Summary of Contents for d&b audiotechnik Z5603.552

  • Page 1 Z5603.552 Manual 1.2 en...
  • Page 2: General Information

    Notes on document version Version 1.2: New DN1 chapter ⇒ “Factory reset”  on page 15 General information Z5603.552 Manual Version: 1.2 en, 03/2025, D2775.US .01 Copyright © 2025 by d&b audiotechnik GmbH & Co. KG; all rights reserved. Keep this document with the product or in a safe place so that it is available for future reference.
  • Page 3: Important Safety Instructions

    9. Unplug the rack assembly during lightning storms or when – Do not operate the rack assembly while it is wet or standing unused for long periods of time. in liquid. d&b Z5603.552 Manual 1.2 en...
  • Page 4: Table Of Contents

      Contents   Z5603.552 D90 Touring rack assembly 18 RU -  NEMA..................5 1.1  Intended use................5 1.2  Scope of supply................5 1.2.1  Z5603.053 Preassembled rack (optional)......6 Handling, cooling and placement......... 7 2.1  Handling..................7 2.2  Cooling and placement.............. 7 Z5611.001 Mains power distributor 2 x 30 A NEMA................
  • Page 5: Z5603.552 D90 Touring Rack Assembly 18 Ru - Nema

    Z5603.552 D90 Touring rack assembly 18 RU - NEMA   1.1  Intended use The d&b Z5603.552 D90 Touring rack assembly NEMA is intended for large scale mobile sound reinforcement applications. It is designed as a closed and prewired 18 RU system rack providing mains power distribution and connector interfaces for six D90 amplifiers.
  • Page 6: Dimensions And Weight

    For wiring details, please refer to ⇒ Chapter 7 “Rack wiring diagrams” on page 17. Z5604 I/O panel. Z4001 DN1 Network switch. Z5333.001 Rack link network.     D2775.US .01 Z5603.552 Manual. [*8]: Remove the transport protection before mounting the amplifiers. d&b Z5603.552 Manual 1.2 en...
  • Page 7: Handling, Cooling And Placement

    Make sure both the front and rear doors are opened and pushed into their park positions to provide sufficient cooling. When using the d&b Z5603.552 Touring rack assembly, make sure to provide sufficient space of 0.5 m (1.6 ft) at the front and rear of the touring rack to ensure adequate cooling airflow.
  • Page 8 ▪ Do not stack D12 Touring racks or any other rack assemblies with opposing airflow on top of the Z5603.552 Touring rack. ▪ Z5603.552 and the D12 Touring rack assemblies can be positioned side by side.
  • Page 9: Z5611.001 Mains Power Distributor 2 X 30 A Nema

    The Z5611.001 Mains power distributor is designed and dimensioned to provide and distribute the mains power supply necessary for one Z5603.552 Touring rack assembly. It is a protective class 1 unit with IP class 20 (NOT rain-, drip-, or splash-proof!).
  • Page 10: Rear Panel

    The remaining sockets are intended for the connection of low current devices such as notebooks or additional Ethernet switches. The sockets are equipped with dedicated circuit-breakers on the front panel (20 A / C-Frame type). d&b Z5603.552 Manual 1.2 en...
  • Page 11: Z5578 Ls Connector Panel 6 X Nl8 / 2 X Lka25

    Each connector carries the output signals of all four channels of the amplifier with the following pin assignment. 1+/— = Channel A pos. / neg. 2+/— = Channel B pos. / neg. 3+/— = Channel C pos. / neg. 4+/— = Channel D pos. / neg. d&b Z5603.552 Manual 1.2 en...
  • Page 12: Output

    AMP 4 1– 1– 2– 2– 3– 3– 4– 4– AMP 2 AMP 5 1– 1–   2– 2– 3– 3– 4– 4– AMP 3 AMP 6 1– 1– 2– 2– 3– 3– 4– 4– d&b Z5603.552 Manual 1.2 en...
  • Page 13: Z5604 I/O Panel

    DN1 when linking entire rack assemblies, as shown in the graphic opposite. It is recommended to link a maximum of up to 6 rack assemblies in this way. I/O panel, rack link: 2ch Analog audio and Ethernet/OCA d&b Z5603.552 Manual 1.2 en...
  • Page 14: Dn1 Ethernet Switch

    Reset the device to factory defaults maintaining remote settings. ▪ Configuration Toggle between primary and secondary configurations. ▪ Remote reset Reset all remote settings to factory defaults. ▪ Wink (device identification) Visual identification of the device. d&b Z5603.552 Manual 1.2 en...
  • Page 15: Factory Reset

    ⇒ Push the «MODE» button once. ↳ All AVB port status LEDs flash in the color of the current Configuration mode ( = Primary / = Secondary). After three seconds, the Wink mode stops automatically. d&b Z5603.552 Manual 1.2 en...
  • Page 16: Led Indicators

    Secondary Device in SEC AVB network detected. network mode. Active PoE supply. LED off Normal operation. No active connection. No AVB network No PoE enabled information. device connected. LED flashing - Data traffic. PoE Error. d&b Z5603.552 Manual 1.2 en...
  • Page 17: Rack Wiring Diagrams

      7  Rack wiring diagrams   Mains power connection and internal mains supply distribution d&b Z5603.552 Manual 1.2 en...
  • Page 18     Internal 4 CHANNEL OUTPUT wiring d&b Z5603.552 Manual 1.2 en...
  • Page 19     Internal analog audio INPUT and LINK wiring d&b Z5603.552 Manual 1.2 en...
  • Page 20     Internal digital audio INPUT and LINK wiring d&b Z5603.552 Manual 1.2 en...
  • Page 21     Internal Ethernet network wiring d&b Z5603.552 Manual 1.2 en...
  • Page 23 www.dbaudio.com...
