- Page 1 Comp Active Drive User Manual...
- Page 2 - 2 -...
- Page 3 Thank you very much for your trust in AUDIUM products! This AUDIUM speakers are the key to a realistic, three-dimensional music reproduction with outstanding dynamics and detail. Active Version lets you connect to devices with built-in preamp and or sources with regulated audio output.
-
Page 4: General Information
After this period, the loudspeakers can develop their full acoustic potentials. For the burn-in of your new AUDIUM loudspeakers, you should play back music signals with a very broad frequency spectrum for min. 2 days. Preferably you can use a special Burn-In CD (containing pink noise signal) or you radio receiver after tuning it to an unassigned frequency so you can just hear noise. -
Page 5: Unpacking The Speakers
Spikes: AUDIUM floor speakers radiate sound best when the front battle is inclined for a fewdegrees. Therefor screw the front spikes for 5mm, the rear spikes totally into the designated winding-drills. -
Page 6: Speaker Placement
Speaker Placement Listening Position: As shown in the illustration, the two speakers and your listening position ideally form an isosceles triangle with the edge lengths A and B. The distance A between the Speakers should be smaller than the distance B between the speakers and yours Listening position. - Page 7 Connect these jacks to the speaker cable. Note: Note the polarity + (red) and - (white). 6. Power socket: Insert here the end of the power supply cable. Power Supply: The AUDIUM Active drive Speakers have an external power supply.
-
Page 8: Connecting The Speakers
Since the integrated sound card of computers / laptops often do not meet the sound level of AUDIUM speakers it is recommended to use an external DAC which you connect to your computer via USB or TosLink. -
Page 9: Activating The System
Plug the power cord into the power adapter, and LAST the mains plug into the mains socket For Comp7, 8 and 9, turn the power switch to the "on" position. The speakers then "boot". They show the AUDIUM logo, followed by the status indicator (as shown below). - 9 -... -
Page 10: Operation
Operation: The display shows the current status, settings and the setup menu. Use the rotary knob to adjust the settings on the speaker: Turn clockwise or anticlockwise to navigate through the menu / change values. You can also use it to lock or mute the speaker (see below "Mute and Lock of the loudspeakers"). - Page 11 The Settings Navigation through the menu is easy: turn the knob while the status is displayed to open the settings menu. Navigate through the menu by turning the knob. When you have found the setting you want to change, press the knob, and then change the value. Press again the button to save the value.
- Page 12 EQ menu: Active Drive At AUDIUM loudspeakers you can configure two or one EQ (aka parametric equalizer) to lower or raise frequencies. This makes it possible to increase or decrease a frequency band. It can be used to correct drone frequencies or room resonances.
- Page 13 Setup Menu: Here you can adjust further speaker parameters: Symbol Menu Description Comment Auto Off Time after which the Default value 15 minutes loudspeaker goes into standby without a music signal Mute Duration after which the Default value 10 seconds duration muting is automatically canceled.
- Page 14 Impressum: This User Manual © 2019: AUDIUM - Siegesleitner & Urban GbR Grossbeerenstr. 146 12277 Berlin Deutschland Version 1.0.0 – vom Dienstag, 6. Oktober 2020 Questions and suggestions to: Klaus Siegesleitner – siegesleitner@audium.com ist a registered Trademark - 14 -...
