INFRARED MOTION SENSOR CEILING MOUNT
TECHNICAL DATA
MODEL
SKU
INPUT VOLTAGE
RATED LOAD
DETECTION RANGE
DETECTION DISTANCE
TIME DELAY
AMBIENT LIGHT
INSTALLATION HEIGHT
WORKING TEMPERATURE
WORKING HUMINDITY
POWER CONSUMPTION
DETECTION MOTION
SPEED
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 5 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product. This product is
warranted for manufacturing defects only.
WARNING
1.
Please make sure to turn off the power before starting
the installation.
2.
Installation must be performed by a qualified electrician.
3.
For Indoor use only.
This marking indicates that this
product should not be disposed
of with other household wastes.
Caution, risk of electric shock.
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
INSTRUCTION MANUAL
VT-8027
23677
AC: 220-240V, 50/60Hz
Max 2000W
1000W
+LED
360°
7m max (<24°C)
Min. 10 sec ±3sec
Max. 15 min ±2min
<3-2000LUX (Adjustable)
2.2-4m
-20° ~+40°C
<93%RH
Approx >0.9W
0.6-1.5 m/s
IP RATING
MATERIAL
DIMENSION
IP20
PC
Ø115x24.3 mm
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
Advertisement
Related Manuals for V-TAC VT-8027
Summary of Contents for V-TAC VT-8027
- Page 1 Ø115x24.3 mm INTRODUCTION & WARRANTY Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions carefully before starting the installation and keep this manual handy for future reference. If you have any another query, please contact our dealer or local vendor from whom you have purchased the product.
- Page 2 FUNCTION • Can identify day and night: The consumer can adjust working state in different ambient light. It can work in the daytime and at night when it is adjusted on the “sun” position (max). It can work in the ambient light less than 3LUX when it is adjusted on the “3”...
- Page 3 SENSOR DIAGRAM Height of installation: 2.2-4m Detection Distance: Max 6m CONNECTION-WIRE DIAGRAM The wires come IN and OUT from bottom The wires come in and out from the side TEST • Turn the TIME knob anti-clockwise on the minimum (10s).Turn the LUX knob clockwise on the maximum (sun).
