Summary of Contents for d&b audiotechnik Z5602.552

  • Page 1 Z5602.552 Manual 1.2 en...
  • Page 2: General Information

    Notes on document version Version 1.2: New DN1 chapter ⇒ “Factory reset”  on page 15 General information Z5602.552 Manual Version: 1.2 en, 03/2025, D2773.US .01 Copyright © 2025 by d&b audiotechnik GmbH & Co. KG; all rights reserved. Keep this document with the product or in a safe place so that it is available for future reference.
  • Page 3: Important Safety Instructions

    9. Unplug the rack assembly during lightning storms or when – Do not operate the rack assembly while it is wet or standing unused for long periods of time. in liquid. d&b Z5602.552 Manual 1.2 en...
  • Page 4: Table Of Contents

      Contents   Z5602.552 D90 Touring rack assembly 10 RU - NEMA..................5 1.1  Intended use................5 1.2  Scope of supply................5 1.2.1  Z5602.053 Preassembled rack (optional)Z5603.003 Preassembled rack (optional)..........6 Handling, cooling and placement......... 7 2.1  Handling..................7 2.2  Cooling and placement.............. 7 Z5610.001 Mains Power Distributor and LS...
  • Page 5: Z5602.552 D90 Touring Rack Assembly 10 Ru - Nema

      1  Z5602.552 D90 Touring rack assembly 10 RU - NEMA   1.1  Intended use The Z5602.552 D90 Touring rack assembly NEMA is designed as a closed system rack providing mains power distribution and connector interfaces for three D90 amplifiers. For this purpose, the touring rack is equipped with a mains power distribution device (Z5610.001), which also serves as a loudspeaker connector...
  • Page 6: Z5602.053 Preassembled Rack (Optional)Z5603.003 Preassembled Rack (Optional)

    For wiring details, please refer to [*7]: Remove the transport protection before mounting the amplifiers. ⇒ Chapter 6 “Rack wiring diagrams” on page 17. Z5604.000 I/O Panel. Z4001 DN1 Network switch. Z5333.001 Rack link network.     D2773.US .01 Z5602.552 Manual. d&b Z5602.552 Manual 1.2 en...
  • Page 7: Handling, Cooling And Placement

    Z5602 / Z5603 D90 Touring rack assembly or any other touring rack containing D90 amplifiers, make sure to provide sufficient space of 0.5 m (1.6 ft) at the front and rear of the touring rack to ensure adequate cooling airflow. d&b Z5602.552 Manual 1.2 en...
  • Page 8 ▪ Do not stack D12 Touring racks or any other rack assemblies with opposing airflow on top of the D90 Touring Rack. ▪ D90/D12 Touring rack assemblies can be positioned side by side. d&b Z5602.552 Manual 1.2 en...
  • Page 9: Z5610.001 Mains Power Distributor And Ls Panel  - Nema

    The Z5610.001 Mains power distributor is supplied with a NEMA 30 A 3ØY 120/208 VAC male connector socket that accepts max. a corresponding NEMA female connector. Required mains supply network configuration 30 A 3ØY 120/208 VAC 50-60 Hz, B or C-Frame type. max. d&b Z5602.552 Manual 1.2 en...
  • Page 10: Amp 1 / Amp 2 / Amp 3 Mains Supply

    One of these sockets is used to apply mains supply for the DN1 device. The remaining sockets are intended for the connection of low current devices such as notebooks or additional Ethernet switches. The sockets are equipped with dedicated circuit-breakers (20 A / B-Frame type). d&b Z5602.552 Manual 1.2 en...
  • Page 11: Amplifier Mains Outputs

    1+/— = Channel A pos. / neg. 2+/— = Channel B pos. / neg. 3+/— = Channel C pos. / neg. 4+/— = Channel D pos. / neg. Please refer to the corresponding channel assignment label above each connector as shown in the graphic opposite. d&b Z5602.552 Manual 1.2 en...
  • Page 12: Output

    12 CH OUTPUT AMP 1/2/3 LKA25 Amplifier LKA25 Amplifier LKA25 Amplifier AMP 1 AMP 2 AMP 3 1– 1– 1– 2– 2– 2– 3– 3– 3– 4– 4– 4– d&b Z5602.552 Manual 1.2 en...
  • Page 13: Z5604 I/O Panel

    DN1 when linking entire rack assemblies, as shown in the graphic opposite. It is recommended to link a maximum of up to 6 rack assemblies in this way. I/O panel, rack link: 2ch Analog audio and Ethernet/OCA d&b Z5602.552 Manual 1.2 en...
  • Page 14: Dn1 Ethernet Switch

    Reset the device to factory defaults maintaining remote settings. ▪ Configuration Toggle between primary and secondary configurations. ▪ Remote reset Reset all remote settings to factory defaults. ▪ Wink (device identification) Visual identification of the device. d&b Z5602.552 Manual 1.2 en...
  • Page 15: Factory Reset

    ⇒ Push the «MODE» button once. ↳ All AVB port status LEDs flash in the color of the current Configuration mode ( = Primary / = Secondary). After three seconds, the Wink mode stops automatically. d&b Z5602.552 Manual 1.2 en...
  • Page 16: Led Indicators

    Secondary Device in SEC AVB network detected. network mode. Active PoE supply. LED off Normal operation. No active connection. No AVB network No PoE enabled information. device connected. LED flashing - Data traffic. PoE Error. d&b Z5602.552 Manual 1.2 en...
  • Page 17: Rack Wiring Diagrams

      6  Rack wiring diagrams   Mains power connection and internal mains supply distribution d&b Z5602.552 Manual 1.2 en...
  • Page 18     Internal 4 CHANNEL OUTPUT wiring d&b Z5602.552 Manual 1.2 en...
  • Page 19     Internal analog audio INPUT and LINK wiring d&b Z5602.552 Manual 1.2 en...
  • Page 20     Internal digital audio INPUT and LINK wiring d&b Z5602.552 Manual 1.2 en...
  • Page 21     Internal Ethernet network wiring d&b Z5602.552 Manual 1.2 en...
  • Page 23 www.dbaudio.com...
