FEATURES
1
• Low Supply-Voltage Range, 1.8 V to 3.6 V
23
• Ultra-Low Power Consumption
– Active Mode: 270 µA at 1 MHz, 2.2 V
– Standby Mode (VLO): 0.3 µA
– Off Mode (RAM Retention): 0.1 µA
• Ultra-Fast Wake-Up From Standby Mode in
Less Than 1 µs
• 16-Bit RISC Architecture, 62.5-ns Instruction
Cycle Time
• Basic Clock Module Configurations:
– Internal Frequencies up to 16 MHz
– Internal Very Low-Power LF Oscillator
– 32-kHz Crystal
– Internal Frequencies up to 16 MHz With
Four Calibrated Frequencies to ±1%
– Resonator
– External Digital Clock Source
– External Resistor
• 12-Bit Analog-to-Digital (A/D) Converter With
Internal Reference, Sample-and-Hold, and
Autoscan Feature
• 16-Bit Timer_A With Three Capture/Compare
Registers
• 16-Bit Timer_B With Seven Capture/Compare
With Shadow Registers
• Four Universal Serial Communication
Interfaces (USCI)
– USCI_A0 and USCI_A1
– Enhanced UART Supporting Auto-Baudrate
Detection
– IrDA Encoder and Decoder
– Synchronous SPI
– USCI_B0 and USCI_B1
2
– I C™
– Synchronous SPI
1
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
MSP430 is a trademark of Texas Instruments.
2
All other trademarks are the property of their respective owners.
3
PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
MIXED SIGNAL MICROCONTROLLER
SLAS547I – JUNE 2007 – REVISED DECEMBER 2012
• On-Chip Comparator
• Supply Voltage Supervisor/Monitor With
Programmable Level Detection
• Brownout Detector
• Bootstrap Loader
• Serial Onboard Programming, No External
Programming Voltage Needed, Programmable
Code Protection by Security Fuse
• Family Members Include:
– MSP430F233
– 8KB+256B Flash Memory,
– 1KB RAM
– MSP430F235
– 16KB+256B Flash Memory
– 2KB RAM
– MSP430F247, MSP430F2471
– 32KB+256B Flash Memory
– 4KB RAM
– MSP430F248, MSP430F2481
– 48KB+256B Flash Memory
– 4KB RAM
– MSP430F249, MSP430F2491
– 60KB+256B Flash Memory
– 2KB RAM
– MSP430F2410
– 56KB+256B Flash Memory
– 4KB RAM
• Available in 64-Pin QFP and 64-Pin QFN
Packages (See Available Options)
• For Complete Module Descriptions, See
MSP430x2xx Family User's Guide (SLAU144)
(1) The MSP430F24x1 devices are identical to the MSP430F24x
devices, with the exception that the ADC12 module is not
implemented on the MSP430F24x1.
Copyright © 2007–2012, Texas Instruments Incorporated
MSP430F23x
MSP430F24x(1)
MSP430F2410
