Solplanet ASW3000H-S2 User Manual

Single phase hybrid inverter
Hide thumbs Also See for ASW3000H-S2:
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASW3000H-S2 and is the answer not in the manual?

Questions and answers

Related Manuals for Solplanet ASW3000H-S2

Summary of Contents for Solplanet ASW3000H-S2

  • Page 2: Table Of Contents

    6.7 Wi-Fi stick connection ........ 50 6.8 BMS CAN cable connection ......51 6.9 DRED cable connection ......52 6.10 Smart meter cable connection ....53 Commissioning and operating ......56 7.1 Inspection before commissioning ....56 7.2 Commissioning procedure ......56 Solplanet APP ..........57...

  • Page 3: General Information

    You will find the latest version of this document and further information on the product in PDF format at www.solplanet.net. It is recommended that this document is stored in an appropriate location and be available at all times.

  • Page 4: Symbols

    1.4 Symbols DANGER Indicates a hazardous situation which, if not avoided, will result in death or serious injury. WARNING Indicates a hazardous situation which, if not avoided, could result in death or serious injury. CAUTION Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. NOTICE Indicates a situation which, if not avoided, can result in property damage.

  • Page 5: Safety

    2 Safety 2.1 Intended use The product is a transformerless hybrid inverter with 2 MPP trackers and a battery connection that feeds the direct current  of the PV array into the connected battery or converts it to grid-compliant single-phase current and then feeds it into the utility grid.
  • Page 6 The DC cables connected to the battery or the PV array may be live. Touching the DC conductors or the live components can cause to lethal electric shocks. If you disconnect the DC connectors from the product under load, an electric arc may occur leading to electric shock and burns.
  • Page 7 Disconnect the product from voltage and energy sources and ensure it cannot be reconnected before working on the device.  Only touch the cables of the PV modules on their insulation.  Do not touch any parts of the substructure or frame of the PV array. ...

  • Page 8: Symbols On The Label

    2.3 Symbols on the label Beware of a danger zone！ This symbol indicates that the product must be additionally grounded if additional grounding or equipotential bonding is required at the installation site. Beware of high voltage and operating current！ The product operates at a high voltage and current. Work on the product must only be carried out by skilled and authorized personnel.

  • Page 9: Unpacking And Storage

    3 Unpacking and storage 3.1 Scope of delivery Check the scope of delivery for completeness and any visible external damage. Contact your distributor if the scope of delivery is incomplete or damage. Object Description Quantity Inverter Wall Bracket AC connector DC connector Battery teminal cover RS485 Communication client...
  • Page 10 The storage temperature must be between -30°C to +70°C, and the storage relative humidity must be between 0 and 100%,  non-condensing. The packing with the inverter shall not be tilted or inverted.  The product must be fully inspected and tested by professionals(Refer to section 1.3) before it can be put into operation, ...

  • Page 11: Inverter Overview

    4 Inverter overview 4.1 Product description Figure shown here is for reference only. The actual product received may differ！ Object Name Description Mounting ears Two ears hang the inverter onto the mounting-bracket. Two points, used for the fixed connection between the inverter and the Inverter fixed point mounting-bracket.

  • Page 12: Led Indicator

    4.3 LED indicator Function Description Glowing The product operates normally and the solar energy is available. Flashing The product is self-checking automatically, or the firmware is updating. SOLAR The solar energy is not available. Glowing The product operates normally and the battery energy is available. The product is self-checking automatically, or the firmware is updating, or the Flashing SOC of the battery is low.

  • Page 13: Interfaces And Functions

    Solplanet communication products or the third-party monitor device can be chosen. RS485 Interface The inverter may or may not be equipped with two RS485 interfaces. The inverter can communicate with Solplanet communication products or third party devices via the RS485 interface. For more information regarding third party devices, please contact the local Solplanet service department.
  • Page 14 This product complies with IEC 62109-2 clause 13.9 for earth fault alarm monitoring. If an Earth Fault Alarm occurs, the red color LED indicator will light up. At the same time, the error code 38 will be sent to the Solplanet Cloud.

  • Page 15: Basic System Solution

    4.6 Basic system solution The product is a high-quality inverter which can convert solar energy to AC energy and store energy into battery. The product can be used to optimize self-consumption, store in the battery for future use or feed into public grid. The basic application of this product as follow: UM0025_ASW3000-6000H-S2_EN_V04_0624...
  • Page 16 Description Object Remark The product supports to connect the monocrystalline silicon, polycrystalline silicon, and thin- PV String film without grounding. Hybrid inverter ASW H-S2 series products have an EPS port. The smart meter is the central device responsible for energy management. Communicate with Smart meter the inverter through the RS485 protocol.
  • Page 17 The system diagram of this product as follow: For Australia and New Zealand, the neutral cable of On-grid side and EPS side must be connected together according to the wiring rules AS/NZS 3000. Otherwise the EPS function will not work. For other countries, the following diagram is an example for grid systems without special requirement on wiring connection.

  • Page 18: Energy Management

    4.7 Energy Management The energy management mode depends on PV energy and user’s preference. There are five energy management mode can be chosen. 4.7.1 Self-Consumption mode The photovoltaic energy is preferentially used by local load to improve the self- consumption rate and self-sufficiency rate. The energy management during daytime: Case 1: PV power generation is lower than the load power consumption, and the energy of the battery is not available.
  • Page 19 Case 2: PV power generation is lower than the load power consumption, and the energy of the battery is available. Case 3: PV power generation is larger than the load power consumption. The energy management during night: UM0025_ASW3000-6000H-S2_EN_V04_0624...
  • Page 20 Case 1: The energy of the battery is available. Case 2: The energy of the battery is not available. UM0025_ASW3000-6000H-S2_EN_V04_0624...
  • Page 21 4.7.2 Back-up mode The battery is a back-up energy storage device. The battery always charged by PV power if it is not full charged. The battery discharge only when the utility grid loss. Case 1: The energy of the battery is not full charged. Case 2: The energy of the battery is full charged, even at night.
  • Page 22 Case 3: The battery discharge when the utility grid loss. 4.7.3 Force time use custom Users can manage the energy according to their own needs, and set the daily regular charging and discharging on the app. Other time follow the Self-Consumption mode. This mode requires WiFi stick to connect to the network normally in order to function properly.
  • Page 23 4.7.5 Time of use Mode Let the inverter charge or discharge the battery to the set SOC value within the time period set by the app, and the battery discharge power in the grid-connected state can be customized. Time of use mode reasonably sets the expected SOC of the battery according to the energy change of PV in the day, which helps the energy storage inverter to store the PV power to the battery with maximum efficiency, reduces the cost of buying electricity from the grid, and improves the cost performance of the energy storage inverter.
  • Page 24 UM0025_ASW3000-6000H-S2_EN_V04_0624...
  • Page 25 For example UM0025_ASW3000-6000H-S2_EN_V04_0624...
  • Page 26 2: During 00:00-05:00, when battery SOC is lower than 80%, it will use grid to charge the battery until battery soc reaches 80%. 3-4: During 05:00-08:00 and 08:00-10:00, when battery SOC is higher than 40%, hybrid inverter will discharge the battery until the Soc reaches 40%.

  • Page 27: Mounting

    5 Mounting 5.1 Requirements for mounting DANGER Danger to life due to fire or explosion！ Despite careful construction, electrical devices can cause fires. This can result in death or serious injury. Do not mount the product in areas containing highly flammable materials or gases. ...

  • Page 28: Taking Out And Moving The Product

    Maintain the recommended clearances to wall as well as to other inverters or objects. In case of multiple inverters, reserve specific clearance between the inverters.  The product should be mounted such that the LED signals can be read off without difficulty. The DC load-break switch of the product must always be freely accessible.

  • Page 29: Mounting

    5.3 Mounting Step 1： Align the mounting-bracket horizontally on the wall with the arrow upwards. Mark the position of the drill hole. Set the wall mounting bracket aside and drill the marked holes with the diameter of 10mm. The depth of the holes should be about 70 mm.
  • Page 30 Step 4： Hang the inverter to the mounting-bracket and ensure that the mounting ears perfectly engage with the mounting- bracket. Step 5： Fix the inverter with screws. Step 6： To protect the inverter from theft, attach the padlock provided by customer through the wall mounting bracket and the inverter.
  • Page 31 Complete the installation. UM0025_ASW3000-6000H-S2_EN_V04_0624...

  • Page 32: Electrical Connection

    6 Electrical connection 6.1 Connection port description Figure shown here is for reference only. The actual product received may differ！ Object Description Battery terminal cover DC-switch PV Input BMS: BMS communication port METER: Merter communication port DRED: DRMs device port Communication device (Wi-Fi Stick) EPS connector AC connector...

  • Page 33: Connecting Additional Grounding

    6.2 Connecting additional grounding The inverter is equipped with a grounding conductor monitoring device. This grounding conductor monitoring device detects when there is no grounding conductor connected and disconnects the inverter from the utility grid if this is the case. Hence the product does not require an additional grounding or equipotential bonding when operating.

  • Page 34: Grid Cable Connection

    Step 3： Apply paint to the grounding terminal to ensure corrosion resistance. Complete the installation. 6.3 Grid cable connection 6.3.1 Requirements for the Grid connection Cable Requirements The cable must be dimensioned in accordance with the local and national directives for the dimensioning of cables. The requirements for the minimum wire size derive from these directives.
  • Page 35 No consumer load should be applied between AC circuit breaker and the inverter. The selection of the AC circuit breaker rating depends on the wiring design (wire cross-section area), cable type, wiring method, ambient temperature, inverter current rating, etc. Derating of the AC circuit breaker rating may be necessary due to self-heating or if exposed to heat.
  • Page 36 Step 3： Crimp the terminals with crimping pliers. Step 4： Set the parts on the cable, insert the terminal holes in sequence. Crimp the wire with an inner hexagon screwdriver and screw the torque 1.2+/-0.1N·m. Step 5： Insert the main body into the rubber core and hear the “click” sound. Tighten the nut with an open-ended wrench (torque 2.5±0.5 N·m).
  • Page 37 6.3.3 Connecting the grid connectors Step 1： Remove the dust cover. Step 2： The installation arrow indicates insertion the female connector, and hear the “click” sound. Complete the installation. UM0025_ASW3000-6000H-S2_EN_V04_0624...

  • Page 38: Eps Load Cable Connection

    6.4 EPS Load cable connection 6.4.1 Requirements for the EPS Load connection For EPS Load connection requirements, refer to “6.3.1 Requirements for the Grid connection” for details. 6.4.2 Assembling the EPS Load connectors Step 1： Switch off the miniature circuit-breaker or the switch of every energy sources and secure it against being inadvertently switched back on.
  • Page 39 Step 4： Set the parts on the cable, insert the terminal holes in sequence. Crimp the wire with an inner hexagon screwdriver and screw the torque 1.2+/-0.1N·m. Step 5： Insert the main body into the rubber core and hear the “click” sound. Tighten the nut with an open-ended wrench (torque 2.5±0.5N·m).

  • Page 40: Dc Connection

    6.4.3 Connecting the Back Load connectors Step 1： Remove the dust cover. Step 2： The installation arrow indicates insertion the female connector, and hear the “click” sound. Complete the installation. 6.5 DC connection 6.5.1 Requirements for the DC connection Requirements for the PV modules per input: All PV modules should be of the same type.
  • Page 41 The thresholds for the input voltage and the input current of the inverter must be adhered to.  The positive connection cables of the PV modules must be equipped with the positive DC connectors. The negative  connection cables of the PV modules must be equipped with the negative DC connectors. 6.5.2 Assembling the DC connectors DANGER...
  • Page 42 Step 2： Crimp the contacts with the corresponding cables. Crimping tool: PV-CZM-61100. If the stranded wire is not visible in the chamber, the cable is not correctly inserted and the connector must be reassembled. To do this, the cable must be removed from the connector. Release the clamping bracket.
  • Page 43 Type 2 DC connector: Assemble the DC connectors as described in the following. Assemble the DC connectors as described below. Be sure to observe the correct polarity. The DC connectors are marked with the symbols “+” and “−”. Cable requirements: Item Description Value...
  • Page 44 Step 3： Lead the cable through cable gland, and insert into the insulator until it snaps into place. Gently pull the cable backward to ensure firm connection. Tighten the cable gland and the insulator (Torque 2.5-3Nm). Step 4： Ensure that the cable is correctly positioned. 6.5.3 Connecting the PV module DANGER...
  • Page 45 Procedure: Step 1： Ensure that the individual miniature circuit-breaker is switched off and ensure that it cannot be accidentally reconnected. Step 2： Ensure that the DC switch is switched off and ensure that it cannot be accidentally reconnected. Step 3： Ensure that there is no ground fault in the PV array. Step 4：...
  • Page 46 Insert the DC connectors with sealing plugs into the corresponding DC inputs on the inverter.  Type 2 DC connector: Connect the assembled DC connectors to the inverter.  For unused DC connectors, push down the clamping bracket and push the swivel nut up to the thread. Insert the DC ...

  • Page 47: Battery Connection

    Check the positive and negative polarity of the PV strings, and connect the PV connectors to corresponding terminals only after ensuring polarity correctness. (The graph uses the type 2 connector as an example only.) Step 7： Ensure that all DC connectors and the DC connectors with sealing plugs are securely in place. Complete the installation.
  • Page 48 Item Description Value External diameter 10-12 mm Copper cable conductor cross-section 20~25 mm² ≤ 55 mm Sheath stripping length 6.6.2 Assembling the Battery connectors Procedure: Step 1： Guide the heat shrink tubing over the uninsulated crimp point and crimp the OT/DT terminal. Step 2：...
  • Page 49 Step 2： Tighten the cable gland nuts (Torque 1.6 N·m). Step 3：Tighten the battery terminal cover. Complete the installation. UM0025_ASW3000-6000H-S2_EN_V04_0624...

  • Page 50: Wi-Fi Stick Connection

    6.7 Wi-Fi stick connection Procedure: Step 1： Use the Wi-Fi stick included in the scope of delivery. Step 2： Remove the dust and waterproof cover of the Ai-Dongle on the inverter and retain it. Step 3： Attach the Wi-Fi stick to the connection port in place and tighten it by hand with the nut on the Wi-Fi stick. Make sure the Wi-Fi stick is securely connected and the label on the Wi-Fi stick can be easily seen to allow for the scanning of the QR code during commissioning.

  • Page 51: Bms Can Cable Connection

    6.8 BMS CAN cable connection Procedure: Step 1： RS485 cable pin assignment as below, strip the wire as shown in the figure, and crimp the copper wire to the appropriate OT terminal (according to DIN 46228-4, provided by the customer) Step 2：...

  • Page 52: Dred Cable Connection

    Complete the installation. 6.9 DRED cable connection Procedure: Step 1： RJ45 cable pin assignment as below, strip the wire as shown in the figure, and crimp the copper wire to the appropriate OT terminal (according to DIN 46228-4, provided by the customer) Step 2：...

  • Page 53: Smart Meter Cable Connection

    Step 4： Insert the network cable into the corresponding communication terminal of the machine according to the arrow sequence, tighten the thread sleeve, and then tighten the forcing nut at the tail. Complete the installation. 6.10 Smart meter cable connection 6.10.1 Connection Procedure Procedure: Step 1：...
  • Page 54 Step 3： Unscrew the communication port cover cap in the following arrow sequence. Step 4： Insert the network cable into the corresponding communication terminal of the machine according to the arrow sequence, tighten the thread sleeve, and then tighten the forcing nut at the tail. Complete the installation.
  • Page 55 6.10.2 Smart meter connection The grid structure supported by the product is TN-S. For other grid types, please refer to 4.4. UM0025_ASW3000-6000H-S2_EN_V04_0624...

  • Page 56: Commissioning And Operating

    7 Commissioning and operating 7.1 Inspection before commissioning CAUTION Danger to life due to high voltages on DC conductors! When exposed to sunlight, the PV array generates dangerous DC voltage which is present in the DC conductors. Touching the DC and AC conductors can lead to lethal electric shocks.. Only touch the insulation of the DC cables.

  • Page 57: Solplanet App

    Procedure: Step 1： Open Solplanet App to enter the login screen, and tap “Do not have an account” to enter the next screen. Step 2： The user groups “Business user” and “End user” need be selected according to your identity, and tap “Next step”.
  • Page 58 Step 1 Step 2 Step 3 Step 4 Step 5 UM0025_ASW3000-6000H-S2_EN_V04_0624...

  • Page 59: Create A Plant

    8.4 Create a plant Procedure: Step 1： Open Solplanet App to enter the login screen, enter the account name and password, and tap “Log in” to enter the next screen. Step 2： Tap the symbol “+” to enter the next screen, and tap “Create or modify a plant”, then the camera of the mobile automatically turns on, and scan the QR code of the Ai-dongle to enter the next screen, tap “Create new plant”...
  • Page 60 Step 1 Step 2 UM0025_ASW3000-6000H-S2_EN_V04_0624...
  • Page 61 Step 3 Step 4 Step 5 Step 6 UM0025_ASW3000-6000H-S2_EN_V04_0624...
  • Page 62 Step 7 Eastron SDM630-Modbus V2 Step 7 Step 8 UM0025_ASW3000-6000H-S2_EN_V04_0624...
  • Page 63 Eastron SDM630-Modbus V2 Step 8 Step 9 Step 9 Step 10 UM0025_ASW3000-6000H-S2_EN_V04_0624...
  • Page 64 Step 11 UM0025_ASW3000-6000H-S2_EN_V04_0624...

  • Page 65: Setting Parameters

    8.5.1 Inverter configuration The Solplanet’s products comply with local grid code when leaving the factory. But you still should check the grid code and the parameters according to the requirements of the installation site. Once configuration of the product is completed, the product will start operating automatically...
  • Page 66 ○ Power on/off Remote turn on/off the inverter on the App. ○ Configure the parameters of the Hybrid inverter. Energy storage settings Configure the parameters of the battery. 8.5.2 Grid code settings For the Australia market, the inverter cannot be connected to the grid before the safety related area is set. Please select from Australia Region A/B/C to comply with AS/NZS 4777.2:2020, and contact your local electricity grid operator on which Region to select.
  • Page 67 8.5.3 Active power reduction at overfrequency P(f) There are four modes (Please refer to the following table) can be chosen for this function and many parameters can be configured according to the requirement of the local grid company. Procedure: Step 1： Tap “Active power settings” to enter to the next page. Step 2：...
  • Page 68 Step 3 Step 4 UM0025_ASW3000-6000H-S2_EN_V04_0624...
  • Page 69 Table description Name Description Droop is defined as the active power as a percentage of Act. Power as a ○ percentage of P The active power will continuously move up and down Linear the frequency characteristic curve in the frequency range of f1 to f stop Droop is defined as the active power as a percentage of...
  • Page 70 Here, the Droop is different from the Droop S in section 3.7.2 of the standard EN 50549-1. If you want to configure the Droop S, the formula as below should be used to configure. 8.5.4 Active power reduction at overvoltage P(U) There are five modes (Please refer to the following table) can be chosen for this function and many parameters can be configured according to the requirement of the local grid company.
  • Page 71 Step 3 Step 4 UM0025_ASW3000-6000H-S2_EN_V04_0624...
  • Page 72 Table description Name Description Droop is defined as the active power as a percentage of The active power will continuously move up and down Act. Power as a ○ the voltage characteristic curve in the voltage range of percentage of Ustart to U stop , Linear...
  • Page 73 power output level reached in response to the increase in voltage between U to U start stop The active power reduce from the P that is the instantaneous active power at the time of exceeding Start voltage U start Droop is defined as the active power as a percentage of The active power will continuously move up and down Act.
  • Page 74 8.5.5 Cosφ(P) curve configuration The power related control mode cosφ(P) controls the cosφ of the output as a function of the active power output. There are four coordinate points that can be configured. The coordinate points are the active power as a percentage of P the displacement factor cosφ.
  • Page 75 Step 3 Step 4 Table description Parameter Description ○ The active power as a percentage of P ○ The displacement factor that is cosine of the phase angle Cosφ between the fundamental components of the line to neutral point voltage and the respective current. ○...
  • Page 76 The lock-in voltage value that enables the automatic ○ Activating reactive power delivery mode. voltage Activation threshold as a percentage of U corresponds to ‘lock-in’ voltage. The lock-out voltage value that disables the automatic ○ Deactivating reactive power delivery mode. voltage Deactivation threshold as a percentage of U corresponds...
  • Page 77 Step 1 Step 2 Step 3 Step 4 UM0025_ASW3000-6000H-S2_EN_V04_0624...
  • Page 78 Table description Name Description ○ The voltage as a percentage of U ○ The reactive power as a percentage of P ○ Phase Choose the over-excited or under-excited. The lock-in active power value that enables the Activating power ○ automatic reactive power delivery mode. as a percentage Activation threshold as a percentage of P corresponds to...

  • Page 79: Decommissioning The Product

    9 Decommissioning the product 9.1 Disconnecting the inverter from voltage sources Prior to performing any work on the product, always disconnect it from all voltage sources as described in this section. Always adhere to the prescribed sequence. WARNING Danger to life due to electric shock from destruction of the measuring device due to overvoltage！ Overvoltage can damage a measuring device and result in voltage being present in the enclo- sure of the measuring device.
  • Page 80 Step 6： Ensure that no voltage is present between the positive terminal and negative terminal at the DC inputs using a suitable measuring device. Step 7： Loosen and remove the Grid connector. Unlock instructions ① Rotate the latch as shown. ②...

  • Page 81: Dismantling The Inverter

    Step 10： Hold down the buckle on the side of the Ai-Dongle and pull out the Ai-Dongle terminal. 9.2 Dismantling the inverter After disconnecting all electrical connections as described in Section 9.1, the inverter can be removed as follows Procedure: Step 1：...

  • Page 82: Technical Data

    10 Technical data 10.1 ASW3000H/3680H/4000H/5000H/6000H-S2 ASW4000H- ASW5000H- ASW3000H- ASW3680H- ASW6000H- Type DC Input 6500 Wp 7500 Wp 9000 Wp Maximum power of PV array 5500 Wp 6180 Wp 4020 Wp 4600 Wp 4600 Wp Max. power per MPP tracker 3420 Wp 3820 Wp 550 V Maximum input voltage...

  • Page 83: General Data

    (1) The voltage range meets the requirements of the corresponding national grid code. (2) The frequency range meets the requirements of the corresponding national grid code. 10.2 General data Type ASW3000H-S2/ 3680H-S2 / 4000H-S2 / 5000H-S2/ 6000H-S2 483 x 455 x 193.5 mm Width × height × depth 25.1kg...

  • Page 84: Protective Device

    WLAN 802.11 b/g/n Radio spectrum WLAN with 2412 – 2472MHz band Maximum transmission power 100 mW 10.3 Protective device Protective devices ASW3000H-S2/ 3680H-S2 / 4000H-S2 / 5000H-S2/ 6000H-S2 Integrated DC reverse polarity protection Integrated DC isolator Integrated Ground fault monitoring...

  • Page 85: Troubleshooting

    11 Troubleshooting When the PV system does not operate normally, we recommend the following solutions for quick troubleshooting. If an error or warning occurs, there will have “Event Messages" display in the monitor tools. The corresponding corrective measures are as follows: Error code Message Corrective measures...
  • Page 86 result this fault? Make exchange of the inverter if complete the above guide with fault is still  there. Check the grid and EPS frequency and observe how often major fluctuations  occur. Fac Failure:Fac Out of Contact customer service if EPS frequency abnormal. ...
  • Page 87 there. Warning Code Message Corrective measures Disconnect the inverter from the AC grid, PV module and battery, and  reconnect after 5 minutes to check is the problem solved? PV1 input over current- Make exchange of the inverter if complete the above guide with fault is still ...
  • Page 88 the voltage range when installing the inverter; three phase inverter) If the fault reports during the inverter first installation, and also doesn’t  work for more than 6 months after production, then the fault may be caused by energy lack of capacitance. Then close the DC switch to charge the capacitor for one day to check is the problem solved? Make exchange of the inverter if it is not solved.
  • Page 89 Check PV string/Battery positive and negative connection.  PV string inverse Warning Code Battery error status Corrective measures details in App Make inspection of the communication wiring loosen or abnormal between  battery package and inverter. To supply power to the inverter through Communication data connecting inverter with the grid or PV.
  • Page 90 Confirm if there is any leakage or short circuit between the positive and  negative terminals of the battery; When insulation failure occurs, it is generally necessary to replace the faulty  Low system insulation battery pack inside the battery; If multiple insulation faults occur, it may be necessary to replace the entire ...

  • Page 91: Maintenance

    12 Maintenance 12.1 Cleaning the contacts of the DC switch DANGER High voltage of PV string may cause life danger！ If the DC connector is disconnected while the PV inverter is working, electric arc may occur, causing electric shock and burns.

  • Page 92: Recycling And Disposal

    When the customer needs warranty service during the warranty period, the customer must pro- vide a copy of the invoice, factory warranty card, and ensure the electrical label of the inverter is legible. If these conditions are not met, Solplanet has the right to refuse to provide with the relevant warranty service.

  • Page 93: Contact

    16 Contact EMEA Service email: service.EMEA@solplanet.net APAC Service email: service.APAC@solplanet.net LATAM Service email: service.LATAM@solplanet.net AISWEI Pty Ltd. Hotline: +61 390 988 674 Add.: Level 40, 140 William Street, Melbourne VIC 3000, Australia AISWEI B.V. Hotline: +31 208 004 844 (Netherlands) +48 134 926 109 (Poland) Add.: Barbara Strozzilaan 101,5e etage,kantoornummer 5.12,1083HN Amsterdam,the Netherlands...
  • Page 94 UM0025_ASW3000-6000H-S2_EN_V04_0624...

This manual is also suitable for:

Asw3680h-s2Asw4000h-s2Asw5000h-s2Asw6000h-s2
