Dräger Medical Fabius GS Technical & Service Manual

Dräger Medical Fabius GS Technical & Service Manual

Hide thumbs Also See for Fabius GS:

Advertisement

Quick Links

Download this manual
RETURN TO THIS MANUAL'S TABLE OF CONTENTS
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO CD-ROM TABLE OF CONTENTS
Anesthesia System
Technical
Service
Manual
Part Number: 4117104
Rev: K
Date: 20 February 2004
© 2004 Draeger Medical, Inc.
Fabius GS
®

Advertisement

loading
Need help?

Need help?

Do you have a question about the Fabius GS and is the answer not in the manual?

Questions and answers

Related Manuals for Dräger Medical Fabius GS

Summary of Contents for Dräger Medical Fabius GS

  • Page 1 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS Technical Service Manual Part Number: 4117104 Rev: K Date: 20 February 2004 © 2004 Draeger Medical, Inc. Fabius GS ® Anesthesia System...
  • Page 2 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS...

  • Page 3: Table Of Contents

    FUNCTION DESCRIPTION ..........2-1 General Information about the Fabius GS ......2-1 Fabius GS Function Diagram .
  • Page 4 PMS PROCEDURE, FABIUS GS ........
  • Page 5 Updating Send Image (utility) file........8-5 INSTALLING FABIUS GS SOFTWARE FROM A PC ....8-5 Boot Strap Download Procedure .
  • Page 6 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS ANESTHESIA SYSTEM DISPLAY AUXILIARY OXYGEN FLOWMETER CONTROL PANEL VENTILATOR VAPORIZER BREATHING SYSTEM CYLINDER PRESSURE GAUGES PIPELINE O2 FLUSH PRESSURE...

  • Page 7: Recommendations

    After any component is replaced, verify that the unit is operating properly by running the appropriate diagnostic procedure. The PMS PROCEDURE in Section 7 must also be performed after any component is replaced. The general arrangement of the Fabius GS anesthesia system is shown on the opposite page.
  • Page 8 Trademark Notices Datagrip, DrägerService, ORM, Quality Service For Life, Respitone, Narkomed, Vigilance Audit, Vitalert, Vitalink, Narkomed GS, Fabius, and Fabius GS are registered trademarks of Draeger Medical, Inc. All other products or name brands are trademarks of their respective owners.

  • Page 9: Function Description

    Monitoring, Electrical and Gas connections are illustrated on following pages. AUXILIARY DISPLAY OXYGEN FLOWMETER CONTROL PANEL VENTILATOR VAPORIZER BREATHING CYLINDER SYSTEM PRESSURE GAUGES PIPELINE PRESSURE GAUGES O2 FLUSH FLOW CONTROLS TROLLEY TOTAL FRESH GAS FLOWMETER SV00543 Figure 2-1. Front View of Fabius GS Anesthesia System...
  • Page 10 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) SV00457 SERIAL COMMUNICATION PORT HOSE CONNECTION FOR PEEP VALVE HOSE CONNECTION FOR APL BYPASS VALVE O2 SENSOR...
  • Page 11 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) SV00505 PIPELINE HOSE CONNECTIONS O2 CYLINDER YOKE N2O OR AIR CYLINDER YOKE O2 CYLINDER YOKE Figure 2-3. Back View Showing Gas Pipeline and Cylinder Yokes...
  • Page 12 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) N2O CYLINDER CONNECTION O2 CYLINDER CONNECTION PIPELINE HOSE CONNECTIONS SV00551 Figure 2-4. Back View Showing Gas Pipeline and Cylinder Hose Connections...

  • Page 13: Fabius Gs Function Diagram

    P VENT BREATHING (AIR ENTRAINMENT) ABSORBER PEEP EXPIRATORY CONTROL VALVE VALVE APL VALVE ELECTRONIC SPONT PEEP VALVE BYPASS VALVE PISTON PUMP SV88038 SCAVENGER OUTLET Figure 2-5. Function diagram of Fabius GS - Typical for Breathing System P/N 4116398 or 4117529...
  • Page 14 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) SV77028 Figure 2-6. Function diagram of Fabius GS - Typical for Breathing System P/N 4118378 or 4118379...

  • Page 15: Battery Backup

    FUNCTION DESCRIPTION (continued) Battery Backup Fabius GS backup power is provided by two series-connected 12 V rechargeable batteries. These batteries remain on charge as long as the machine is plugged into an active AC outlet. Should power to the main controller PCB assembly fail...

  • Page 16: Fabius Gs Piping Diagram

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) Fabius GS Piping Diagram SV00454 Figure 2-8. Fabius GS Piping Diagram...

  • Page 17: Function Description Of Gas Box

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) Function Description of Gas Box The supply gases flow through the filters and non-return valves in the gas inlet assembly.
  • Page 18 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) If the O flush button is pressed, oxygen is delivered to the fresh gas outlet. The fresh-gas ejector prevents the fresh gas from flowing back into the anesthetic vaporizer.

  • Page 19: Sorc (Sensitive Oxygen Ratio Controller)

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) SORC (Sensitive Oxygen Ratio Controller) The SORC is a control element that functions like an N...
  • Page 20 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) The flow control valves are used to adjust the O and N O flows. Restrictors located at the outlets of the SORC generate back-pressures. These back-pressures exert a force on the control diaphragms of the SORC.

  • Page 21: Compact Breathing System, Cosy Ii

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) Compact Breathing System, Cosy II The Cosy II compact breathing system allows various modes of patient ventilation: manual and spontaneous breathing, volume controlled, and pressure controlled.
  • Page 22 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) SV00493 Figure 2-13. Compact breathing system, CosyII - Typical for P/N 4116398 or 4117529 PEEP/Pmax valve...
  • Page 23 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) SV77029 Figure 2-14. Compact breathing system, CosyII - Typical for P/N 4118378 or 4118379 PEEP/Pmax valve...
  • Page 24 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) 2.7.1 Function Description: Manual Ventilation Manual Ventilation: General During manual ventilation, the APL valve is set to the "MAN" position.
  • Page 25 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) SV77030 XYGEN SENSOR PRESSURE SENSOR FLOW SENSOR INSPIRATORY VALVE OPEN PEEP/PMAX VALVE OPEN VENTILATOR FRESH GAS...
  • Page 26 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) Manual Ventilation: Expiration - Typical for Breathing System P/N 4116398 or 4117529 During expiration, the inspiratory valve remains closed and thus prevents the expiratory gas from flowing back into the inspiratory branch.
  • Page 27 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) Manual Ventilation: Expiration - Typical for Breathing System P/N 4118378 or 4118379 During expiration, the inspiratory valve remains closed and thus prevents the expiratory gas from flowing back into the inspiratory branch.
  • Page 28 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) 2.7.2 Function Description: Spontaneous Breathing Spontaneous Breathing: General A prerequisite for spontaneous breathing is that the patient is supplied with a sufficient amount of fresh gas.
  • Page 29 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) SV77032 OXYGEN SENSOR PRESSURE SENSOR FLOW SENSOR INSPIRATORY VALVE OPEN PEEP/PMAX VALVE OPEN VENTILATOR FRESH GAS...
  • Page 30 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) Spontaneous Breathing: Expiration - Typical for Breathing System P/N 4116398 or 4117529 During expiration, the inspiratory valve remains closed thus preventing the expiratory gas from flowing back into the inspiratory branch.
  • Page 31 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) Spontaneous Breathing: Expiration - Typical for Breathing System P/N 4118378 or 4118379 During expiration, the inspiratory valve remains closed thus preventing the expiratory gas from flowing back into the inspiratory branch.
  • Page 32 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) 2.7.3 Function Description: Volume/Pressure Mode Ventilation Volume Control Mode: General A prerequisite for volume control is that the patient is supplied with a sufficient amount of fresh gas.
  • Page 33 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) Volume/Pressure Control Mode: Inspiration During inspiration, the PEEP/Pmax valve remains closed. The control pressure present at the PEEP/Pmax valve varies with the set pressure limit (Pmax).
  • Page 34 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) SV77034 OXYGEN SENSOR PRESSURE SENSOR FLOW SENSOR INSPIRATORY VALVE OPEN PEEP/PMAX VALVE VARIABLE VENTILATOR FRESH GAS...
  • Page 35 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) Volume/Pressure Control Mode: Expiration During expiration, the inspiratory valve remains closed thus preventing rebreathing into the inspiratory branch.
  • Page 36 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) SV77035 OXYGEN SENSOR PRESSURE SENSOR FLOW SENSOR INSPIRATORY VALVE CLOSED PEEP/PMAX VALVE OPEN VENTILATOR FRESH GAS...
  • Page 37 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) 2.7.4 Cosy II Absorber The absorber canister is filled with fresh soda lime. The soda lime scrubs from the respiratory expired gas.

  • Page 38: Ventilator

    The ventilator is located in a swing-out compartment at the left side of the Fabius GS. A hose terminal is provided on the left side of the compartment for connection to the breathing system. Fresh gas is delivered to the patient by a piston that is driven by a motor and ball-screw arrangement.
  • Page 39 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) NEGATIVE PRESSURE RELIEF VALVE VENT CHAMBER PRESSURE HIGH PRESSURE SENSOR LINE VALVE VACUUM LINE TO PNEUMATIC...
  • Page 40 Negative Pressure Relief Valve The negative pressure relief valve allows the patient to spontaneously breathe ambient air should the medical gas supply and/or Fabius GS fail. The opening pressure of this valve is indicated in the table below. threaded ring...

  • Page 41: Pneumatic System

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) Pneumatic System The pneumatic assembly provides pressure for the PEEP valve control, and also provides vacuum for the ventilator bag-type rolling seals and the APL bypass valve control.
  • Page 42 FUNCTION DESCRIPTION (continued) 2.9.1 PEEP/Pmax Valve Control When the Fabius GS is operating in the automatic mode, the pump on the pneumatic assembly is running, and the electronic PEEP valve receives a signal from the main control PCB. The amount of current...

  • Page 43: Electrical Block Diagram

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) 2.10 Electrical Block Diagram FLOW METER BEZEL ASM FRESH LOW O2 SV88046 PRESS DISPLAY PNEUMATIC ASM...

  • Page 44: Function Description: Control Pcb

    FABIUS GS FUNCTION DESCRIPTION (continued) 2.11 Function Description: Control PCB The control PCB provides the following functions in the Fabius GS: 2.11.1 Flowmeter Receives flow rate data from the N2O, Air, and O2 flow sensors and provides fresh gas display information for these gases.
  • Page 45 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) SV88047 FLASH BUFFER XCVR LATCH FRESH GAS DISPLAY FRESH GAS FLOW SENSORS DISPLAY VIDEO PANEL CONTROL...

  • Page 46: Control Panel Assembly

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) 2.12 Control Panel Assembly The control panel assembly consists of a 320 x 240 pixel graphical display, a table lamp with six LEDs, a membrane keypad, rotary encoder and speaker.
  • Page 47 Parameters Pressure Standard Options Secure Options PEEP Figure 2-34. Fabius GS Control Panel (Main Service Screen Illustrated) Item Function Selects volume controlled ventilation mode. Refer to Operator’s Manual Selects pressure controlled ventilation mode. Refer to Operator’s Manual Reserved for future use...

  • Page 48: Fio2 Measurement

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) 2.13 FiO2 Measurement The O sensor measures the fraction of inspired O (FiO ) in the respiratory gas.

  • Page 49: Respiratory Flow Measurement

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) 2.14 Respiratory Flow Measurement The flow sensor functions according to the constant temperature hot-wire anemometer principle. Respiratory gas flows past a thin platinum wire. This platinum wire (A) is located in a measuring tube and is electrically heated.

  • Page 50: Gas Flow Rate Measurement

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) 2.15 Gas Flow Rate Measurement The gas flow sensors operate on the principle of specific heat for individual gases.

  • Page 51: Vaporizer

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS FUNCTION DESCRIPTION (continued) 2.16 Vaporizer Refer to separate technical documentation of the anesthetic vaporizer. 2-43...
  • Page 52 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS...

  • Page 53: Troubleshooting

    Power Supply and Voltage Distribution In the Fabius GS, the power supply delivers 28 VDC to the main controller unit PCB assembly. Some of the other voltages derived on this assembly can be measured at the connectors listed in Table 3-1. Fuse data is listed in Table 3-2.
  • Page 54 O2 SENSOR PUMP SPIROLOG VOL SENSOR MAIN CONTROLLER PCB ASSEMBLY FRONT MOTOR PANEL DISPLAY TACH SENSOR KEYPAD INTERFACE HOME SENSOR VENTILATOR TABLE LAMP BOOST ON/OFF CAPS ROTARY ENCODER BATT POWER MAINS SUPPLY PWR ENTRY FIGURE 3-1. Fabius GS Block Diagram (Electrical)
  • Page 55 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS TROUBLESHOOTING GUIDE (continued) J18 SPIROLOG SENSOR J17 O2 SENSOR J2 FRONT PANEL DISPLAY J9 KEYPAD INTERFACE J15 SERIAL PORT...
  • Page 56 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS TROUBLESHOOTING GUIDE (continued) FABIUS GS FRONT PANEL KEYPAD SERIAL PORT DISPLAY INTERFACE INTERFACE SPIROLOG VENT SENSOR CHAMBER PRESSURE SENSOR O2 SENSOR...
  • Page 57 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS TROUBLESHOOTING GUIDE (continued) SV00454 FIGURE 3-4. Fabius GS Piping Diagram...
  • Page 58 TO UPPER PORT OF LS1 ON PCB ASM SV88048 VENT CHAMBER PRESSURE PNEUMATIC ASSEMBLY VENTILATOR ELECTRONIC PEEP VALVE PUMP RESERVOIR APL BYPASS VALVE PEEP VALVE INTERFACE BREATHING CONTROL SIGNAL PANEL SYSTEM FROM J7 ON PCB ASM FIGURE 3-5. Fabius GS Pneumatic Control Diagram...

  • Page 59: Battery

    Troubleshooting Guides Table 3-3 lists common failure modes and symptoms (excluding simultaneous multiple faults) for the monitoring and display devices in the Fabius GS. Each failure mode or symptom is keyed to a troubleshooting guide flow chart at the back of this section to assist the service representative in locating the cause of a problem.
  • Page 60 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS TROUBLESHOOTING GUIDE (continued) GUIDE 1: Loss of O Monitor START SV77001 IS O2 MONITOR WORKING PROPERLY CONNECT SENSOR CORD TO...
  • Page 61 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS TROUBLESHOOTING GUIDE (continued) FABIUS GS GUIDE 2: Loss of Breathing Pressure Monitor START SV77002 BREATHING PRESSURE MONITOR WORKING PROPERLY? CHECK PILOT LINE...
  • Page 62 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS TROUBLESHOOTING GUIDE (continued) GUIDE 3: Loss of Respiratory Volume Monitor START RESPIRATORY SV77003 VOLUME MONITOR WORKING PROPERLY? CONNECT SENSOR...
  • Page 63 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS TROUBLESHOOTING GUIDE (continued) FABIUS GS GUIDE 4: No Audio Alarms START SV77004 AUDIO ALARMS WORKING? CHECK CABLE FROM J1 ON FRONT PANEL...
  • Page 64 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS TROUBLESHOOTING GUIDE (continued) GUIDE 5: Serial Port Communication Failure START SV77005 DOES HOST UNIT COMMUNICATE WITH PERIPHERAL DEVICE? CONNECT...
  • Page 65 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS TROUBLESHOOTING GUIDE (continued) FABIUS GS GUIDE 6: No O Supply Pressure Alarms START SV77006 LOW O2 SUPPLY PRESSURE ALARM FUNCTIONAL? VERIFY NO O2...
  • Page 66 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS TROUBLESHOOTING GUIDE (continued) GUIDE 7: Main Display Blank Upon System Power-up START IS DISPLAY FUNCTIONAL UPON SYSTEM POWER-UP? SV77007...
  • Page 67 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS TROUBLESHOOTING GUIDE (continued) FABIUS GS GUIDE 8: Keypad Inoperative START SV77008 KEYPAD WORKING PROPERLY? CHECK ALL KEYS FOR TACTILE FEEDBACK CHECK CABLE FROM J1...
  • Page 68 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS TROUBLESHOOTING GUIDE (continued) GUIDE 9: Ventilator Inoperative START SV77009 IS VENTILATOR WORKING PROPERLY? VERIFY GASKET, VENTILATOR COVER, EXTERNAL HOSE...
  • Page 69 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS TROUBLESHOOTING GUIDE (continued) FABIUS GS GUIDE 10: Fresh Gas Display Blank or Not Working Properly START ARE ALL FRESH GAS DISPLAYS...
  • Page 70 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS...

  • Page 71: Diagnostics

    Standby screen. The power-up screen also displays one of three messages at completion of the diagnostics: FUNCTIONAL: This message indicates that the Fabius GS has passed all power-up tests and is fully functional. The machine will 4-2.) after a short...
  • Page 72 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) The following quick reference tree is for use in quickly locating the Service Screens necessary to perform specific functions within the software. The indentions shown below indicates the relationship of the Service Screen/function relative to the location of each Service Screen within the software.

  • Page 73: System Diagnostics

    System RAM Pass Program Memory Pass Video Test Pass Interrupts Pass A/D Converter Pass NV RAM Pass Serial Port Pass Clock Pass Speaker Pass Main Power Pass Battery Pass Fabius GS SW XXX CRC XXX Figure 4-1. Power-up Diagnostics Screen...
  • Page 74 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) Figure 4-2. Standby Screen Further diagnostic functions are available through service screens that can be called up at the display panel. The following paragraphs provide a description of each service screen that can be accessed at the display.

  • Page 75: System Service Screen

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) System Service Screen Figure 4-3. The System Service Screen shown in displays system service data. Press the rotary knob to go to the Main Service screen.

  • Page 76: Main Service Screen

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) Main Service Screen Figure 4-4. The Main Service Screen shown in lists the service functions available under each of the displayed categories.

  • Page 77: Service Log

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) Service Log Figure 4-5. When the Service Log category is selected, the screen shown in will appear.
  • Page 78 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) 4.3.1 Service Log Entries Figure 4-6. When Entries is selected, the screen shown in appears. Use the rotary knob to scroll through the list of service log entries. The service log holds up to 256 entries.
  • Page 79 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) Fabius GS Service Log Entries: Table 4-1: Communication Errors Code Description Possible Cause C001 Handler Busy Bad processor, external device incorrect operation...
  • Page 80 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) Table 4-3: Diagnostic Errors Code Description Possible Cause F001 Diag Watchdog Bad hardware F002 Diag System Ram System RAM fails on pwr up, bad RAM chip, bad CPU, bad trace, etc.
  • Page 81 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) Table 4-4: System Errors Code Description Possible Cause PS02 -2.5V Supply Failure Bad Processor Board PS03 +12V Supply Failure...
  • Page 82 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) Table 4-7: Ventilator Errors Code Description Possible Cause V001 VENT PEEP NOT CAL Auto ventilation was attempted without valid PEEP...
  • Page 83 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) 4.3.2 Real Time Values Figure 4- When Real Time Values is selected, the typical screen shown in appears.
  • Page 84 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) Table 4-9: Table 4-10: Refer to for Battery/Charger Status error message list and for PSC (Power Supply Controller) error message list as shown on the following screen.
  • Page 85 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) Table 4-8: Real Time Values Screen Key and Acceptable Range Data Label Description Acceptable Range (AD) Pressure Sensor Calib. value...
  • Page 86 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) Table 4-9: Battery/Charger Status Error Message List Message Description Condition Charger OFF The PSC has detected a +28V supply...

  • Page 87: Preventive Maintenance

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) Preventive Maintenance When the Preventive Maintenance category is selected, the screen shown in Figure 4-9. will appear.
  • Page 88 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) 4.4.1 Activate Preventive Maintenance Date Figure 4-10. With Activate selected, the screen will appear as shown in Turn the rotary knob to position the box under Mth and press the knob to highlight the box.

  • Page 89: General

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) General Figure 4-11. When the General category is selected, the screen shown in will appear. Turn the rotary knob to scroll down to select the desired function, then press the knob to confirm.
  • Page 90 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) 4.5.1 Serial Number When Serial Number is selected, the screen will appear as shown in Figure 4-12.
  • Page 91 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) 4.5.2 Reset Hours Run When Reset Hours Run is selected, the screen will appear as shown in Figure 4-13.
  • Page 92 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) 4.5.3 Reset Last Service Date When Reset Last Service Date is selected, the screen will appear as Figure 4-14.
  • Page 93 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) 4.5.4 Select Market Kit When Select Market Kit is selected, the screen will appear as shown in Figure 4-15.
  • Page 94 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) Figure 4-16. Select Market Kit Screen (Non-US) To return to the General category screen, scroll to the press the knob.

  • Page 95: Calibration

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) Calibration Figure 4-17. When the Calibration category is selected, the screen shown in will appear. Turn the rotary knob to scroll down to select the desired function, then press the knob to confirm.
  • Page 96 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) 4.6.1 Fresh Gas Flow Calibration Figure 4-18. When Fresh Gas Flow is selected, the screen shown in appears.
  • Page 97 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) 4.6.2 Pressure Calibration Figure 4-19. When Pressure is selected, the screen shown in appears. Follow the on-screen instructions to perform the calibration. The Store Zero and Exit keys are located just below their legends at the bottom of the screen.
  • Page 98 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) 4.6.3 O2 Zero Calibration Figure 4-20. When O2 is selected, the screen shown in appears. Follow the on-screen instructions to perform the calibration. The Store Zero and Exit keys are located just below their legends at the bottom of the screen.
  • Page 99 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) 4.6.4 PEEP Valve Calibration Figure 4-21. When PEEP is selected, the screen shown in appears. NOTE: Before performing the PEEP valve calibration, a valid pressure calibration must be performed.

  • Page 100: Configure

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) Configure Figure 4-22. When the Configure category is selected, the screen shown in will appear. Turn the rotary knob to scroll down to select the desired function, then press the knob to confirm.
  • Page 101 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) 4.7.1 System Settings (US and Non-US) Figure 4-23. When the System Settings category is selected, the screen shown in 4.7.1.1...
  • Page 102 Turn the rotary knob to scroll down to select the model type ‘Fabius GS’, then press the knob to confirm. NOTE: Machines from the factory are configured with the appropriate model type. Other than performing a software download or PCB replacement, the model type should not be changed.
  • Page 103 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) 4.7.2 Standard Options When the Standard Options category is selected, the screen shown in Figure 4-25. will appear.
  • Page 104 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) 4.7.2.1 Flowmeter When Flowmeter is selected, the screen shown in one of the following illustrations will appear. Turn the knob to scroll down to the desired selection, and press the knob to enter that function.
  • Page 105 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) 4.7.2.1.1 O2 Position (Virtual Flowtubes) When O2 Position for virtual flowtubes is selected, Figure 4-27. the screen will appear as shown in...
  • Page 106 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) 4.7.2.1.2 Gas Selection When Gas Selection is chosen, the screen will appear Figure 4-28. as shown in...
  • Page 107 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) 4.7.2.1.3 Flowtube Resolution When Flowtube Resolution is chosen, the screen will Figure 4-29. appear as shown in...
  • Page 108 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) 4.7.2.2 O2 Whistle Figure 4- When O2 Whistle is chosen, the screen will appear as shown in Turn the rotary knob to select Change State, and press the knob to highlight the choices.
  • Page 109 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) 4.7.2.3 Alarms Figure 4-31. When Alarms is selected, the screen shown in will appear. Turn the knob to scroll down to the desired selection, and press the knob to enter that function.
  • Page 110 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) 4.7.2.3.1 No Fresh Gas When No Fresh Gas is chosen, the screen will appear Figure 4-32. as shown in...
  • Page 111 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) 4.7.2.3.2 Fresh Gas Low Alarm When Fresh Gas Alarm is chosen, the screen will Figure 4-33. appear as shown in...
  • Page 112 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) 4.7.2.3.3 Threshold Low Alarm When Threshold Low Alarm is chosen, the screen Figure 4-34. will appear as shown in...
  • Page 113 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) 4.7.2.4 Pressure Figure 4-35. When Flowmeter is selected, the screen shown in will appear. Turn the knob to scroll down to the desired selection, and press the knob to enter that function.
  • Page 114 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) 4.7.2.4.1 Ambient Pressure When Ambient Pressure is chosen, the screen will Figure 4-36. appear as shown in Turn the rotary knob to select Adjust, and press the knob.
  • Page 115 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) 4.7.2.4.2 Plateau-Mean Display Screen The breathing pressure monitor window can display Mean airway pressure or Plateau airway pressure.
  • Page 116 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) 4.7.3 Secure Options Figure When the Secure Options category is selected, the screen shown in 4-38. will appear.
  • Page 117 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) Serial Port Figure 4-39. When the Serial Port category is selected, the screen shown in will appear.
  • Page 118 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) 4.8.1 Serial Port Parameters Figure 4- With Parameters selected, the screen will appear as shown in Turn the rotary knob to select the parameter you want to set, and press the knob to highlight that parameter.
  • Page 119 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS DIAGNOSTICS (continued) Pump On/Off The pump on/off softkey provides the ability to toggle the pump ON or OFF as part of the troubleshooting and diagnostics process.
  • Page 120 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS...

  • Page 121: Replacement Procedures

    REPLACEMENT PROCEDURES REPLACEMENT PROCEDURES This section outlines removal and replacement procedures for the field-replaceable assemblies of the Fabius GS Anesthesia System. These procedures are to be performed only by a qualified technical service representative (TSR). The following are the only procedures authorized by DrägerService to be performed in the field.

  • Page 122: Cylinder Yokes And Regulators

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS NOTE: The following procedure will require making adjustments and calibrations with the possibility of removal of accessories and/or additional monitoring equipment.
  • Page 123 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) BOTTOM VIEW SV00472 N2O OR AIR REGULATOR YOKE MOUNTING O2 REGULATOR SCREWS AND LOCK WASHERS (2X PER YOKE)
  • Page 124 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS 5.1.12 Reattach the yoke to the machine with the hardware previously removed. 5.1.13 If a new cylinder is being installed, remove the old sealing washer from the gas inlet of the yoke and install a new washer.

  • Page 125: Cylinder Pressure Gauges

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) Cylinder Pressure Gauges Each pressure gauge is secured by two 6-32 kep nuts As shown in Figure 5-2.

  • Page 126: Tubing Connection

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS 5.2.13 Perform the following leak test: NOTE: The cylinder used for this test must contain the following minimum pressure: 5.2.13.1...

  • Page 127: Auxiliary Oxygen Flow Meter

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) Auxiliary Oxygen Flow Meter The auxiliary oxygen flowmeter is attached to the outside of the ventilator door on the left side of the machine, by a stud and nut arrangement - accessible by opening the door.
  • Page 128 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS Figure 5-3. Auxiliary O Flowmeter...

  • Page 129: Vaporizers

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) Vaporizers The vaporizer mounting is shown in Figure 5-4. Before removing a vaporizer from the machine for shipment, it must be completely drained and dried in accordance with the procedure given below.
  • Page 130 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS SV00518 LOCKING LEVER SELECTOR LEVER O-RINGS VAPORIZER MOUNTING AND EXCLUSION SYSTEM Figure 5-4. Vaporizer Installation 5-10...
  • Page 131 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) NOTE: Should a 19.x series vaporizer containing anesthetic agent be accidentally tilted more than 45 degrees, it must be drained and flushed in accordance with instructions given in the manual supplied with the vaporizer.
  • Page 132 RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS O2 Flush Valve The O2 flush valve is accessible from the underside of the table top. Valve removal requires disconnecting the plastic tubing and removal of an L-fitting.

  • Page 133: O2 Flush Valve

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) UNDERSIDE VIEW OF TABLE SV00474 STRAIGHT FITTING L-FITTING O2 FLUSH VALVE RETAINING NUT Figure 5-5. O...

  • Page 134: Caster

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS Caster The casters are threaded into the frame rails on the trolley. A typical arrangement is shown in Figure 5-6.
  • Page 135 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) SV00507 THREADED STEM Figure 5-6. Caster Replacement 5-15...
  • Page 136 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS Ventilator The ventilator and door assembly are retained in the monitor housing by a hinge rod.

  • Page 137: Ventilator

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) E-RING UPPER HINGE BUSHING VENTILATOR ASSEMBLY HINGE ROD LOWER HINGE BUSHING SPACERS J11 TACH SENSOR J12 HOME...
  • Page 138 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS TOP VIEW OF HINGE DETAILS VENTILATOR ASSEMBLY HINGE UPPER HINGE BUSHING VENT PRESSURE HOSE DOOR CONNECTION...
  • Page 139 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) Ventilator Servicing: Upper Diaphragm (patient side) 5.7.11 Release the three clamps holding the patient assembly to the upper cylinder;...

  • Page 140: Retaining Ring

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS Lower Diaphragm: (motor & case assembly) 5.7.15 Note the position of the clamp for reassembly, then remove the bolt securing the band clamp holding the upper and lower cylinders together.
  • Page 141 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) O-RING LOWER DIAPHRAGM SV00544 Figure 5-11. Lower Diaphragm Installation 5.7.21 Reinstall the O-ring in the groove on the outside of the diaphragm.
  • Page 142 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS SV88059 PISTON SCREW (3X) RETAINING RING TOP VIEW OF PISTON PISTON LOWER DIAPHRAGM O-RING LOWER CYLINDER...
  • Page 143 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) 5.7.26 While holding the cylinders together, move the band clamp into position and reinstall its bolt to join the cylinders. Make sure the band clamp is positioned as shown in Figure 5-8.
  • Page 144 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS Ventilator Reassembly: 5.7.38 Position the ventilator against the door; slide the upper and lower hinge bushings in place, and reinstall Screw A (Figure 5-8.
  • Page 145 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) Patient Assembly: In case of repair, replace the high pressure valve, the negative pressure relief valve, or the complete patient system. See Figure 5-8.
  • Page 146 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS 5.7.61 Carefully reinstall the patient system, making sure the diaphragm seats properly. 5.7.62 Secure the three clamps holding the patient assembly to the upper cylinder.

  • Page 147: Gas Inlet Assembly (Including O2 Supply Pressure Switch)

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) Gas Inlet Assembly (including O2 supply pressure switch) The gas inlet assembly is attached to the inside of the back panel on the gas box assembly as shown in Figure 5-13.
  • Page 148 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS GAS INLET ASSEMBLY WIRE HARNESS O2 SUPPLY PRESSURE ALARM SWITCH GAS INLET ASSEMBLY MOUNTING SCREWS BACK PANEL SV00473 Figure 5-13.

  • Page 149: Battery

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) Battery The two 12 V rechargeable batteries are located in the vent & monitor assembly behind the front bezel. The batteries and their connections are accessible through the ventilator compartment as shown in Figure 5-14.
  • Page 150 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS TOP CUT AWAY TO SHOW BATTERY ARRANGEMENT BATTERIES BATTERY RETAINER BRACKET RETAINER SCREW BLACK WIRE CABLE CLIP...

  • Page 151: Power Supply

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) 5.10 Power Supply The power supply is attached to the inside of the controller assembly back panel.
  • Page 152 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS SV00464 WIRE CLIPS GROUND WIRE CONNECTION INPUT CABLE (J1) POWER SUPPLY OUTPUT CABLE (J3) BACK PANEL OF...

  • Page 153: Control Pcb Assembly

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) 5.11 Control PCB Assembly The control PCB assembly is accessible by removing the back cover of the controller housing.
  • Page 154 DrägerService - Technical Support: Phone 1-800-4-Drager, Phone: 215-721-5402, or e-mail to techsupport@draegermed.com and provide the following information to receive the necessary release codes: -- Machine Type (Fabius GS or Fabius Tiro) -- Feature Description and Part Number -- Machine Serial Number -- Device ID Number 5.11.15 Perform the PMS procedure, including all calibrations and site...
  • Page 155 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) Table 1: Default Market Kit Settings for SW Versions 1.2n and 1.3n Date Time Alarm Pres.
  • Page 156 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS Table 2: Default Market Kit Settings for SW Version 2.X O2 Whistle Language Date Format Time Format...

  • Page 157: Serial Port

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) FRONT PANEL KEYPAD SERIAL PORT DISPLAY INTERFACE INTERFACE SPIROLOG VENT SENSOR CHAMBER PRESSURE SENSOR O2 SENSOR...

  • Page 158: Pneumatic (Peep Control) Assembly

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS 5.12 Pneumatic (PEEP Control) Assembly The Pneumatic assembly is accessible by removing the back cover of the controller housing.
  • Page 159 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) SV279001 CONTROLLER PCB LS1 SENSOR PUMP CABLE CONNECTION CONNECTION MUFFLER ASSEMBLY EXHAUST PORT PUMP ASSEMBLY CAPTIVE...
  • Page 160 RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS 5.12.6.2.1 Remove the adhesive backing from the foam cushion (P/N 4118174) and attach the cushion to the underside of the new Motor Pump Assembly. Refer to...
  • Page 161 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) 5.12.6.3.6 Apply a thin coating of #222 purple Loctite to two pan head screws (P/N 1343068).
  • Page 162 RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS 5.12.6.3.7 Using the two pan head screws, attach the Motor Pump Assembly to the Pump Adapter Mounting Bracket. 5.12.6.3.8 Secure ferrule from Motor Pump Assembly to Pump Adapter Mounting Bracket using tie strap (P/N 4106068).

  • Page 163: Flow Meter Bezel Assembly

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) 5.13 Flow Meter Bezel Assembly Following is the procedure for removing and replacing the flow meter bezel assembly.

  • Page 164: Ribbon Cable

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS SV00506 FLOWMETER BEZEL ASSEMBLY RIBBON CABLE FLOWSENSOR CONNECTION (TYPICAL) FLOWMETER BEZEL ASSEMBLY RETAINER SCREWS BACK VIEW OF MACHINE (PARTIAL) Figure 5-21.

  • Page 165: Fresh Gas Flow Meter

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) 5.14 Fresh Gas Flow Meter Access to the fresh gas flow meter requires removal of the flow meter bezel assembly as described in a previous paragraph.
  • Page 166 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS BEZEL ASSEMBLY SV00478 TUBE TO VAPOR FLOW MOUNT TUBE TUBE FROM FLOW SENSOR MANIFOLD FLOW TUBE MOUNTING BRACKET (2X)

  • Page 167: Flow Control Valves

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) 5.15 Flow Control Valves Flow control valves can be replaced from the front panel while the flow meter bezel assembly is in place.
  • Page 168 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS COVER SPRING WASHER FLAT WASHER KNOB CHUCK COLLET SPACER FLOW CONTROL VALVE FLOW METER BEZEL ASSEMBLY...

  • Page 169: Fresh Gas Flow Sensors And Filter Assembly

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) 5.16 Fresh Gas Flow Sensors and Filter Assembly Access to the flow sensors and filter assembly requires removal of the flow meter bezel assembly as described in Section 5.13.
  • Page 170 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS 5.16.8 Reinstall the flow meter bezel assembly in the machine (refer to the Flow Meter Bezel Assembly instructions, Section 5.13).

  • Page 171: Pipeline Pressure Gauges

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) 5.17 Pipeline Pressure Gauges Access to the pipeline pressure gauges requires removal of the flow meter bezel assembly as described in Section 5.13.
  • Page 172 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS SV88012 FLOW METER BEZEL ASSEMBLY TUBES FROM GAS INLET ASSEMBLY STRAIGHT FITTINGS (3X) RETAINER PLATE PIPELINE PRESSURE GAUGE (3X)

  • Page 173: Sorc (Sensitive Oxygen Ratio Controller)

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) 5.18 SORC (Sensitive Oxygen Ratio Controller) Access to the SORC requires removal of the flow meter bezel assembly as described in Section 5.13.
  • Page 174 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS Figure 5-26. SORC 5-54...
  • Page 175 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) 5.19 Fresh Gas Display PCB Access to the fresh gas display PCB requires removal of the flow meter bezel assembly as described in Section 5.13.

  • Page 176: Fresh Gas Display Pcb

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS FLOWMETER SV00483 BEZEL ASSEMBLY PCB MOUNTING SCREWS AND LOCKWASHERS (4X) RIBBON CABLE FROM CONTROLLER (J1) INSULATOR...

  • Page 177: Monitor Bezel Assembly

    RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS 5.20 Monitor Bezel Assembly The monitor bezel assembly comprises the keypad, flat panel display, rotary switch, and LED lamp PCB assembly. Access to the bezel assembly mounting screws is through the ventilator compartment as shown in Figure 5-28.
  • Page 178 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS REPLACEMENT PROCEDURES (continued) FABIUS GS SV00463 SEE TEXT KEY PAD INSERT BEZEL SCREWS GROUND WIRE KEYPAD CONNECTOR L OCKING T ABS DISPL A Y PANEL CONNECTOR Figure 5-28.

  • Page 179: Spirolog Sensor And Cable

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS REPLACEMENT PROCEDURES (continued) 5.21 Spirolog Sensor and Cable 5.21.1 Set machine power switch to OFF and disconnect AC power from the machine.
  • Page 180 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS...

  • Page 181: Section 6: Adjustment And Calibration Procedures

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS ADJUSTMENT AND CALIBRATION PROCEDURES ADJUSTMENT AND CALIBRATION PROCEDURES Cylinder Pressure Regulator Adjustment 6.1.1 Set the System Power switch to OFF.
  • Page 182 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS ADJUSTMENT AND CALIBRATION PROCEDURES (continued) FABIUS GS SV00465 O2 REGULATOR REGULATOR ACORN NUT O2 PIPELINE HOSE TEST GAUGE Figure 6-1. Cylinder Pressure Regulator Adjustment: O2 Connection Illustrated...
  • Page 183 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS ADJUSTMENT AND CALIBRATION PROCEDURES (continued) NOTE: Cylinder pressure compensation for the N2O regulator is not required. Cylinder Pressure Compensated Regulator...

  • Page 184: Gas Inlet Regulator Output Adjustment

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS ADJUSTMENT AND CALIBRATION PROCEDURES (continued) FABIUS GS Gas Inlet Regulator Output Adjustment O2 Inlet Regulator: 6.2.1 Bleed all cylinder and pipeline pressures. Disconnect all cylinders and pipeline hoses.
  • Page 185 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS ADJUSTMENT AND CALIBRATION PROCEDURES (continued) 6.2.4 Reconnect the O2 pipeline supply hose to the O2 pipeline inlet connector and pressurize the O2 supply.

  • Page 186: Oxygen Supply Pressure Alarm Switch Adjustment

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS ADJUSTMENT AND CALIBRATION PROCEDURES (continued) FABIUS GS Oxygen Supply Pressure Alarm Switch Adjustment 6.3.1 Disconnect all pipeline hoses and set the System Power switch to ON.
  • Page 187 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS ADJUSTMENT AND CALIBRATION PROCEDURES (continued) SIDE VIEW SV00504 OF GAS INLET ASSEMBLY SUPPLY SWITCH ADJUSTMENT SCREW O2 PIPELINE HOSE TEST GAUGE Figure 6-3.

  • Page 188: Sensitive Oxygen Ratio Controller (Sorc) Adjustment

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS ADJUSTMENT AND CALIBRATION PROCEDURES (continued) FABIUS GS Sensitive Oxygen Ratio Controller (SORC) Adjustment 6.4.1 Set the System Power switch to OFF.
  • Page 189 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS ADJUSTMENT AND CALIBRATION PROCEDURES (continued) OPERATING LOCK NUT POINT ADJUSTMENT N2O FLOW ADJUSTMENT TEST PRESSURE GAUGE O2 CONTROL PRESSURE...
  • Page 190 RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS ADJUSTMENT AND CALIBRATION PROCEDURES (continued) FABIUS GS 6.4.14 The N2O flow should be 3 ±0.3 mL/min, resulting in an O2 concentration of 25 ± 3 vol. % O2 at the fresh gas outlet.

  • Page 191: Oxygen Sensor Calibration

    ‘Calibrate O2 Sensor’ softkey shall illuminate. Following calibration the screen returns to normal. NOTE: If an “O2 Sensor Calibration Failed” message appears, refer to the oxygen monitoring section of the Fabius GS Operator’s Instruction Manual for further information. 6.5.3.8 Reinstall the O2 sensor assembly in the inspiratory valve dome.
  • Page 192 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS ADJUSTMENT AND CALIBRATION PROCEDURES (continued) FABIUS GS OXYGEN SENSOR HOUSING SENSOR CAPSULE SENSOR HOUSING COVER INSPIRATORY VALVE DOME SV00492 Service 9:34...

  • Page 193: Pressure Calibration

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS ADJUSTMENT AND CALIBRATION PROCEDURES (continued) Pressure Calibration 6.6.1 Set the main power switch to ON. 6.6.2 Access the main service screen (ref. Section 4).

  • Page 194: Fresh Gas Flow Calibration

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS ADJUSTMENT AND CALIBRATION PROCEDURES (continued) FABIUS GS Fresh Gas Flow Calibration 6.7.1 Set the main power switch to ON. Access the main service screen (ref. Section 4.0).

  • Page 195: Peep Valve Calibration

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS ADJUSTMENT AND CALIBRATION PROCEDURES (continued) PEEP Valve Calibration NOTE: Before performing the PEEP valve calibration, a valid pressure calibration and system leak test must be performed first. Otherwise an ‘Inv pres.
  • Page 196 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS ADJUSTMENT AND CALIBRATION PROCEDURES (continued) FABIUS GS INSPIRATORY VALVE TERMINAL TUBE, CORRUGATED 22mm x 12 in. LONG P/N 9995112 EXPIRATORY SV00494...

  • Page 197: Vacuum Adjustment

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS ADJUSTMENT AND CALIBRATION PROCEDURES (continued) Vacuum Adjustment The vacuum adjustment is located on the pneumatic assembly and is accessible by removing the back cover of the controller housing.
  • Page 198 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS ADJUSTMENT AND CALIBRATION PROCEDURES (continued) FABIUS GS 6.10 Vacuum Pressure Pump Assembly (SW Version 2.X) 6.10.1 Pump Calibration (If Applicable) NOTE: The ability to calibrate the pump is dependant upon the current PCB installed in the Core Unit.

  • Page 199: Pms Procedure, Fabius Gs

    Fabius GS Parts Replacement Schedule: ........7-3...

  • Page 200: Test Equipment Required

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS Test Equipment Required: -- Multi-Meter (Fluke or equivalent) -- Electrical Safety Analyzer (Biotek 501 Pro or equivalent)

  • Page 201: Fabius Gs Parts Replacement Schedule

    4199912 Filter, Pressure & Pneumatic asm 8402868 Diaphragm, Patient 2600650 O-ring, Vapor 4115864 O-ring, for Diaphragm (piston) 8604831 Every 3 Years: Fabius GS/Tiro 3 year kit 4117360-002 4199911 Diaphragm, Piston 2600651 Battery, 12V Rechargeable 4114229 Canister Assembly M29320 Lip Seal...

  • Page 202: Test Connector

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS 4113119 FRESH GAS LEAK TEST DEVICE CONNECT TO TEST PRESSURE GAUGE TEST CONNECTOR 4117361 SV00517...
  • Page 203 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) 8401892 SIEMENS TEST LUNG SV00025...
  • Page 204 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS S010159 BREATHING SYSTEM LEAK TEST DEVICE 4104389 TEST TERMINAL ADAPTER SV00515...
  • Page 205 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) SV00559 S000081 FLOW METER TEST STAND 0-250cc/MIN...
  • Page 206 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS SV00552 Liter 2212300 vol/min MINUTE VOLUMETER TEST VOLUME METER 4115087 33mm x 22mm ADAPTER...
  • Page 207 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) M33972 TEST CAP SV00516...
  • Page 208 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS 4114807 PRESSURE TEST ASSEMBLY , WITH ADAPTERS SV00376 4114830-002 4114830-001 4114830-004 4114830-003 4114830-006 4114830-005 7-10...

  • Page 209: Periodic Manufacturer's Certification General Instructions

    Periodic Manufacturer’s Certification General Instructions The purpose of these procedures is to provide detailed instructions for performing a Periodic Manufacturer’s Certification (PMC) inspection on the Fabius GS anesthesia machines. A PMC consists of a complete Periodic Manufacturer’s Service procedure and a certification level inspection based on Draeger Medical, Inc.
  • Page 210 RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS The letters A, B, C, D and the Roman Numerals I, II are used as codes in the individual matrix for each model of anesthesia machine. The letters A, B, C, and D are used in descending order to indicate the certification level of the equipment.
  • Page 211 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) A Narkomed AMIII or Narkomed II could have recommendations 6 apply, and failure code 46.2. 6 - Oxygen ratio monitor instead of oxygen ratio monitor controller. Code D II.
  • Page 212 PMS PROCEDURE (continued) FABIUS GS PM Certification Procedure for Fabius GS Anesthesia System 1. Use the PM Certification form P/N 4117715 for the Fabius GS Anesthesia System. 2. Completely fill in the header information. 3. Perform the vapor concentration test on all Dräger vapor vaporizers every six months in accordance with SP00073 at a six month maximum interval.
  • Page 213 PM Certification Procedure for Fabius GS Anesthesia System 5. Based on the “EQUIPMENT CONDITION” inspect the machine for any “NAD RECOMMENDATIONS” that would apply. Use the Fabius GS section of the “NAD RECOMMENDATION GUIDELINES INDEX”, P/N S010250. Note all applicable NAD recommendations on the Executive Summary. NOTE: If using a carbon form, indicate the Equipment Condition number and to see reverse side under “RECOMMENDATIONS / GENERAL COMMENTS”...

  • Page 214: Electrical Safety

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS NOTE: The following procedure will require making adjustments and calibrations with the possibility of removal of accessories and/or additional monitoring equipment.
  • Page 215 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) 7.1.2 Circuit Isolation (If Applicable) NOTE: This test is not applicable on machines with serial numbers 12191 to 12334.

  • Page 216: System Diagnostics

    Pass Pass Speaker Speaker Pass Pass Main Power Main Power Pass Pass Battery Battery Pass Pass Fabius GS SW 1.03 CRC 6DBA Fabius GS SW XX 7.2.4 Record the machine software version on the header of the checklist form. 7-18...

  • Page 217: Battery Circuit

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) Battery Circuit 7.3.1 Press the Man Spont key, and press the rotary dial to confirm. 7.3.2 Unplug the AC power cord and verify the “Power Fail”...

  • Page 218: Calibrations

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS 7.5.7 Inspect the condition of the ventilator (piston diaphragm) O-ring. Is the O-ring in good condition? (Y) 7.5.8...
  • Page 219 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) O2 Position (virtual flowtubes): 7.7.2 Scroll to Flowmeter and confirm. Scroll to O2 Position and confirm.
  • Page 220 RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS NOTE: Machines from the factory are configured with the appropriate model type. Other than performing a software download or PCB replacement, the model type should not be changed. Changing the model type will disable some ventilator options and will require reconfiguration.
  • Page 221 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) Elevation Range in Barometric Pressure Elevation Range in Feet Meters Setting -200 - 199 -60 - 60...

  • Page 222: Scavenger, Ags

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS Scavenger, AGS Scavenger Cleaning 7.8.1 Remove all scavenger hoses one at a time and drain all accumulated moisture.

  • Page 223: Breathing System

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) Breathing System 7.9.1 Breathing System Inspection 7.9.1.1 Record the serial number (located on the side of the COSY) on the PMS form.
  • Page 224 RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS 7.9.1.16 Examine all pneumatic hoses connecting from the interface panel to the breathing system. Are the hoses kink free and in good condition? ___(Y) 7.9.1.17 Inspect the breathing circuit and manual breathing bag.
  • Page 225 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) 7.9.2.11 If applicable, turn on the right mounted vaporizer to the first graduated marking; repeat Steps 7.9.2.5 thru 7.9.2.10 ___ (>40 cm H 7.9.2.12 Remove the test equipment from the fresh gas hose.
  • Page 226 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS 7.9.3 Breathing System Leak NOTE: Use the appropriate column in the following table - according to the software version of the machine you are testing: Software ≥...

  • Page 227: Test Terminal

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) SV00549a SET APL VALVE TO MAN, 70 cmH2O INSTALL TEST CAP M33972 ON VENTILATOR HOSE TERMINAL (UNDERSIDE)
  • Page 228 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS 7.9.4 APL Valve Verification 7.9.4.1 Connect a digital manometer between the inspiratory and expiratory ports of the breathing system (using two test terminals and modified 4113119 fresh gas leak test device).
  • Page 229 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) Lever Style APL Valve Rotary Knob Style APL Valve 7.9.4.3 Verify the fresh gas hose is connected to the breathing system.
  • Page 230 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS 7.9.5 Inhalation and Exhalation Valves Inhalation: 7.9.5.1 Install test terminal on the 22 mm inspiratory connector.
  • Page 231 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) 7.9.5.3 Remove the freshgas hose from the breathing system and connect it to the freshgas leak connector (4117163).
  • Page 232 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS Exhalation: 7.9.5.8 Occlude ventilator and inspiratory port, each with test cap M33972. 7.9.5.9 Connect a digital manometer to bag mount and 0-250 cc test flowmeter to thre expiratory port as shown.
  • Page 233 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) 7.9.6 Reverse Flow Test (Fresh Gas Decoupling Valve) 7.9.6.1 Verify the breathing bag port, fresh gas connection and expiration port connections are open and not occluded.
  • Page 234 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS 7.9.6.5 Verify the APL valve is in the MAN position and set to 70 cmH2O. 7.9.6.6 Slowly increase O2 flow to maintain 40 cmH2O on the digital pressure meter.
  • Page 235 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) 7.9.7 Leakage Control Port 7.9.7.1 Disconnect the APL and PEEP control hoses from the interface panel at rear of machine.
  • Page 236 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS 7.9.7.3 Short circuit the inspiratory and expiratory ports, attach a test terminal to the breathing bag port and attach a digital manometer to the test terminal.

  • Page 237: Vapor Interlock System

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) 7.10 Vapor Interlock System 7.10.1 Set all vapors to zero (0). 7.10.2 Adjust the handwheel on the left vapor to any concentration above zero (0).

  • Page 238: Yokes & Gauges

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS 7.11 Yokes & Gauges 7.11.1 Yokes & Check Valves (if applicable) 7.11.1.1 Turn the System Power switch Off.
  • Page 239 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) 7.11.2 Cylinder Gauges (if applicable) 7.11.2.1 Are the pressure gauges correct for the gases indicated by the flowmeters? ___ (Y) 7.11.2.2 Bleed all pressure from the cylinder circuits using the flow...

  • Page 240: Gas Inlet Regulator Output

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS 7.12 Gas Inlet Regulator Output 7.12.1 O2 Inlet Regulator 7.12.1.1 Bleed all cylinder and pipeline pressures. Disconnect all cylinders and pipeline hoses and remove rear panel to access gas inlet assembly.
  • Page 241 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) 7.12.1.5 After the digital manometer stabilizes, what is the regulator output pressure? ___psi (28 - 32 psi) 7.12.1.6 Deplete O2 pressure from the pipeline supply.

  • Page 242: Quick Disconnect

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS 7.12.3 Pipeline Check Valves O2 Pipeline Check Valve: 7.12.3.1 Attach a Swagelock fitting (P/N 4109318) to the inlet of the S000081 test flowmeter.
  • Page 243 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) N2O Pipeline Check Valve (if applicable) 7.12.3.5 Attach the appropriate N2O adapter to the N2O connector on the inlet block, and transfer the end of the hose with the quick disconnect fitting to the N2O adapter.

  • Page 244: Cylinder Regulator & Pipeline Gauges

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS 7.13 Cylinder Regulator & Pipeline Gauges Minimum cylinder pressure requirements for this test are: N2O: 600 psi; O2, Air: 1000 psi.
  • Page 245 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) 7.13.1.2 Connect the test fixture hose to the machine’s nitrous oxide pipeline inlet. 7.13.1.3 Does the back panel correctly identify the nitrous oxide inlet? ___(Y) 7.13.1.4 Connect the nitrous oxide pipeline supply hose to the test fixture.
  • Page 246 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS 7.13.3 N2O Pipeline Leak 7.13.3.1 Close the nitrous oxide flow control valve. 7.13.3.2 Release the test device push button.
  • Page 247 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) 7.13.5 Air Pipeline Gauge Accuracy 7.13.5.1 Close the air cylinder valve and drain all air pressure.
  • Page 248 RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS 7.13.7.7 Release the push button. After the pressure decay stabilizes, what is the regulator output pressure? ___psi (based upon cylinder pressure as given in the following table)

  • Page 249: High Pressure Leak

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) 7.14 High Pressure Leak 7.14.1 Oxygen High Pressure Leak 7.14.1.1 Verify the System Power switch is OFF.
  • Page 250 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS 7.14.3 Air High Pressure Leak 7.14.3.1 Turn the System Power switch to ON. 7.14.3.2 Open one (1) oxygen cylinder valve and the air cylinder valve.

  • Page 251: Oxygen Supply Failure Protection

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) 7.15 Oxygen Supply Failure Protection 7.15.1 Nitrous Oxide (if applicable) 7.15.1.1 Open and close the oxygen cylinder valve.
  • Page 252 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS 7.15.2 Oxygen Supply Pressure Alarm 7.15.2.1 If not already connected, connect the Pressure Test Assembly (P/N 4114807) with O adapters between the central supply hose and the machine.

  • Page 253: Flowmeters

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) 7.16 Flowmeters 7.16.1 Oxygen Flowmeter 7.16.1.1 Open the O cylinder valve. 7.16.1.2 Is it possible to adjust the flow of oxygen to 10 L/min.? ___ (Y) 7.16.1.3 Close the O...
  • Page 254 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS 7.16.3 Air Flowmeter 7.16.3.1 Connect the Air pipeline supply (if applicable). 7.16.3.2 Is it possible to adjust the flow of air to 10 L/min.? ___ (Y) 7.16.3.3 Close the air flow control valve and disconnect the Air pipeline...

  • Page 255: Oxygen Monitor

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) 7.17 Oxygen Monitor 7.17.1 Press the Man Spont key and press the rotary knob to confirm.
  • Page 256 RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS 7.17.18 Verify that the high alarm limit has a range from 100 to 19%. 7.17.19 Set the high alarm limit to below the correct O2 reading.

  • Page 257: Oxygen Concentrations

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) 7.18 Oxygen Concentrations 7.18.1 Oxygen + Nitrous Oxide Concentration (if applicable) 7.18.1.1 Verify the oxygen flow is at 4 L/min.

  • Page 258: Sorc

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS 7.19 SORC 7.19.1 Depress the O FLUSH for 5 seconds. 7.19.2 Set the O2 and N2O flow to 10 L/min.

  • Page 259: Pressure Monitor

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) 7.20 Pressure Monitor 7.20.1 Verify unit is in Man Spont mode. 7.20.2 Disconnect the breathing pressure sensor line from the breathing system.
  • Page 260 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS 7.20.16 At what pressure does the APNEA PRESSURE alarm deactivate? ___ cm H O (7-13) 7.20.17 Adjust the threshold to 18 cm H 7.20.18 Increase the pressure to 20 cm H...

  • Page 261: Ventilator

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) 7.21 Ventilator 7.21.1 Manual Ventilation 7.21.1.1 Cycle machine power-using On/Off switch and allow completion of the self-test.
  • Page 262 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS 7.21.4 Ventilator Delivery 7.21.4.1 Set APL to Man position and set to 30 cmH2O. 7.21.4.2 Switch to Volume Control mode and set the fresh gas flow to 3 L/ min.
  • Page 263 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) 7.21.6 Pmax Accuracy 7.21.6.1 Connect a test pressure gauge in line with the pressure port connector of breathing system.
  • Page 264 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS 7.21.8.2 Set: pmax = 40 mbar (cmH2O) Vt = 600 mL Freq = 6 BPM TI:TE = 1:1...

  • Page 265: Test Terminal

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) 7.21.10 Verify relief valve opens between 70 and 80 mbar (cmH2O) when ventilator is in inspiratory phase.
  • Page 266 RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS 7.21.11 Auxiliary Air Valve Test 7.21.11.1 Close all flow control valves. Verify vacuum valve opens at the pressure indicated in the following table, when ventilator is in expiratory phase.

  • Page 267: Fresh Gas

    FRESH GAS LEAK TEST SV00548 DEVICE 4113119 (MODIFIED) 7.21.13 Vacuum Pressure 7.21.13.1 Set Fabius GS to Volume mode. 7.21.13.2 Remove APL bypass hose from breathing system and attach to digital manometer. 7.21.13.3 Verify vacuum is between -150 and -240 cmH2O (mbar) (-110 and -175 mmHg) as shown on digital manometer.

  • Page 268: Volume Alarms

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS 7.22 Volume Alarms 7.22.1 Set ventilator to Volume Control mode and confirm. 7.22.2 Set: pmax = 40 mbar (cmH2O)
  • Page 269 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) 7.22.17 Fresh Gas Low 7.22.17.1 Select Volume Control mode and confirm. 7.22.17.2 Disconnect the hose attached to the breathing system’s inspiratory port.

  • Page 270: Audio Silence

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS 7.23 Audio Silence 7.23.1 Press the key. 7.23.2 Does the LED on the Silence Alarms key light? Is the audio alarm silenced for 120 sec.?

  • Page 271: Oxygen Flush Valve

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS PMS PROCEDURE (continued) 7.24 Oxygen Flush Valve 7.24.1 Press and release the O FLUSH button. 7.24.2 Does the flow of oxygen stop immediately? __ (Y) 7.24.3...

  • Page 272: Final Tests

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS PMS PROCEDURE (continued) FABIUS GS 7.25 Final Tests 7.25.1 Operator's Instruction Manual 7.25.1.1 Verify that the availability/location of the machine's Operator's Instruction Manual is in close proximity of the machine.

  • Page 273: Software Update Procedure

    RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS SOFTWARE UPDATE PROCEDURE SOFTWARE UPDATE PROCEDURE This section outlines the basic software installation procedure, including the equipment needed and its connections. For specific software versions, refer to applicable Service Procedures.
  • Page 274 RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SOFTWARE UPDATE PROCEDURE (continued) FABIUS GS 8.2.2 Minimize all programs and check desktop area for the following icon. NOTE: If the ‘SendImage’ icon exists on your laptop, proceed to Section 8.3 ‘Updating Send Image’.
  • Page 275 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS SOFTWARE UPDATE PROCEDURE (continued) 8.2.6 Verify the following ‘InstallShield Wizard’ screen appears and the Destination Folder is C:. Choose ‘Next’.
  • Page 276 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SOFTWARE UPDATE PROCEDURE (continued) FABIUS GS...
  • Page 277 Using Windows Explorer, double click on the appropriate drive and open the ‘send_image_install’ file. 8.3.3 Double click on the ‘copy_si.bat’ file. This updates your current ‘Send Image’ file to the latest version.Proceed to ‘Installing Fabius GS Software from a PC’, Section 8.4. INSTALLING FABIUS GS SOFTWARE FROM A PC 8.4.1 Record the market settings on the unit for re-configuration of the controller PCB after download.
  • Page 278 ‘send_img’. The ‘Communications Settings’ screen will appear. Configure the ‘Communications Settings’ as follows: 8.4.4 Press Enter or click OK. Connect the download cable from Com1 on the laptop computer to the serial interface port on the Fabius GS. See Figure 8.1.

  • Page 279: Serial Interface Port

    RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS SOFTWARE UPDATE PROCEDURE (continued) REAR VIEW OF FABIUS GS SERIAL INTERFACE PORT SV00524 FIGURE 8-1. Fabius GS Serial Port Location 8.4.5 From the drop-down box, select the CD Drive.
  • Page 280 RETURN TO CD-ROM TABLE OF CONTENTS SOFTWARE UPDATE PROCEDURE (continued) FABIUS GS 8.4.6 Double click the ‘software image’ folder (fgs_vxxx). The ‘Fabius GS.IMG’ is displayed. 8.4.7 Double-click the ’.IMG’ file or single-click (highlight), then press ‘Enter’. The following screen will be displayed: 8.4.8...
  • Page 281 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS SOFTWARE UPDATE PROCEDURE (continued) 8.4.9 As the software is downloading, programming blocks will appear on the Figure 8.2. When the download is complete and machine display.
  • Page 282 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SOFTWARE UPDATE PROCEDURE (continued) FABIUS GS In Progress Fabius GS Image Loader Loading programming blocks FIGURE 8-2. Image Loader Screen Complete - Successful Fabius GS Image Loader...
  • Page 283 FABIUS GS SOFTWARE UPDATE PROCEDURE (continued) 8.4.10 Set the power switch on the Fabius GS to OFF. Close the PC loader screen and power down the PC. Disconnect the interface cable. 8.4.11 Switch machine power to ON and verify all self-diagnostics indicate a Pass condition, except for NAVRAM.
  • Page 284 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SOFTWARE UPDATE PROCEDURE (continued) FABIUS GS Table 8-1: Market Kit Settings Date Time Alarm Pres. Language Whistle Format Format Position Sounds...
  • Page 285 Fabius GS boot Strap load function to the original SENDIMG.EXE program that is currently used in existing products. When a Fabius GS does not have a valid bootable image installed, it can not perform an Automatic Image Reload Operation. The same PC and files are used (including SENDIMG.EXE V2).
  • Page 286 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SOFTWARE UPDATE PROCEDURE (continued) FABIUS GS 8.5.6 Power up the PC and double-click the “send_img” icon on desk top. The following screen will appear: 8.5.7...
  • Page 287 8.5.14 Reinstall the back panel of the control unit. 8.5.15 Access the appropriate service screens (see Section 7.5 of the Fabius GS Service Manual) and update the machine serial number, clear service log and reset hours run. The machine serial number is located on the rear of the machine.
  • Page 288 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SOFTWARE UPDATE PROCEDURE (continued) FABIUS GS SV00611 FIGURE 8-6. Boot Strap Jumper and Download Connections on Control PCB P/N 4118079 8-16...

  • Page 289: Spare And Replacement Parts

    Fresh gas flow sensors & filter asm (part of flow meter bezel assembly) (Applicable to Fabius GS machines Serial Number 12191 or higher).....
  • Page 290 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SPARE AND REPLACEMENT PARTS (continued) FABIUS GS WRITING TRAY ASSEMBLY SV77015...
  • Page 291 Tray Top, Fabius GS ........
  • Page 292 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SPARE AND REPLACEMENT PARTS (continued) FABIUS GS SV00558...
  • Page 293 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS SPARE AND REPLACEMENT PARTS (continued) ITEM DESCRIPTION PART NUMBER 1. Spirolog flow sensor, 5 pack ......... . . 8403735 2.
  • Page 294 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SPARE AND REPLACEMENT PARTS (continued) FABIUS GS FRESH GAS DECOUPLING VALVE NOTE NOTE APL BYPASS VALVE PEEP/PMAX VALVE SV77012 NOTE A - DEPENDANT UPON THE CONFIGURATION OF THE COSY CURRENTLY INSTALLED,...
  • Page 295 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS SPARE AND REPLACEMENT PARTS (continued) ITEM DESCRIPTION PART NUMBER 1. Dome, insp valve ............4107960 2.
  • Page 296 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SPARE AND REPLACEMENT PARTS (continued) FABIUS GS TYPICAL BREATHING BAG EXTENSION CONFIGURATIONS EXPIRATORY INSPIRATORY MOUNT PORT PORT PORT TYPICAL BREATHING SYSTEM CONFIGURATIONS...
  • Page 297 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS SPARE AND REPLACEMENT PARTS (continued) ITEM DESCRIPTION PART NUMBER 1. Pole Assembly, Breathing Bag Extension (for use with item #3)....4117753 2.
  • Page 298 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SPARE AND REPLACEMENT PARTS (continued) FABIUS GS SV00418 9-10...
  • Page 299 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS SPARE AND REPLACEMENT PARTS (continued) ITEM DESCRIPTION PART NUMBER 1. Absorber top ............M33013 2.
  • Page 300 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SPARE AND REPLACEMENT PARTS (continued) FABIUS GS SV00419 9-12...
  • Page 301 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS SPARE AND REPLACEMENT PARTS (continued) ITEM DESCRIPTION PART NUMBER 1. Canister assembly ........... M29320 Screen insert .
  • Page 302 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SPARE AND REPLACEMENT PARTS (continued) FABIUS GS SV77026 0.19 M [7 1/2 IN] 0.33 M [13 IN] 0.94 M [37 IN]...
  • Page 303 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS SPARE AND REPLACEMENT PARTS (continued) ITEM DESCRIPTION PART NUMBER 1. Breathing system mount assembly ........4117400 Breathing system mount assembly, Right Hand COSY .
  • Page 304 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SPARE AND REPLACEMENT PARTS (continued) FABIUS GS SV00477 9-16...
  • Page 305 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS SPARE AND REPLACEMENT PARTS (continued) ITEM DESCRIPTION PART NUMBER Fresh Gas Flow Meter [part of flow meter bezel assembly 4116543 (3-gas) or 4116542 (2-gas)] 1.
  • Page 306 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SPARE AND REPLACEMENT PARTS (continued) FABIUS GS SV77016 9-18...
  • Page 307 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS SPARE AND REPLACEMENT PARTS (continued) ITEM DESCRIPTION PART NUMBER Flow control valves and valve manifold [part of flow meter bezel assembly 4116543 (3-gas) or 4116542 (2-gas)] 1.
  • Page 308 RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SPARE AND REPLACEMENT PARTS (continued) FABIUS GS SV77017 CONFIGURATION OF FRESH GAS FLOW SENSORS AND FILTER ASSEMBLY FOR FABIUS GS MACHINES WITH SERIAL NUMBERS 12191 AND LOWER 9-20...
  • Page 309 SPARE AND REPLACEMENT PARTS (continued) ITEM DESCRIPTION PART NUMBER Fresh gas flow sensors and filter assembly (Fabius GS Machines with Serial Numbers of 12191 and lower) [part of flow meter bezel assembly 4116543 (3-gas) or 4116542 (2-gas)] 1. Deleted 2. Flow sensor assembly (3x) (w/o angle connector (12) and O-ring (8)) ...4116938 3.
  • Page 310 RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SPARE AND REPLACEMENT PARTS (continued) FABIUS GS SV77038 CONFIGURATION OF FRESH GAS FLOW SENSORS AND FILTER ASSEMBLY FOR FABIUS GS MACHINES WITH SERIAL NUMBERS 12191 AND HIGHER 9-22...
  • Page 311 ITEM DESCRIPTION PART NUMBER Fresh gas flow sensors and filter assembly (Fabius GS Machines with Serial Numbers of 12191 and higher) [part of flow meter bezel assembly 4116543 (3-gas) or 4116542 (2-gas)] 1. Flow sensor housing ..........4118279 2.
  • Page 312 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SPARE AND REPLACEMENT PARTS (continued) FABIUS GS SV77018 9-24...
  • Page 313 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS SPARE AND REPLACEMENT PARTS (continued) ITEM DESCRIPTION PART NUMBER Pipeline pressure gauges [part of flow meter bezel assembly 4116543 (3-gas) or 4116542 (2-gas)] 1.
  • Page 314 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SPARE AND REPLACEMENT PARTS (continued) FABIUS GS SORC SV77019 9-26...
  • Page 315 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS SPARE AND REPLACEMENT PARTS (continued) ITEM DESCRIPTION PART NUMBER SORC [part of flow meter bezel assembly 4116543 (3-gas) or 4116542 (2-gas)] 1.
  • Page 316 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SPARE AND REPLACEMENT PARTS (continued) FABIUS GS SV77020 9-28...
  • Page 317 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS SPARE AND REPLACEMENT PARTS (continued) ITEM DESCRIPTION PART NUMBER Fresh gas display PCB [part of flow meter bezel assembly 4116543 (3-gas) or 4116542 (2-gas)] 1.
  • Page 318 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SPARE AND REPLACEMENT PARTS (continued) FABIUS GS SV77021 9-30...
  • Page 319 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS SPARE AND REPLACEMENT PARTS (continued) ITEM DESCRIPTION PART NUMBER Cylinder Yokes, Regulators, and Gauges: 1. O2 yoke (2x) ............1101620 N2O yoke.
  • Page 320 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SPARE AND REPLACEMENT PARTS (continued) FABIUS GS SV77022 9-32...
  • Page 321 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS SPARE AND REPLACEMENT PARTS (continued) ITEM DESCRIPTION PART NUMBER 1. Deleted 2. Deleted 3. Deleted 4. Deleted 5. Connector, NIST N2O male ..........4111382 Connector, DISS N2O.
  • Page 322 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SPARE AND REPLACEMENT PARTS (continued) FABIUS GS NOTE A SV77023 NOTE A: CONFIGURATION SHOWN IN ILLUSTRATION IS BASED UPON CONTOL PCB P/N 4116632. THE CONFIGURATION OF CONTROL PCB P/N 4118079 WILL DIFFER.
  • Page 323 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS SPARE AND REPLACEMENT PARTS (continued) ITEM DESCRIPTION PART NUMBER 1. PCB assembly, Service Exchange ........SE4116632 Alternate part number .
  • Page 324 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SPARE AND REPLACEMENT PARTS (continued) FABIUS GS SV77024 9-36...
  • Page 325 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS SPARE AND REPLACEMENT PARTS (continued) ITEM DESCRIPTION PART NUMBER Pneumatic (PEEP Control) Assembly ........4117004 1.
  • Page 326 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SPARE AND REPLACEMENT PARTS (continued) FABIUS GS SV77036a 9-38...
  • Page 327 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS SPARE AND REPLACEMENT PARTS (continued) ITEM DESCRIPTION PART NUMBER 1. Bezel Assembly, Monitor ..........4117019 2.
  • Page 328 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SPARE AND REPLACEMENT PARTS (continued) FABIUS GS 10 10A SV77025 9-40...
  • Page 329 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS SPARE AND REPLACEMENT PARTS (continued) ITEM DESCRIPTION PART NUMBER Ventilator (w/-8 mbar pressure relief valve) ......4117080-001 Ventilator, Service Exchange (w/-8 mbar pressure relief valve) .
  • Page 330 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SPARE AND REPLACEMENT PARTS (continued) FABIUS GS 9-42...
  • Page 331 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS SPARE AND REPLACEMENT PARTS (continued) ITEM DESCRIPTION PART NUMBER 1. Auxiliary O2 Flow Meter, USA, complete ......4109310-003 Auxiliary O2 Flow Meter, ISO .
  • Page 332 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SPARE AND REPLACEMENT PARTS (continued) FABIUS GS SV77027 ***G ***G ***G - MOLYKOTE 55M GREASE **P = LOCTITE #222 (PURPLE) *R - LOCTITE #271 (RED)
  • Page 333 NOTE: The adapter fitting is needed when ordering a two-vapor mounting system as a replacement part for Fabius GS units with serial numbers < 10685. O-rings, vaporizer mount (4x) ........4115864 One-vapor mounting system .
  • Page 334 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SPARE AND REPLACEMENT PARTS (continued) FABIUS GS SV00560 9-46...
  • Page 335 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS SPARE AND REPLACEMENT PARTS (continued) ITEM DESCRIPTION PART NUMBER Scavenger, AGS ............M33300 1.
  • Page 336 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS SPARE AND REPLACEMENT PARTS (continued) FABIUS GS SV00598 9-48...
  • Page 337 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS FABIUS GS SPARE AND REPLACEMENT PARTS (continued) ITEM DESCRIPTION PART NUMBER AGS Scavenger w/adj valve ..........4117494 1.
  • Page 338 RETURN TO THIS MANUAL'S TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS...
