audium Comp 3.2 Active User Manual page 8

Controls and Connectors of Comp 3
1
3
1
4
1. Display: OLED graphic display shows the current speaker status.
2. Knob / push-button for navigation in the menu and setting of the parameters.
Power LED: lights red when speaker is active, dimmed red when in standby
3.
4. Line - Input: Connect this input with the Pre - Out of your audio source
5. Speaker Input:
Note: Note the polarity + (red) and - (white).
6. Power socket: Insert here the end of the power supply cable.
Power Supply
The AUDIUM Active
The outsourcing of the power supply from the speaker prevents mutual unwanted
influencing the Amplifier electronics, the chassis and the power supply.
Furthermore, this allows a simple upgrade of the power supply to a higher- performance
type.
The power supplies of Comp7 Active, Comp8 and Comp9
additionally a power switch. Switch on the power supply with it when all connections have
been made.
Power-LED
Stromversorgungs-Stecker
Active
6
Connect these jacks to the speaker cable.
and drive Speakers have an external power supply.
- 9
.2 .2
Drive
5
Active
- 8 -
and drive have
Netzschalter
Netzbuchse
