Vestil TDT-50-HD Series Assembly Manual

TDT-50-HD S
Step 1: Fasten the casters (2) to the carriage. [NOTE:
Attach casters before attaching carriage to bottom of bin.]
Align the bolt holes in the mounting brackets of the
casters with the corresponding bolt holes in the cross
rails of the undercarriage; then install the (small) caster
bolts through the holes and secure them with hex nuts as
shown in FIG. 1A.
FIG. 1A: Attach casters
Hex
head
screw
Cross rail
of carriage
FIG. 1B: Attach wheels to axle
Tighten hex nut against metal
hub to secure wheel on axle
