CompuFlow In figure 2 you can see the CompuFlow and its parts. 1. Keypad 6. Probe 2. AC Adapter Port 7. Dimple 3. Printer/Computer Port 8. Velocity Sensor 4. Battery Compartment 9. Temperature and RH Sensor 5. Stand 10. - Page 8 3. Turn the instrument on by pressing the ON/OFF key on the keypad. Each time the instrument is turned on, it will display % battery life, % logging memory available, baud rate, time, entered barometric pressure, and entered ambient temperature. You ↵...
-
Page 9: Detailed Operation
SECTION 6 Detailed Operation Changing the Baud Rate The CompuFlow has a variable baud rate that is used when downloading or printing information from the instrument. By increasing the baud rate, the data will be downloaded faster. Note: The baud rate must be equal to that of your computer or printer. The baud rate is displayed during the initial power up sequence. -
Page 10: Measuring Flow Rate
Measuring Flow Rate The first time the VOL key is pressed, the type of volume measurement to be made must be selected. The symbols shown are: circle – for a round duct; rectangle—for a square or rectangular duct; and the third choice is a horn. Use the ↑↓ arrow keys to choose one of the symbols. - Page 11 Taking and Storing Measurements All readings are stored in test IDs. You may store up to 1871 samples in 285 IDs. To advance to a new test ID, press the NEXT TEST key. Press the ↵ key to store a reading. “SAMPLE” will light up on the display, and a countdown the length of the time constant will begin.
-
Page 12: Recalling Stored Data
The log mode remains programmed until you go into TIME LOG and turn this feature “OFF”. This was done so you can use continuous datalogging in various locations without resetting the TIME LOG. When “LOG” is on the display, pressing ↵ starts the TIME LOG operation. -
Page 13: Auto Shut Off
COMPUDAT is a Windows-based program designed to download the data stored in the memory of the CompuFlow to a computer. This data includes the test ID, measurement, unit of measure, correction factors, actual/standard parameter, flow area, and time constant. This data is date and time stamped. In addition, the statistics for each test ID are provided. -
Page 14: Changing Measurement Units
Changing Measurement Units The measurement units can easily be changed by changing a few DIP switch positions. To access the DIP switches, turn the instrument off and remove the batteries from the battery compartment. On the inside of the battery compartment, there is a window with eight DIP switches (see figure 3). -
Page 15: Troubleshooting
SECTION 7 Troubleshooting Symptom Possible Cause and Corrective Action Meter does not turn on. Batteries may be discharged. Charge or replace them. • Switch failure, wiring failure, or circuit failure. Contact • Customer Service. Meter reading lower or Odd air flow pattern. Perform traverse to get average •... - Page 16 Please have the following information available when you call: • Owner’s name, address, and phone number • Billing address, if different and applicable • Instrument name and model • Serial number • Date of purchase • Where purchased We recommend that you keep a “calibration log” and keep all records of service on your instrument.
- Page 18 ® COMPUFLOW MODEL 8585/8586 SPECIFICATIONS Velocity Range: 0 - 9999 ft/min (0-50 m/s) 1&2 Accuracy: ±3 % of reading or ±3 ft/min, whichever is greater Resolution: 1 ft/min under 500 ft/min (0.05 m/s under 10.00 m/s), 5 ft/min at 500 ft/min and over (0.1 m/s at and over 10.00 m/s) Volumetric Flow Rate Range:...
- Page 19 TSI Incorporated Alnor Products 500 Cardigan Road Shoreview, MN 55126 USA Toll-Free (800) 424-7427 Telephone (651) 490-2811 September 2002 Fax (651) 490-3824 Printed in USA www.alnor.com Part No. 116-159-858, rev. 6 (1980341e) Copyright 2002 TSI Incorporated customerservice@alnor.com...
