- Page 1 USER MANUAL DL-HD70-H3 Owners Manual Digitalinx Series HDBaseT 3.0 70m Extension Set 18G HDBaseT 3.0 Extender set extends uncompressed resolutions up to 4K60 4:4:4, 40m or IR,RS232 & Power up to www.libav.com 800.530.8998...
-
Page 2: Product Overview
PRODUCT OVERVIEW The Digitalinx DL-HD70-H3 HDBaseT 3.0 extender set transmits video, audio, IR, and RS232 over single category 6a F/UTP or better twisted pair cable.The DL-HD70-H3 can transmit 4K resolutions up to 4K@60Hz, 4K30 or below supports 4:4:4 up to 40m / 131’ up to 70m / 230’. - Page 3 TRANSMITTER PRODUCT BREAKDOWN 1. Power LED (Red) :When the red power LED is on the transmitter has power. 2. Status LED (Green) : When blinking the units are working properly. 3. Link LED (Green) : Link LED is on, the transmitter and receiver have a good connection. When it's off the units are not connected.
- Page 4 RECEIVER PRODUCT BREAKDOWN 1. Power LED (Red) :When the red power LED is on the transmitter has power. 2. Status LED (Green) : When blinking the units are working properly. 3. Link LED (Green) : Link LED is on, the transmitter and receiver have a good connection. When it's off the units are not connected.
-
Page 5: Configuration Settings
CONFIGURATION SETTINGS DIP SWITCH on Receiver EDID MODE 1 is up and 2 is up Copy display's EDID (factory default) 1 is up and 2 is down 4K 30 4:4:4 1 is down and 2 is up 1080p60 4:4:4 1 is down and 2 is down 1200p60 4:4:4 APPLICATION DIAGRAM Below is an example of an extender set in a typical application. - Page 6 HDBaseT reliably and may only work over short distances. When using shielded category cabling ALWAYS..use shielded connectors ..properly ground the category cable For optimized HDBaseT performance use the following Liberty Wire and Cable branded cabling; Category 6 plenum; 24-4P-P-L6SH Category 6A plenum; 24-4P-P-L6ASH Category 6 NON-plenum;...
-
Page 7: Technical Specifications
TECHNICAL SPECIFICATIONS Model DL-HD70-H3 Physical Parameter Case Material Receiver: Industrial-grade metal chassis with metal brackets Transmitter: Industrial-grade metal chassis with metal brackets Dimensions Transmitter: 170mm [W] x 105mm [D] x 25mm [H] Receiver: 170mm [W] x 105mm [D] x 25mm [H] Weight Transmitter: 265g Receiver: 265g... - Page 8 Thank you for your purchase. For technical support please call our toll-free number at 800-530-8998 or email us at supportlibav@libav.com www.libav.com 800-530-8998 Rev 221712 OWNERS MANUAL DL-HD70-H3...
