Page 2: General Information
The information in this guide is subject to change without notice. The latest version of this document and the manual for installation, commissioning, configuration and decommissioning are to be found in PDF format at www.solplanet.net. Safety Intended Use This product is designed and tested strictly in accordance with national standards and industry standards, and there may still be residual risks. -
Page 3: Eu Declaration Of Conformity
8, 2011) and 2015/863/EU (L 137/10, March 31,2015) (RoHS) AISWEI Technology Co., Ltd. confirms herewith that the product described in this manual are in compliance with the fundamental requirements and other relevant provisions of the above mentioned directives. The entire EU Declaration of Conformity can be found at www.solplanet.net. Ai-AMU 2000_EN_V02... - Page 4 Overview Name Cabinet Door Mounting parts Grounding point of cabinet Single-phase AC port Three-phase ABUS/ PID port Ethernet/ RS485 communication port Antenna/ Ethernet port Ai-AMU 2000_EN_V02...
- Page 5 Optical fiber port USB port AI/PT signal port DI signal port DO signal port Ventilation valve System Structure: Ai-AMU 2000_EN_V02...
-
Page 6: Scope Of Delivery
Scope of Delivery Name Quantity Ai-AMU 2000 M6×16 Screw M12 Expansion bolt M12 Combination bolt Plum spanner Hoop mounts M5×12 screw Hoop Mount Connection Assembly Documentation bag Ai-AMU 2000_EN_V02... -
Page 7: Mounting Environment
Mounting Environment ） Ai-AMU 2000_EN_V02... - Page 8 Dimensions Unit：mm Mounting Wall Mounting Ai-AMU 2000_EN_V02...
- Page 9 Bracket Mounting * The bracket needs to be prepared by the customer. Hoop Mounting * The hoop needs to be prepared by the customer. Ai-AMU 2000_EN_V02...
- Page 10 Second Protective Grounding *OT terminals and cables need to be prepared by the customer. 10 Electrical Connection 10.1 Open the Cabinet Door Ai-AMU 2000_EN_V02...
- Page 11 10.2 Connect the Single-Phase Power Cable *As shown in the figure, after the wires are ready, connect the wires from AC INPUT and the lower end of the single-phase switch. The left side is L and the right side is N (for backup power supply, it is not necessary to connect when using three-phase power supply and there is no special working condition) .
- Page 12 10.4 Connect RS485 Communication Cable Port Silkscreen Definition Port Silkscreen Definition RS485-1A RS485-4A RS485-1 RS485-4 RS485-1B RS485-4B RS485-2A RS485-5A RS485-2 RS485-5 RS485-2B RS485-5B RS485-3A RS485-6A RS485-3 RS485-6 RS485-3B RS485-6B *As shown in the figure, the line is fed in from ETH/RS485. After the corresponding line is prepared, the operation is as follows: A.
- Page 13 10.5 Connect Optical Fiber * Optical module needs to be prepared by the customer. * SFP1 corresponds to TX1/RX1, SFP2 corresponds to TX2/RX2. Optical module is optional, if you configure it by yourself, you can choose • 100/1000Mbps optical module according to the docking port of the optical switch, the optical module adopts SFP or eSFP package, the 100Mbps optical module supports the transmission distance of >12km, and the 1000Mbps optical module supports the transmission distance of ≥10km.
-
Page 14: App Download
10.6 Close the Cabinet Door App Download Download and install the Solplanet app by scanning the QR code below. For details, please refer to the APP user manual. Android Ai-AMU 2000_EN_V02... - Page 15 The following information is needed to provide necessary assistance: ——Product serial number ——Fault code ——Installation location ——Warranty card EMEA Service email: service.EMEA@solplanet.net APAC Service email: service.APAC@solplanet.net LATAM Service email: service.LATAM@solplanet.net Aiswei Greater China Service email: service.china@aiswei-tech.com Hotline: +86 400 801 9996 Taiwan Service email: service.taiwan@aiswei-tech.com...
- Page 16 Ai-AMU 2000_EN_V02...
