MS-6728 ATX Mainboard
Back Panel
I/O, p.2-10
JPW1, p.2-9
NBFAN1, p.2-17
AGP Slot, p.2-33
JCD1, p.2-22
PCI Slots, p.2-33
JS1, p.2-32
JSP1, p.2-22
JAUD1, p.2-27
2-2

Quick Components Guide

CPUFAN1, p.2-17
CPU, p.2-3
JUSB1, JUSB2,
p.2-28
DDR DIMMs, p.2-7
JCI1, p.2-30
ATX1, p.2-9
FDD1, p.2-16
IDE1, IDE2, p.2-18
BATT
+
JBAT1, p.2-31
JDB1, p.2-29
SATA1, SATA2,
p.2-19
IDE3, p.2-20
SATA3, SATA4,
p.2-20
SFAN1, p.2-17
JIR1, p.2-30
JFP1, p.2-26
JFP2, p.2-26
J1394_1, J1394_2,
J1394_3, p.2-24
