Front Panel Functions - continued -
E: Track number display indicates the track being
played.
F: Repeat indicator lights up when repeat mode is
enabled.
Sampling Frequency display
Sampling frequency of a selected music source
being played is displayed. PCM or DSD depends on
the input signal lights up as well.
Digital Source indicator
Selected USB, COAX or TOS lights up. CD does not
light up.
Digital Filter indicator
Selected digital filter type PULSE or FLAT lights up.
CD Door knob
Open or close the CD door sliding backward or
forward by hand when placing a compact disc on the
tray. To keep the inside clean always close the CD
door.
Inside the CD Door
O A
X
T O
S
U L
S E
P C
M
D S
D
Optical Laser Pickup Lens
The optical laser pickup reads music signals from
a compact disc. To keep it clean never touch the lens
with your fingers, etc., and always close the CD door.
CD Stabilizer
The CD Stabilizer for CD5 is heavy with a diameter
of 7cm and weighing 330g.
Handle with care. Hold the edge steadily
when placing on or removing it from the
CD-Turntable in the CD tray. Dropping the
CD Stabilizer may damage it and decrease
playback accuracy.
CD-Turntable
Place a compact disc on the CD-Turntable, and
place the CD Stabilizer on top of the disc. The CD
Stabilizer can be placed on the CD-Turntable when not
in use, even when no disc is in place.
Rubber Belt
Square rubber belt to drive a disc on the CD -
Turntable. Periodic maintenance is not required. The
tension of the belt may be lowered by using for years
which may affect the disc rotation accuracy. Refer to
page 17 to replace the belt.
