Getting started with MSP MCUs featuring CapTIvate™ technology

Information about the CapTIvate MCU Development Kit (MSP-CAPT-FR2633) can be found at:

ti.com/msp-capt-fr2633

STEP 1:

Install CapTIvate Design Center

Available as part of MSPWare:

ti.com/tool/mspware

Or as a separate download:

ti.com/captivatedesigncenter

STEP 2:

Install and update your IDE –

Code Composer Studio™ or IAR

Please update your IDE to the latest device

and emulation support for MSP430FR2633

STEP 3:

Getting started with CapTIvate out-of-box

experience demo – Wake-on-proximity

• Connect the CAPT-BSWP demonstration

PCB as shown below

• Attach the micro-USB cable between the

CAPT-PGMR programmer PCB and your PC

• Verify the CAPT-PGMR green LED (Power

Good) is on and the green LED

(USB Enumeration) is blinking

• See next page or visit

ti.com/captivateexperience

for instructions for the

Out-of-box demo
