MICROWAVE SENSOR DOWNLIGHT TYPE-ADJUSTABLE
TECHNICAL DATA
MODEL
SKU
INPUT POWER
RATED LOAD
TIME DELAY
DETECTION
RANGE
DETECTION
DISTANCE
DETECTION
MOVING SPEED
WORKING
TEMPERATURE
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 5 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product.
In case of any query/issue with the product, please reach out to us at: support@v-tac.eu
For More products range, inquiry please contact our distributor or nearest dealers.
V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B
INSTRUCTION MANUAL
VT-80360
23165
AC: 220-240V, 50/60 Hz
Max. 1200W
300W
+LED
Min. 10sec ±3sec
Max. 12min ±1min
360°
1-8m (Radius), Adjustable
0.6-1.5m/s
-20°C to +40°C
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code to
access the manual in multiple languages.
POWER
CONSUMPTION
AMBIENT LIGHT
INSTALLATION
HEIGHT
POWER
CONSUMPTION
DETECTION
MOTION SPEED
IP RATING
HF SYSTEM
DIMENSION
COMPATIBLE WITH
V-TAC LED
RANGE (UPTO 400W)
Approx, 0.5W
<3-2000 LUX (Adjustable)
1.5-3.5m
approx 0.9w
0.6-1.5 m/s
IP20
5.8Ghz CW Radar, ISM
Band
Ø80x66.6 mm
Advertisement
Related Manuals for V-TAC VT-80360
Summary of Contents for V-TAC VT-80360
- Page 1 TEMPERATURE INTRODUCTION & WARRANTY Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions carefully before starting the installation and keep this manual handy for future reference. If you have any another query, please contact our dealer or local vendor from whom you have purchased the product.
- Page 2 WARNING Please make sure to turn off the power before starting the installation. 2. Installation must be performed by a qualified electrician. 3. For Indoor use only This marking indicates that this prod- uct should not be disposed of with Caution, risk of electric shock.
- Page 3 CONNECTION-WIRE DIAGRAM TEST • Turn the LUX knob clockwise on the maximum (sun). Turn the SENS knob clockwise on the maximum (+). Turn the TIME knob anti-clockwise on the minimum (10s). • When you switch on the power, the light will be on at once. And 10sec±3sec later the light will be off automatically.
- Page 4 NOTES • Electrician or experienced human can install it. • Can not be installed on the uneven and shaky surface • In front of the sensor there shouldn’t be obstructive object affecting detection. • Avoid installing it near the metal and glass which may affect the sensor. •...
