Belt Drive CD Player
USB Sound System
Installation and Setup Guide
for USB Driver on Windows PC
Thank you for purchasing a CD5.
This guide book will show you how to install and setup the CD5 USB
driver at your Windows PC to playback music files through USB
connection.
POWER
SOURCE
CD5
HEADPHONE
BELT DRIVE CD PLAYER CD5
VOLUME

Advertisement

loading
Need help?

Need help?

Do you have a question about the CD5 and is the answer not in the manual?

Questions and answers

Related Manuals for C.E.C. CD5

Summary of Contents for C.E.C. CD5

  • Page 1 Installation and Setup Guide for USB Driver on Windows PC Thank you for purchasing a CD5. This guide book will show you how to install and setup the CD5 USB driver at your Windows PC to playback music files through USB connection.
  • Page 2 OS or Browser. USB Driver (Your PC recognizes CD5 as a regular audio device.) ▷   B RAVO-HD (is the USB driver specialized in CD5, supplied by SAVITEC, USB Audio IC manufacturer.) Necessary components to reproduce DSD fi...
  • Page 3 CD5 USB Driver Installation and Setup USB Driver Installation Install a USB driver, BRAVO-HD on your Windows PC to recognize CD5 as USB audio device and playback PCM music fi les. BRAVO-HD is an exclusive USB driver that a USB Audio IC maker, SAVITEC company provides for CD5.
  • Page 4 CD PLAYER / USB SOUND SYSTEM CD5 1.4. BRAVO-HD install wizard will start. Click "Next" to continue. 1.5. Select an install folder and Windows user. Click "Browse" to select an installation folder other than the default folder being showed. Select "Everyone" for all Windows users to use BRAVO-HD or "Just me" only for the user that is installing the driver now.
  • Page 5 CD5 USB Driver Installation and Setup Click "Next" to start the installation. When the installation fi nishes a short-cut icon "BRAVO-HD Audio CPL" will be created on desktop and the restart wizard will appear. Click "Yes(Y)" to restart the computer.
  • Page 6 Sound property on WindowsXP Sound property on Windows7 1.10. Starting a PC-music after selecting the USB input on CD5 you can listen to the playback music through the analog or headphones output on CD5. CD5 USB input is compatible with up to 32bit/384kHz PCM signal but the sampling frequency may be limited by the system setting or PC-Music player.
  • Page 7 Installation and Setup to play DSD fi les Installing ASIO and DSD drivers to a freeware pc-music player foobar2000 for Windows DSD64(2.8224MHz) and DSD128(5.6448MHz) fi les can be played through CD5. Before starting these steps install foobar2000 to your Windows PC, which can be downloaded from http://www.foobar2000.org/.
  • Page 8 CD PLAYER / USB SOUND SYSTEM CD5 The installing component "foo_out_asio" will be listed up marked with (unknown). Click "Apply" to continue the installation. Click "OK" to complete the installation and change. foobar2000 will restart.
  • Page 9 CD5 USB Driver Installation and Setup Installation for foobar2000 ASIO Proxy 3.1. Double-click "ASIOProxyInstall-0.6.0.exe" in the "cd5_dsd-plugin_fb2k" folder. 3.2. Click "Next" on ASIO Proxy for foobar2000 Setup wizard to continue.
  • Page 10 CD PLAYER / USB SOUND SYSTEM CD5 3.3. Select an install folder. Click "Browse" to select a folder other than the default folder being showed. Click "Install" to start the installation. 4.2. Install will fi nish soon and click "Close" to complete the installation.
  • Page 11 CD5 USB Driver Installation and Setup 4. Installation for foobar2000 DSD Driver 4.1. Double-click "foo_input_sacd.fb2k-component" in the "cd5_dsd-plugin_fb2k" folder 4.2. foobar2000 Component Installer will start. Click "Yes(Y)" to continue.
  • Page 12 CD PLAYER / USB SOUND SYSTEM CD5 The installing component "foo_input_sacd" will be listed up marked with (unknown). Click "Apply" to continue the installation. Click "OK" to complete the installation and change. foobar2000 will restart.
  • Page 13 CD5 USB Driver Installation and Setup 5. DSD Playback Setting on foobar2000 5.1. Click "File" on foobar2000 to open "Preferences". 5.2. Click "Tools - SACD" on the left side tree and select "DSD" at ASIO Driver Mode. 5.3. Click "Playback - Output - ASIO" on the left side tree, and double-click "foo_dsd_asio"...
  • Page 14 CD PLAYER / USB SOUND SYSTEM CD5 5.4. Dialog for foo_dsd_asio v0.6.0 setting will appear. Select "BRAVO-HD" at ASIO Driver. Select "ASIO Native", "DoP marker" or "dCS Marker" at DSD Playback Method. Note: ASIO Native is not compatible with DSD128.
  • Page 15 In order to avoid any interruption or affection from PC upon listening to your desired music through ASIO at foobar2000, set the output of reproduction to the other than CEC CD5 HS USB Audio at Sound and Audio Device property at your PC (refer to page 6). The volume control and/or mute function can be operated by foobar 2000 and/or amplifi...
  • Page 16 CD PLAYER / USB SOUND SYSTEM CD5 BRAVO-HD Control Panel 1. Start "BRAVO-HD Audio CPL" from the short- 2. Turning on CD5 connected via USB cable the BRAVO-HD control panel will change to show cut on desktop or programs menu. BRAVO- a current setting.
  • Page 17 CD5 USB Driver Installation and Setup 3. Changing the sample rate and bits per sample on BRAVO-HD control panel the Windows system setting on "sound - digital output property" will change accordingly, and vice versa. Note: Setting 352.8kHz or 384kHz the sound from ex. an internet browser may be unstable...
  • Page 18 CD PLAYER / USB SOUND SYSTEM CD5 4. PCM, bit rate, sampling frequency and buffer Ex. Playback after changing the bit rate and size of a current PCM playback via ASIO like buffer size during stop will show the new a foobar2000 output setting are displayed.
  • Page 19 CD5 USB Driver Installation and Setup 5. Displaying a DSD64/2.8MHz playback. 6. Displaying a DSD128/5.6MHz playback. Note: When playing a DSD file set the bit rate 24 or 32. 16 bits setting can not play any DSD. Ex. Playback after changing to 32 bits and 10ms buffer during stop will show the new settings.
  • Page 20 CEC Holdings Co., Ltd., Japan 1701-D...
