VIA EPIA SP-Series Specifications

Processor
Chipset
System Memory
VGA
Expansion Slot
Onboard IDE
Onboard LAN
Onboard Audio
Onboard TV Out
Onboard 1394
Onboard I/O
Connectors
Back Panel I/O
BIOS
System
Monitoring &
Management
Form Factor
August 17, 2004
- VIA C3/EDEN EBGA Processor
- VIA CN400 North Bridge
- VT8237 South Bridge
- 1 DDR400/333/266 DDR SDRAM slot
- Up to 1GB memory size
- Integrated VIA UniChrome™ Pro AGP Graphics
- 1 PCI
- 2 UltraDMA 133/100 connectors
- VIA VT6103 10/100 Base-T Ethernet PHY
- VIA VT1617A 6 channel AC'97 Codec
- VIA VT1623 TV Encoder
- VIA VT6307S IEEE 1394 Firewire
- 3 USB connectors for 6 USB 2.0 ports
- 2 Serial ATA ports
- 1 1394 connector for 1 1394 port
- 1 serial port connector for a second com port
- 1 VIP connector
- 1 Front-Panel Audio connector (Mic-in and Line-Out)
- 1 CD Audio-in connector
- 1 FIR connector
- 1 CIR connector (Switchable for KB/MS)
- 1 LPT port connector
- 1 Wake-on-LAN connector
- 2 FAN connectors: CPU and SYS FAN
- 1 LVDS/TTL module connector (Manufacturing option)
- 1 +12V power connector
- ATX Power connector
- 1 PS2 Mouse port
- 1 PS2 Keyboard port
- 1 RJ-45 LAN port
- 1 Serial port
- 2 USB 2.0 ports
- 1 VGA port
- 1 RCA port (SPDIF or TV out)
- 1 S-Video port
- 3 Audio jacks: line-out, line-in and mic-in (Horizontal, Smart 5.1
support)
- Award BIOS
- 4/8Mbit flash memory
- CPU voltage monitoring
- Wake-on-LAN, Keyboard-Power-on, Timer-Power-on
- System power management
- AC power failure recovery
- Mini-ITX (6 Layer)
- 17 cm x 17 cm
- 3 -
EPIA SP-Series Operating Guide
Version 1.00
