Vestil TDT-50-LD Series Assembly Manual

TDT-50-LD S
Step 1: Fasten the casters (2) to the undercarriage.
[NOTE: Attach casters before fastening undercarriage to
bottom of bin.] Referring to FIG. 1A, insert the threaded
stem of each caster into the threaded bolt hole in the side
rail (of the undercarriage); then install hex nuts on the
ends of the stems and tighten the nuts against the side
rail.
FIG. 1A: Attach casters
Hex head
screw
Side rail of carriage
FIG. 1C: Attach wheels to axle
Tighten hex nut against metal
hub to secure wheel on axle
