CreatBot D600 Pro2 HS User Manual page 10

Screen operation
Filament
Main Menu
Click to activate the extruder.
Blue means it is activated.
Select the filament to quickly set
the extrusion temperature
Automatic loading/unloading filament
Extrude and retract filament according to set length/speed
5mm 10mm 15mm 25mm 1mm/s 2mm/s 5mm/s 25mm/s
Set the length and speed of extruding/retracting filament
Inserted Inserted
Detect the current filament status. Click the button to turn off the
filament detection function.
- 10 -
