Vestil TDT-100-HD Series Assembly Manual

TDT-100-HD S
Step 1: Fasten the casters (2) to the carriage. [NOTE:
Attach casters before attaching carriage to bottom of bin.]
Align the bolt holes in the mounting brackets of the
casters with the corresponding bolt holes in the cross
rails of the undercarriage; then install the (small) caster
bolts through the holes and secure them with hex nuts as
shown in FIG. 1B.
FIG. 1A: Attach carriage to bin
Large hex head screw
Tighten hex nut against metal hub
to secure wheel on post
Copyright 2015 Vestil Manufacturing Corp.
Rev. 2/17/2015
V
ESTIL
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
www.vestilmfg.com
H D M
ERIES EAVY UTY
A
SSEMBLY
Step 3: Slide a wheel onto each end
of the axle. The threaded ends of the
axle should project from the wheel
hubs. Secure each wheel to the axle
with hex nuts.
M
ANUFACTURING
Fax: (260) 665-1339
e-mail:
P
OLDED OLYURETHANE
M
ANUAL
Step 2: Fasten the carriage to the underside of the bin at
the four locations highlighted with light-colored arrows
below. To attach the carriage to the bin, use the 4 large hex
head screws provided with the product. Insert the screws
through slots in the cross rails of the undercarriage and into
the bin as shown in FIGS. 1A & 1B.
FIG. 1B: Attach casters
Carriage
TDT-100-HD, MANUAL.doc
C .
ORP
sales@vestil.com
3
B (1 )
INS YD
Cross
Hex head
Caster
rail
screw
bolt and
hex nut
Mounting
bracket
Side rail of carriage
Page 1 of 2
