- Page 1 MULTIFUNCTIONAL DIGITAL COLOR SYSTEMS / MULTIFUNCTIONAL DIGITAL SYSTEMS Paper Preparation Guide...
- Page 2 © 2018 TOSHIBA TEC CORPORATION All rights reserved Under the copyright laws, this manual cannot be reproduced in any form without prior written permission of TTEC.
-
Page 3: Preface
Preface Thank you for purchasing TOSHIBA Multifunctional Digital Systems or Multifunctional Digital Color Systems. This manual describes how to load paper and place originals to use the copying functions of this equipment. Read this manual before using this equipment. How to read this manual ... -
Page 4: Optional Equipment
Model and series names in this manual In this manual, each model name is replaced with a series name as shown below: Model name Series name e-STUDIO2010AC/2510AC e-STUDIO5015AC Series e-STUDIO2515AC/3015AC/3515AC/4515AC/5015AC e-STUDIO2018A/2518A/3018A/3518A/4518A/5018A e-STUDIO5018A Series Optional equipment For the available options, refer to the Quick Start Guide. ... -
Page 5: Table Of Contents
CONTENTS Preface..............................3 How to read this manual ............................3 Chapter 1 LOADING PAPER Precautions for Paper ..........................8 Acceptable paper ................................. 8 Unacceptable copy paper ............................9 Precautions for storing copy paper .......................... 11 Loading Paper in Drawers ........................12 Drawer for this equipment ............................ - Page 6 6 CONTENTS...
- Page 7 LOADING PAPER This chapter explains how to set paper for this equipment. Precautions for Paper ......................8 Acceptable paper ..............................8 Unacceptable copy paper .............................9 Precautions for storing copy paper ........................11 Loading Paper in Drawers ....................12 Drawer for this equipment ..........................12 e-STUDIO2010AC/2510AC............................16 Envelope Drawer..............................19 Large Capacity Feeder ............................24 Doing Paper Settings ......................26...
-
Page 8: Precautions For Paper
Precautions for Paper Acceptable paper The paper that is acceptable differs depending on your model or the drawer to be used. To learn more about accepted paper and recommended paper, refer to the Specifications Guide. Do not place paper with mixed sizes or types in the same drawer. ... -
Page 9: Unacceptable Copy Paper
1.LOADING PAPER Unacceptable copy paper Do not use the types of paper listed below since they may cause paper misfeeds or an equipment malfunction. Damp paper Folded paper Curled or creased paper Paper whose surface is extremely smooth or rough ... - Page 10 1.LOADING PAPER Notes for using envelopes Do not use the following envelopes as they may cause paper misfeeding or damage to the equipment. Badly curled, wrinkled, folded or twisted envelopes Extremely thick or thin envelopes Wet or damp envelopes Torn envelopes Envelopes which include the contents Envelopes with a special shape...
-
Page 11: Precautions For Storing Copy Paper
1.LOADING PAPER Precautions for storing copy paper Make sure of the following when storing copy paper: Wrap the paper in its wrapping to keep it free from dust. Avoid direct sunlight. Store in a damp-free space. ... -
Page 12: Loading Paper In Drawers
Loading Paper in Drawers Follow the procedure below to place paper in the drawer, Paper Feed Unit, Paper Feed Pedestal, or Additional Drawer Module. For acceptable paper, refer to the Specifications Guide. Be careful not to let your fingers be caught when pushing the drawer into this equipment. This could injure you. - Page 13 1.LOADING PAPER Place paper in the drawer. e-STUDIO2515AC/3015AC/3515AC/4515AC/5015AC and e-STUDIO5018A Series The maximum number of sheets that can be loaded in a drawer differs depending on your model. Be sure that the height of the stacked paper does not exceed the line indicated inside of the side guides. For the maximum number of sheets that can be loaded, refer to the Specifications Guide.
- Page 14 1.LOADING PAPER Move the end guide to the trailing edge of the paper while pushing its lower part in the direction of the arrows. Check that there is no gap between the paper and the side guides, as well as the paper and the end guide.
- Page 15 1.LOADING PAPER The confirmation screen appears. If the status is correct, press [Yes]. The menu above may not appear depending on the setting of this equipment. If it is not, check that the correct paper size appears in the equipment status indication area on the menu screen. ...
-
Page 16: E-Studio2010Ac/2510Ac
1.LOADING PAPER e-STUDIO2010AC/2510AC For the Paper Feed Unit, Paper Feed Pedestal, or Additional Drawer Module, see the following page: P.12 “Drawer for this equipment” Pull out a drawer carefully until it comes to a stop. Press down the paper plate. Press it down until you hear a click sound and it is no longer lifted up. - Page 17 1.LOADING PAPER Place paper in the drawer. The maximum number of sheets that can be loaded in a drawer differs depending on your model. Be sure that the height of the stacked paper does not exceed the line indicated inside of the side guides. For the maximum number of sheets that can be loaded, refer to the Specifications Guide.
- Page 18 1.LOADING PAPER Change the paper size indicator if required. Push the drawer straight into this equipment carefully until it comes to a stop. Push the drawer into this equipment until you hear a click. The paper size is automatically detected. The confirmation screen appears.
-
Page 19: Envelope Drawer
1.LOADING PAPER Envelope Drawer In the envelope drawer, you can load envelopes as well as standard size paper such as A4. To learn more about accepted paper, refer to the Specifications Guide. For how to handle envelopes to load, see the following page: ... - Page 20 1.LOADING PAPER Load paper in the drawer. Load paper with its face up. Load an envelope with its bottom side at the rear and its flap side at the front. If the flap of the envelope touches the side guide, fold the flap and load the envelope. ...
- Page 21 1.LOADING PAPER Check that there is no gap between the paper and the side guides, as well as the paper and the end guide. If the gap is too wide, it could cause paper misfeeding, or the paper size could not be correctly detected. Between the paper and side guides (“A”...
- Page 22 1.LOADING PAPER Select the desired drawer and change the paper size. The acceptable standard envelope sizes are as follows: DL (110 mm x 220 mm), COM10 (4 1/8" x 9 1/2"), MONARCH (3 7/8" x 7 1/2"), CHO-3 (120 mm x 235 mm), YOU-4 (105 mm x 235 mm), and KAKU-2 (240 mm x 332 mm).
- Page 23 1.LOADING PAPER When printing on envelopes with the e-STUDIO2010AC/2510AC When you copy or print on envelopes with the e-STUDIO2010AC/2510AC, some kinds of envelope may get wrinkled after printed. In this case, you can ease the wrinkle by operating this equipment following the procedure below. Open the automatic duplexing unit cover on the right.
-
Page 24: Large Capacity Feeder
1.LOADING PAPER How to replace the fuser pressure release lever Open the automatic duplexing unit cover on the right. Press down the two green fuser pressure release levers. Slide the two gray levers to the side, and then lift the two green fuser pressure release levers. Close the automatic duplexing unit cover. - Page 25 1.LOADING PAPER Push the drawer of the Large Capacity Feeder straight into this equipment carefully. When the drawer is completely inserted, the right-hand tray will move up to the paper feeding position. Be careful not to let your fingers be caught when pushing the drawer into this equipment. This could injure you.
-
Page 26: Doing Paper Settings
Doing Paper Settings Setting paper size The paper size is automatically detected when the paper is loaded in a drawer. To automatically detect the size of paper placed in a drawer: Press [User Functions -User-] on the Home screen > [Drawer] and select the desired drawer on the displayed screen. Select [Auto (mm)] when A/B format paper is loaded and [Auto (inch)] when LT format paper is loaded. - Page 27 1.LOADING PAPER Setting paper with non-standard sizes Press [User Functions -User-] on the Home screen. Press the [User] tab > [Drawer]. Select the desired drawer and press [Custom]. Enter the size and press [OK]. Doing Paper Settings 27...
-
Page 28: Setting Paper Type
1.LOADING PAPER Setting paper type When you place any special paper other than plain paper or that not used for normal copying, you need to set the thickness and attribute into this equipment. For acceptable paper type, refer to the Specifications Guide. If you select a wrong paper type, this could cause a paper misfeed, significant image trouble or an equipment malfunction. - Page 29 1.LOADING PAPER Thickness (Bypass Tray) Icon Thickness Icon Thickness — Plain Transparency Recycled Paper Thin Thick *2, *3 Special 1 *2, *3 Special 2 Thick 1 Thick 2 *1, *2, *3 Special 3 Thick 3 Envelope *1, *3 Thick 4 Usertype *1 These types of paper cannot be accepted for the e-STUDIO2010AC/2510AC.
- Page 30 1.LOADING PAPER If paper cannot be fed, printing takes a long time after feeding or the quality is poor, turn over the paper and place it again as shown in the figure or place fewer sheets. The thickness and attribute can be set together. ...
-
Page 31: Clearing The Set Paper Type
1.LOADING PAPER Press [Paper Type]. Select the desired drawer and paper type and press [OK]. Press [OK]. There is no affect on the printing quality though noise may occur during paper feeding depending on the paper type. Clearing the set paper type Press the drawer button on the menu in step 4 of “Setting paper type”, and then press the paper type whose setting you want to clear. -
Page 32: Loading Paper On The Bypass Tray
Loading Paper on the Bypass Tray When you make copies on OHP film, sticker labels, envelopes, Thick 4 paper, or non-standard size paper, load the copy paper on the bypass tray. Using the bypass tray is also recommended for copying or printing on standard size paper which is not set in any of the drawers. - Page 33 1.LOADING PAPER When placing or removing copy paper, move the paper holding lever toward the outside. After loading paper, move the paper holding lever back toward the equipment. If paper cannot be fed, printing takes a long time after feeding or the quality is poor, turn over the paper and place it again as shown in the figure or place fewer sheets.
-
Page 34: Standard Size Paper On The Bypass Tray
1.LOADING PAPER Standard size paper on the bypass tray Automatic 2-sided printing cannot be applied to some kind of paper in the bypass tray. For the paper which Automatic 2-sided printing cannot be applied to, refer to the Specifications Guide. ... - Page 35 1.LOADING PAPER Check that there is no gap between the paper and the side guides. If the gap is too wide, it could cause paper misfeeding, or the paper size could not be correctly detected. Between the paper and side guides (“A” in the figure): Make sure there is no gap.
-
Page 36: Envelopes On The Bypass Tray
1.LOADING PAPER Envelopes on the bypass tray For acceptable envelope, refer to the Specifications Guide. For how to handle envelopes to load, see the following page: P.10 “Notes for using envelopes” When you use a drawer of the e-STUDIO2010AC/2510AC, see the following page before performing the procedure below: ... - Page 37 1.LOADING PAPER Align the side guides to the length of the envelope. Move the paper holding lever toward the equipment. Check that there is no gap between the paper and the side guides. If the gap is too wide, it could cause paper misfeeding, or the paper size could not be correctly detected. Between the paper and side guides (“A”...
-
Page 38: Tab Paper On The Bypass Tray
1.LOADING PAPER Tab paper on the bypass tray You can print on the tab extension of tab paper. For acceptable tab paper, refer to the Specifications Guide. Move the paper holding lever toward the outside. Place paper with its print side down on the bypass tray. -
Page 39: Non-Standard Paper On The Bypass Tray
1.LOADING PAPER Non-standard paper on the bypass tray You can also copy or print non-standard size paper. For paper size which can be set, refer to the Specifications Guide. To learn how to set the paper size, refer to the Copying Guide or Printing Guide. Move the paper holding lever toward the outside. -
Page 40: Long Custom Size Paper On The Bypass Tray
1.LOADING PAPER Long custom size paper on the bypass tray In the printing function, you can also print the paper longer than the maximum standard paper size by setting it as a custom size. For paper size which can be set, refer to the Specifications Guide. To learn how to set the custom size, refer to the Printing Guide. - Page 41 1.LOADING PAPER Do not mix different sizes of paper. Feed paper sheet by sheet from the bypass tray if you have set more than one copy in the number of copies setting. Slightly curl the paper. Hold it gently as it is being fed into the equipment. ...
- Page 42 1.LOADING PAPER 42 Loading Paper on the Bypass Tray...
-
Page 43: Placing Originals
PLACING ORIGINALS This chapter explains how to place originals on this equipment. Precautions for Originals ....................44 Acceptable originals ............................44 Unacceptable originals............................45 Placing Originals ......................46 Placing originals on the original glass ........................46 Book-type originals..............................47 Using the ADF ...............................48... -
Page 44: Precautions For Originals
Precautions for Originals Acceptable originals When the ADF (RADF or DSDF) is used, 2-sided originals can be automatically scanned one sheet after another. When the original glass is used, originals such as OHP films, tracing paper, booklet or 3-dimensional objects, that cannot be placed on the ADF can be scanned, as well as plain paper. -
Page 45: Unacceptable Originals
2.PLACING ORIGINALS Unacceptable originals Notes for using the ADF Do not load the types of originals shown below (1 to 10) in the ADF because such originals may cause misfeeding or damage to the equipment. Badly wrinkled, folded or curled originals Originals with carbon paper Taped, pasted or cut-out originals Originals with multiple perforations such as loose leaf paper... -
Page 46: Placing Originals
Placing Originals Placing originals on the original glass The original glass can be used for originals such as OHP films or tracing paper, as well as plain paper, which cannot be loaded in the ADF. Do not place any heavy objects (4 kg (9 lb.) or over) on the original glass and do not press on it with force. Breaking the glass could injure you. -
Page 47: Book-Type Originals
2.PLACING ORIGINALS Lower the Original Cover or the ADF carefully. The original size is sometimes not detected correctly. To prevent this, slowly and gently close the Original Cover or the ADF. When it is being closed, the scanner lamp flashes to detect the original size. ... -
Page 48: Using The Adf
2.PLACING ORIGINALS Using the ADF Precautions for using the ADF Do not load unacceptable originals in the ADF. P.45 “Unacceptable originals” If you scan mixed-size originals at a time or scan some types of paper of originals using the ADF, a distortion may occur on your scan result. - Page 49 2.PLACING ORIGINALS Scanning originals with the ADF Place originals on the ADF. Align all the originals. Collate the originals in the order that you want them to be copied. The top sheet of the originals will be copied first. Place the originals with their face up and align the side guides to the original length.
- Page 50 2.PLACING ORIGINALS When there are too many originals to be scanned at one time, divide the originals into several sets before copying. Place the first set of the originals and then press [Continue] on the touch panel while the data of this set are being scanned.
- Page 51 2.PLACING ORIGINALS If there is another original, insert it in the same way. After all the originals are pulled in, press [Job Finish]. If you want to stop copying, press [Job Cancel]. Scanning mixed-size originals in one operation You can copy or scan a set of originals whose sizes are individually different, using the ADF with the mixed size function.
- Page 52 2.PLACING ORIGINALS 52 Placing Originals...
-
Page 53: Operating Stapling Manually
OPERATING STAPLING MANUALLY This chapter explains how to operate manual stapling using the Finisher or the Saddle Stitch Finisher. Stapling Using the Finisher....................54... -
Page 54: Stapling Using The Finisher
Stapling Using the Finisher You can staple copied paper manually without any copying operation. This is useful when you have forgotten to set the staple sort mode before starting copying, or when you want to staple originals. For models supporting the manual staple mode and the maximum sheets that can be stapled for each model, refer to the Specifications Guide. -
Page 55: Index
INDEX A/B format ................. 4 Paper ADF (Automatic Document Feeder) ......... 4 paper size setting ............26 precautions ..............48 paper type setting............28 unacceptable originals..........45 placing ..............12, 24 using the ADF ............... 48 precautions for storing copy paper......11 Automatic Document Feeder (ADF) registering paper size .......... - Page 56 56 INDEX...
- Page 57 FC-2010AC/2510AC FC-2515AC/3015AC/3515AC/4515AC/5015AC DP-2018A/2518A/3018A/3518A/4518A/5018A OME170046A0...
- Page 58 MULTIFUNCTIONAL DIGITAL COLOR SYSTEMS / MULTIFUNCTIONAL DIGITAL SYSTEMS Paper Preparation Guide 1-11-1, OSAKI, SHINAGAWA-KU, TOKYO, 141-8562, JAPAN R171020T5100-TTEC Ver01 F Issued in Aug. 2018 © 2018 TOSHIBA TEC CORPORATION All rights reserved Patent; http://www.toshibatec.com/en/patent/...
