Promise 20378 On-Board (Optional)
Supports Ultra ATA, Serial ATA, Ultra ATA RAID 0 or 1 , Serial ATA RAID
0 or 1, Ultra/Serial ATA RAID 0+1 supported.
Connect up to 2 Serial ATA devices and 2 Ultra ATA 133 devices.
On-Board Peripherals
On-Board Peripherals include:
- 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and
2.88Mbytes
- 1 serial port COM1, 1 VGA port (for 865G only) (Optional)
- 1 parallel port supports SPP/EPP/ECP mode
- 8 USB 2.0 ports (Rear * 6/ Front * 2 or Rear * 4/ Front * 4)
- 1 Line-In/Line-Out/Mic-In port
- 1 RJ45 LAN jack (Optional)
- 3 IEEE 1394 pinheaders (Optional)
Audio
6 channels software audio codec C-Media 9739A.
- Compliance with AC97 v2.2 Spec.
- Meet PC2001 audio performance requirement.
- Can support SPDIF Out via S-Bracket only.
LAN (Optional)
®
Intel 82547EI (CSA interface) /Intel
- Integrated Fast Ethernet MAC and PHY in one chip.
- Supports 10Mb/s, 100Mb/s and 1000Mb/s (1000Mb/s only for Intel
82547EI).
- Compliance with PCI 2.2.
- Supports ACPI Power Management.
BIOS
The mainboard BIOS provides "Plug & Play" BIOS which detects the
peripheral devices and expansion cards of the board automatically.
The mainboard provides a Desktop Management Interface (DMI) function
which records your mainboard specifications.
Dimension
ATX Form Factor: 30.5 cm (L) x 24.4 cm (W).
Mounting
9 mounting holes.
®
82562EZ Dual layout.
Getting Started
®
1-3
