PT502 Firmware Upgrade User Manual

Before upgrade, Please kindly check whether you already get ready of all following items:

 PT502 Device

 Screwdriver (to open PT502)

 Bofan USB cable (Usually we will send 1 free USB cable with your first order,please kindly keep it

well)

 USB Driver Installer( please kindly contact your sales representative to get it )

 mcuisp_stm.exe

 PT502 firmware file (please kindly contact your sales representative for the latest firmware)

1. Install the USB Driver in your computer under XP system or Win7 system.

2. Connect the USB cable to your computer, then you can go to your computer's Device Manager to

get the USB com port, please refer to it as below:

3. Double click "mcuisp_stm.exe" we offered, and then you need make some setting on this file,

please refer to below picture steps:

Step1: Select Com port what you checked at above.

Step2: Select 115200 as the Baud rate.

Step3: Select the upgrade firmware file

Need help?

Do you have a question about the PT502 and is the answer not in the manual?

Page 1  PT502 Device  Screwdriver (to open PT502)  Bofan USB cable (Usually we will send 1 free USB cable with your first order,please kindly keep it well)  USB Driver Installer( please kindly contact your sales representative to get it ) ...
Page 2 Note: Please don’t click any other button or modify any setting in this Tool except above steps. After you’ve done above 3 steps, you use screwdriver to open the PT502 shield board from the side where you can see on/off button After you open the shield board, please connect USB cable to PT502, Then push “Upgrade...
Page 3 Important Note: please remember to move the “ Upgrade button” back to USB port side and also move “ON/OFF switch” back to OFF side to turn off PT502, Otherwise you will not be able to turn on PT502 If any questions, please feel free to contact your sales representative or email us at sales@bofan.cc...
