- Page 1 HD690 ANGLOCK VISE ® BASE ASSEMBLY Operating Instruction Manual HD690/HDM690 ENGLISH...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction ...................... 3 Set-Up Instructions ..................4 Operating Instructions ................5-11 HD690 Parts List ...................12 HD690 Mechanical Drawing ...............13 HDM690 Parts List ..................14 HDM690 Mechanical Drawing ..............15 Maintenance Schedule ................16-18 Troubleshooting Tips ..................19 Warranty ......................20 VISE DATA Use this to fill out information about your vise for quick reference. -
Page 3: Introduction
INTRODUCTION Thank you for purchasing a Kurt HD690 vise. You have just purchased one of the best machine vises in the industry. The outstanding accuracy of this product is second to none. Backed by a lifetime warranty against workmanship and material defects, this product is built to last when used and maintained properly. -
Page 4: Set-Up Instructions
SET-UP INSTRUCTIONS Now that you have your new Kurt Vise, it’s time to set-up and begin using it. You will see that your new vise comes with a Kurt swivel handle and chip guard in the shipping carton (instruction manual available online at www.kurtworkholding.com). -
Page 5: Operating Instructions
To properly clamp a part in your Kurt vise, you should place the part in the center of the jaws resting on the ways of the vise. Clamping only on one side or above the movable and stationary jaws can result in jaw lift or loss of accuracy. - Page 6 Fig.2 Sketch #2A Incorrect part clamping. Vise width centerline Sketch #2B Correct part clamping Sketch #2C Correct part clamping Sketch #2D Correct part clamping Dummy spacer OPERATING INSTRUCTIONS...
- Page 7 JAW POSITIONING Fig.3 Note: Dimensions below are in inches unless specified. 9.062 12.099 13.787 16.824 OPERATING INSTRUCTIONS...
- Page 8 SIDE & END VIEW Fig.4 Note: Dimensions below are in inches unless specified. GG Hex 3.125 6.000 16.81 Ø P 3.75 (Typ) 0.66 1.485 2.312 1.735 7.33 0.725 4.000 2.000 5.812 0.940 3.875 1/2-13 1.51 OPERATING INSTRUCTIONS...
-
Page 9: Mounting Locations
MOUNTING LOCATIONS Fig.5 Note: Dimensions below are in inches unless specified. ØY 0.330 2.000 50 mm ØX 200 mm 80 mm 10.000 4.000 16 mm 0.625 ØY 0.992 ØZ 1.51 16.81 ØX GG Hex ØY OPERATING INSTRUCTIONS... - Page 10 SURFACE MOUNT USING SINE KEYS Mounting the new HD690 with keys requires the use of sine keys instead of standard keys. They are available in several different sizes that are listed on our website at www.kurtworkholding.com. The keys are sold in sets of 2 per package.
- Page 11 PROPER CHIP GUARD* INSTALLATION AND USAGE Fig.6 Chip Guard Length = Part Length + 1" 0.725" Part Length 0.725" CHIP GUARD TO BE Chip Guard* stock shown above keep chips from the nut and screw assembly and must be cut and deburred to meet your application and safety needs.
-
Page 12: Hd690 Parts List
THRUST BEARING WASHER 3600V-147 RETAINING RING, SPIRAL, SMALLEY #WS-84 3600V-99 O-RING, BUNA #117, 70 DURO HD690-102 MODEL/SERIAL NUMBER TAG HDLM6J-111 KURT LOGO TAG 3600V-128 O-RING, BUNA #129 HDM6-142 SPRING GUIDE DX6-169 WAVE SPRING, SMALLEY SSR-0137 HD6-197 LEE COMPRESSION SPRING #LC-059E-17S... -
Page 13: Hd690 Mechanical Drawing
HD690 MECHANICAL DRAWING Fig.7 HD690 MECHANICAL DRAWING... -
Page 14: Hdm690 Parts List
THRUST BEARING WASHER 3600V-147 RETAINING RING, SPIRAL, SMALLEY #WS-84 3600V-99 O-RING, BUNA #117, 70 DURO HDM690-102 MODEL/SERIAL NUMBER TAG HDLM6J-111 KURT LOGO TAG 3600V-128 O-RING, BUNA #129 DX6-169 WAVE SPRING, SMALLEY SSR-0137 HD6-197 LEE COMPRESSION SPRING #LC-059E-17S HDM6-142 SPRING GUIDE... -
Page 15: Hdm690 Mechanical Drawing
HDM690 MECHANICAL DRAWING Fig.8 HDM690 MECHANICAL DRAWING... -
Page 16: Maintenance Schedule
MAINTENANCE SCHEDULE It is very important to perform regular maintenance on your Kurt vise to ensure proper operation. Improper maintenance will result in poor vise performance and may void your warranty. Daily/ Weekly 1. Remove chips from surface of vise. - Page 17 MAINTENANCE SCHEDULE 7. Tip the jaw so the front of the jaw (the side with the jaw plate) is on the vise bed. Lower the jaw on to the bed so that the segment contacts the hook part of the nut and rest the jaw on to the vise bed. 8.
- Page 18 MAINTENANCE SCHEDULE 3 to 6 months 1. Open vise to maximum opening. 2. Loosen the set-screw and remove the movable jaw. 3. Remove spiral-retaining ring from handle end of the vise screw. 4. Remove the screw support from the vise body. 5.
-
Page 19: Troubleshooting Tips
TROUBLESHOOTING TIPS If properly maintained, The Kurt HD690 Series vise will operate trouble free for many years. In some cases, it will be necessary to troubleshoot. Use the information below to help in the process. Problem: My vise turns hard. -
Page 20: Warranty
The sole obligation of Kurt Manufacturing Company, Inc. (Kurt) and the purchaser’s SOLE AND EXCLUSIVE REMEDY hereunder, shall be limited to the replacement or repair of any Kurt product or part (by an authorized Kurt technician) which are returned to Kurt Manufacturing Company’s place of business or any authorized service... - Page 21 If you have any feedback or questions please contact us: Kurt Industrial Products // A Division Of Kurt Manufacturing 9445 East River Road NW | Mpls, MN 55433 Phone 763-574-8309 | Toll Free 877-226-7823 Fax 763-574-8318 | Toll Free Fax 877-226-7823 Manual Revision: kurtworkholding.com | workholding@kurt.com...
