Summary of Contents for Liberty Digitalinx DL-HD70-H3
Page 1
USER MANUAL DL-HD70-H3 Owners Manual Digitalinx Series HDBaseT 3.0 70m Extension Set 18G HDBaseT 3.0 HDMI 2.0 Extender set extends uncompressed resolutions up to 4K60 4:4:4, IR,RS232 & Power up to 40m or 70m with built in test pattern generator and adjustable bandwidth mode for maximum cable compatibility.
PRODUCT OVERVIEW The Digitalinx DL-HD70-H3 HDBaseT 3.0 extender set transmits video, audio, IR, and RS232 over single category 6a F/UTP or better twisted pair cable.The DL-HD70-H3 can transmit uncompressed 4K resolutions up to 4K@60Hz 4:4:4 up to 40m / 131’ and 4K30 or below up to 70m / 230’. The Digitalinx DL- HD70-H3 supports HDMI 2.0 and is HDCP 2.2/2.3 compliant and supports CEC pass through.
Page 3
Transmission Distance Note: Straight-through category cable wired T568B standard recommended. For max HDMI 2.0 performance, recommended cable is: Cat 6A U/FTP or F/FTP. The extender supports two transmission modes: High-bandwidth and Low- bandwidth. When the extender is set to High-bandwidth mode (set the pin4 of the DIP switches of the transmitter and receiver to “Up”...
Display Video Source Maximum Distance HDMI HDMI Cable Cable Wall mounted link segment Patch Patch VS3100RX VS3100TX RJ45 RJ45 The standard specifies the following lengths for the three-segment cable installation: X = Left-side patch cable length ≤ 5 [meter] Y = Right-side patch cable length ≤...
Name Description On: HDBT link is normal. LINK LED Off: No HDBT link or link error. Green: Source video is being transmitted. Red: Pattern video with HDCP is being transmitted. VIDEO LED Blue: Pattern video without HDCP is being transmitted. Off: No video is being transmitted.
Name Description HDBT OUT Connect to the HDBT IN port of the receiver. HDMI IN Connect to an HDMI source device. Connect to an HDMI display for video looping out. Note: When input 4K@60Hz signal in Low- HDMI OUT bandwidth mode, this loop-out port doesn’t support downscaler function.
Page 7
Installation and Wiring Installation Warnings: Before wiring, disconnect the power from the device. During wiring, connect and disconnect the cables gently. Steps to install the device: Attach the installation bracket to the enclosure using the screws provided in the package separately. The bracket is attached to the enclosure as shown.
Page 8
Audio and Video Extender Mode: Connect an HDMI source to HDMI IN port of the transmitter, and connect an HDMI display to HDMI OUT port of the receiver. Connect the transmitter and the receiver. Connect the provided power adapter to the transmitter or receiver. Power on all attached devices.
Page 10
Cat x Figure 2 Additional control connection selection: RS232 Pass-through: Connect a RS232 control system/controlled device to the transmitter/receiver, and connect a RS232 controlled/control system device to the receiver/transmitter for serial communication. See “RS232 Pass-Through” section to get detail information. IR Pass-through: Connect the IR emitter cable provided to IR OUT port of ...
port of the receiver/transmitter. Users can control the source at the receiver side using source remote or control the display at the transmitter side using display remote (See Figure 1). Test Pattern Generation DL-HD70-H3 extender kits purchased after 2/15/25 can generate a test pattern video signal, with different HDCP capabilities.
DIP Switch Settings Using DIP Switches on front panel of the transmitter and receiver to set audio mode, set upgrade function and bandwidth rate. 1 2 3 4 Please refer to the following table to set: Transmitter: Function Audio EDID 2CH (default) Down Audio EDID pass-through Audio de-embed (default)
Page 13
port of the receiver. If audio source signal is compressed audio, AUDIO OUT port will be muted. Both Valens firmware of the transmitter and receiver can be upgraded through FW port of the transmitter/receiver. Set the DIP switch of the transmitter/receiver to “x, x, Up, x”.
RS232 Pass-Through RS232 ports can be used for bi-directional RS232 signal pass-through between the transmitter and receiver. Connect a RS232 master/slave Device to RS232 port of transmitter /receiver and connect a slave/master device to RS232 port of receiver/transmitter. Connect HDBT OUT of the transmitter to HDBT IN of the receiver. When all is set, RS232 signal can be passed through bi-directionally between two RS232 devices.
Page 15
Cabling Requirements HDBaseT Cabling HDBaseT3.0 Specification is made using high quality Cat6a F/UTP cabling. For maximum full capability performance, ensure Cat6a F/UTP or above is used.To ensure proper performance of the DL-HD70-H3, it is recommended that you use solid core, shielded Category 6a F/UTP or above cabling.
TECHNICAL SPECIFICATIONS Model DL-HD70-H3 Physical Parameter Case Material Receiver: Industrial-grade metal chassis with metal brackets Transmitter: Industrial-grade metal chassis with metal brackets Dimensions Transmitter: 190mm [W] x 115mm [D] x 23mm [H] Receiver: 190mm [W] x 115mm [D] x 23mm [H] Weight Transmitter: 265g Receiver: 265g...
Page 17
Thank you for your purchase. For technical support please call our toll-free number at 800-530-8998 or email us at supportlibav@libav.com www.libav.com 800-530-8998 Rev 221712 OWNERS MANUAL DL-HD70-H3...
