TECHNICAL DATA
MODEL
SKU
INPUT VOLTAGE
RATED LOAD
TIME DELAY
DETECTION
RANGE
DETECTION
DISTANCE
DETECTION
MOTION SPEED
WORKING
TEMPERATURE
AMBIENT LIGHT
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 5 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product.
Caution, risk of electric shock.
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
In case of any query/issue with the product, please reach out to us at: support@v-tac.eu
For More products range, inquiry please contact our distributor or nearest dealers.
V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B
INSTRUCTION MANUAL
REAL PRESENCE SENSOR
VT-81013
23429
AC: 110-240V, 50/60 Hz
Max. 1200W
(220-240V/AC)
800W
(110-130V/AC)
600W
(220-240V/AC)
300W
(110-130V/AC)
Min. 10sec ±3sec
Max. 12min ±1min
360°
3m (radius)
0.6-1.5m/s
-20°C to +40°C
<3-2000 LUX (Adjustable)
+LED
COMPATIBLE WITH
V-TAC LED
RANGE (UPTO 600W)
INSTALLATION
HEIGHT
CUTOUT SIZE
DIMENSION
This marking indicates that this
product should not be disposed
of with other household wastes.
2-4m
Ø63x66mm
Ø76x66.2
mm
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for V-TAC VT-81013
Summary of Contents for V-TAC VT-81013
- Page 1 <3-2000 LUX (Adjustable) INTRODUCTION & WARRANTY Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions carefully before starting the installation and keep this manual handy for future reference. If you have any another query, please contact our dealer or local vendor from whom you have purchased the product.
- Page 2 WARNING Please make sure to turn off the power before starting the installation. 2. Installation must be performed by a qualified electrician. FUNCTION 1. Can identify day and night: It can work in the daytime and at night when it is adjusted on the “sun”...
- Page 3 TEST 1. Turn the LUX knob clockwise on the maximum (sun). Turn the TIME knob anti-clockwise on the minimum (10s). 2. When you switch on the power, the light will be on at once. And 10sec±3sec later the light will be off automatically.
