Fulmer
ZG6951
Sensor-Operated Gear Driven Type
Faucets with Battery Powered,
Hardwired or Connected
Installation, Operation, Maintenance
and Parts Manual
ZG6951
LIMITED WARRANTY
Series
®
Advertisement
Table of Contents
Related Manuals for ZURN Fulmer ZG6951-E
Summary of Contents for ZURN Fulmer ZG6951-E
- Page 1 NOTICE: READ ENTIRE MANUAL PRIOR TO INSTALLING PRODUCT. AVIS : LIRE L’ENSEMBLE DU MANUEL AVANT D’INSTALLER LE PRODUIT Rev: B | Date: 06/20/24 | C.N. No. 146057 | Prod./Dwg. No. FV850 Patent zurn.com/patents US 1.855.ONE.ZURN CANADA 1.877.892.5216 ZURN.COM...
-
Page 2: Specifications
Aerator: 0.5 GPM Vandal-Resistant (Standard) Important Safety Information • Do not convert or modify this Zurn product. All warranties will be voided. • All plumbing is to be installed in accordance with applicable codes and regulations. • Water supply lines must be sized to provide an adequate volume of water for each fixture. • Flush all water lines prior to making connections. - Page 3 The following information refers to Zurn Smart Connected Products, types: -W2. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference intended for use in non-residential/non-domestic environments.
-
Page 4: Package Contents
Package Contents Hydrogenerator Electronics module Batteries ZG6951 Faucet Body & Mounting Hardware Connected Monitor (If ordered) Aerator & Key Required Tools Optional Accessories 3/32” & M3 Hex Key Wrenches Adjustable Wrench (Supplied) AC/DC Power Supply P6900-ACA Phillips Head Screwdriver * For more accessories see the Parts List on the last page. FV850 Rev. - Page 5 Cover Plate Installation Instructions Pass the sensor connector and shank through the cover plate, securing them to the faucet using the supplied screws. Spout Installation Instruction NOTE: Before installation, turn off water supplies to existing faucet and remove faucet if replacing an existing device. Clean the faucet basin and clear away debris.
- Page 6 7. Connect sensor cable from electronics module to sensor cable from spout. To customize the following individual electronics module settings, download Zurn plumbPRO App. • Adjustable Time Out Feature • Hygienic Line Flushing • Sensing Mode • Sensor Range Adjustment •...
- Page 7 Connected Monitor Installation Instructions (-W2) NOTE: Follow and complete Electronics Module Installation Instruction before continue. 1. Install Connected Monitor on wall surface within 2 feet radius 2. Loosen lid screw with supplied 3mm hex key wrench and open the lid. of faucet with dry wall anchors &...
- Page 8 Mixing Valve Installation (All Configurations) Faucet Control Box -SSH Option P6900-MV-ADAP Braided Hose Supplied Adapter -MV Option Mixing Valve -TMV-1 Option 3/8 Copper Tube Thermostatic (Not Supplied) Mixing Valve Note:To install Braided Hose, need to hold swivel nut on control box or mixing valve in position then apply torque by hand or wrench to install.
- Page 9 Spout Replacement NOTE: To replace spout body, you must first turn water off, then remove spout with sensor cable. 1. Before removing the spout, ensure to disconnect the sensor 2. Note location of set screw and spring lock. cable bebeath the deck, allowing the cable head to be pulled up through the deck.
- Page 10 Zurn connected product. 3. Drill holes for the screws and insert anchors. 4. Zurn Gateways have been set to DHCP by default. Please 4. Place the mounting bracket and secure it with screws. consult local IT support for possible additional access requirements for your network.
- Page 11 Register in plumbSMART (-W2) NOTE: Instructions below are duplicated from registration card supplied with monitor Install Zurn Connected Product(s) Install Zurn Gateway per the Gateway Instructions Manual Request plumbSMART Administrator Account at 844-987-6737 Zurn creates your Enterprise Account for you! (You will be required to identify your building location, number of floors, and number of rooms.) Log in to plumbsmart.zurn.com Register each Connected Product in plumbSMART (Watch How-To Videos to Get Started. Located in the support section inside the portal.)
- Page 12 If the shank, is missing. gasket is not installed, proceed to install it. In case of any damage, replace the gasket with a new one. For further assistance with troubleshooting visit http://www.zurn.com FV850 Rev. B 06/20/24 Page 11...
- Page 13 Details tab is listed as “Activated” NETWORK: Senet SUBSCRIPTION STATUS: Activated LAST HEARD FROM: 07/14/2020, 04:29 PM CDT If listed as “Deactivated”, contact Zurn Customer Service at 1.855.ONE.ZURN (1.855.663.9876) for assistance. “Status – Good” posted in plumbSMART and faucet not Step 1 actuating Verify LoRa Monitor’s cables are connected to IR sensor...
- Page 14 If LORA LED does not turn ON solid and ethernet cable connected, contact facility IT administrator to modify port rules to allow Zurn gateway to access the internet via local router. If gateway model is ETH/LTE, visually verify SIM card is installed in designated slot on the side of gateway.
- Page 15 ZG6951 Parts List 9 & 10 Description Product No. Description Product No. Item 1: ZG6951 Spout Assembly with Item 12: Composite Mixing Valve Adapter P6900-MV-ADAP P6951-XL-S-1 Sensor Item 13: Thermostatic Mixing Valve P6900-TMV-1-XL Item 2: Spout Shank Base P6950-XL-B Item 14: Optional Plug-in Power Converter P6900-ACA Item 3: Mounting Kit P6900-43...
