V-TAC VT-8018 Installation Instructions

Microwave sensor

Advertisement

Quick Links

TECHNICAL DATA
Power Sourcing:
220-240V/AC
Power Frequency:
50/60Hz
Ambient Light:
<3-2000LUX (adjustable)
Min.10sec±3sec
Time Delay:
Max. 12min±1min
1200W (Traditional Lighting)
Rated Load:
300W (LED Lighting)
Detection Range:
360°/180°
Wall: 5-15m (adjustable)
Detection Distance:
Ceiling: 1-8m (radius),(adjustable)
Transmission Power
<0.2mW
Installing Height:
Wall: 1.5-3.5m, Ceiling: 2-8m
Power Consumption: approx 0.9W
Detection Motion Speed: 0.6-1.5m/s
HF System:
5.8GHz CW radar, ISM band
2. Must be installed by professional electrician.
This marking indicates that this
product should not be disposed of
with other household wastes.
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions carefully before
starting the installing and keep this manual handy for future reference. If you have any another query, please contact our dealer
or local vendor from whom you have purchased the product. They are trained and ready to serve you at the best.The warranty is
valid for 2 years from the date of purchase. The warranty does not apply to damage caused by incorrect installation or abnormal
wear and tear. The company gives no warranty against damage to any surface due to incorrect removal and installation of the
product. This product is warranted for manufacturing defects only. The product is a new saving-energy switch; it adopts micro-
wave sensor mould with high-frequency electro-magnetic wave (5.8GHz) and integrated circuit. It gathers automatism, conve-
nience, safety, saving-energy and practical functions. The wide detection field depends on detectors. It works by receiving human
motion. When one enters the detection field, it can start the load at once and identify automatically day and night. Its installation
is very convenient and its using is very wide. Detection is possible to go through doors, panes of glass or thin walls
FUNCTION
• Can identify day and night: It can work in the daytime and at night when it is adjusted on the "sun" position (max). It can work in the ambient light less than
3LUX when it is adjusted on the "3" position (min). As for the adjustment pattern, please refer to the testing pattern.
• Detection range selectable: It can be adjusted according to using location. The detection distance of low sensitivity could be only 2m and high sensitivity could
• Time–Delay is adjustable. It can be set according to the consumer's desire. The minimum time is 10sec±3sec. The maximum is 12min±1min
MICROWAVE SENSOR(VT-8018)
WARNING
Caution, risk of electric shock.
