Harper DewEze 800 RT Series Operator's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
800/900 RT
Serial Number: 25A01
Manual PN: 201001
3-2025

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DewEze 800 RT Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Harper DewEze 800 RT Series

Summary of Contents for Harper DewEze 800 RT Series

  • Page 1 800/900 RT Serial Number: 25A01 Manual PN: 201001 3-2025...
  • Page 2 800/900...
  • Page 3 Email info@deweze.com Website www.deweze.com © 2025 Harper Industries, Inc. The Harper and DewEze names and the logo are registered trademarks of Harper Industries, Inc. All other brand and product names are trademarks or registered trademarks of their respective companies. 800/900...
  • Page 4 Harper Industries or at the manufacturing plant in Harper, KS. A part will be replaced after inspection discloses it to have been defective. This warranty does not apply to defects caused by damage or unreasonable...
  • Page 5 Table of Contents OPERATOR SECTION PARTS SECTION To the Owner or Operator..........RT Dummy Arms..........Warranty Statement............Crosstubes & Arms Table of Contents............800 or 900 RT Crosstube & Arms....26-27 Specifications Cylinders Bed Model Chart..........RT Squeeze Cylinder........Toolboxes, Skirts..........RT Lift Cylinder &...

  • Page 6: Specifications

    Specifications RT MODEL SPECS BED MODEL REAR WHEELS Single Single Dual Dual Dual DIMENSIONS 7’1” x 8’11” 7’1” x 9’10” 8’ x 8’11” 8’ x 9’10” 8’ x 11’10” CAB-TO-AXLE 56-58” 60” 56-58” 60” 84” TRUCK BRAND Ford/Ram SETUP CODE Box Removal Cab/Chassis Box Removal...
  • Page 7 Hydraulic System Specifications Engine driven pump or self-contained battery powered E/H unit HYDRAULIC 2700 PSI SYSTEM PRESSURE 4.25 Gallons OIL RESERVOIR CAPACITY 2.75 - 3.75 gallons OIL SYSTEM Deweze 222119 IFP/Schroeder Industries 6GZ5 (5 micron) OIL FILTER RT - 3.50" x 16.62" CYLINDER, LIFT XRT - 4.00"...

  • Page 8: Feature Identification

    Feature Identification A. Headache Rack - Protects the rear pickup J. Lights - LED lighting for stop-tail-turn has window. The hydraulic oil tank and valve are long life and low current draw. located in the headache rack. K. Rub Rails - Tie-down locations for straps. B &...
  • Page 9 Front View cautions with all users annually. If you have any questions not answered in this manual or require additional copies, contact your dealer or Harper Industries. Flatbed Operation Safety • Ensure all safety pins are in place and flatbed mounting bolts are secure to the truck frame.

  • Page 10: Initial Startup Procedure

    Hydraulic Safety SAFETY WARNING! • Do not operate the hydraulic system Hydraulic fluid escaping under pressure can with the hood open. penetrate the skin and may cause death if not • Do not activate the electric clutch unless treated immediately. the truck engine is at idle.
  • Page 11 • Wireless transmitter LEDs: Unloading Green = TRANSMIT • To unload, do the reverse of the loading Red = BATTERY/DIAGNOSTICS operation. Pay-out • The green light flashes rapidly when there communication with • Position the truck on as level terrain as receiver.
  • Page 12 RT, Reel/Spool Diameters & Lifting Capacities The diagrams below shows the largest and smallest spools and how each affects relative lifting capacity. (45) in 51 in (45) in 48in. Ø 24 in 102 in Max Ø 2800 lbs. Ground 3100 lbs. Ground *** CAUTION *** Arms on the Deck Place...
  • Page 13 Arbor, Risers & Spinners Alternate spindle mounting gives more clearance Minimum Reel Size Alt mount 57.3 Alt 1 With Winder 25.0 51.6 90.5 Max Reel Size: Normal Configuration Max Reel Size: Alternate Configuration Alt mount Alt mount 62.2 52.4 Alt 2 No Winder 90.5 90.5 Arbor &...
  • Page 14 Note: always start out with the flow control Reel Power Attachment in the lowest setting. • An optional pressure gauge can be In order to use the hydraulic winder attachment, installed to monitor pressure applied to a third bank valve must be installed. the material being pulled.
  • Page 15 Storing the Arms Drive Engagement Pin Storage Location • Close the arms partially and lay them on the flatbed. • Open arms until they are flush with the side of the bed. They now function with the dummy arms as the bed’s side rails. Turn System Off Grease Every Drive Engagement Pin...

  • Page 16: Maintenance

    Maintenance Check Daily or Before Use • Ensure the hydraulic oil level is “Full” via the sight glass. • Check the belt, belt tensioner and idler pulleys on engine clutch pump system. • Examine the hydraulic hoses for leaks with an object such as cardboard. Lubrication Grease the locations indicated in the following illustrations once per week while the unit is...

  • Page 17: Troubleshooting

    TROUBLESHOOTING Problem Symptom Possible Solution Hydraulic No Oil Flow • CHECK OIL LEVEL IN RESERVOIR. If oil level is low, check for leaks in Pump system then re-fill to FULL. • CHECK BELT TENSION. Replace tensioner or tighten idlers if needed. Replace belt if worn.
  • Page 18 GatorHyde Protective Coatings, Inc., 2210 South Highway 69, Wagoner, OK 74467 * (918) 485-2835 * www.gatorhyde.com Harper Industries Operator’s Manual 800/900...

  • Page 19: Remote Control

    TRANSMITTER ERROR CODE CHART Appendix II ERROR PROBABLE CAUSE CODE LOW BATTERY FAULTY CIRCUIT TO OUTPUT A FAULTY CIRCUIT TO OUTPUT B FAULTY CIRCUIT TO OUTPUT C FAULTY CIRCUIT TO OUTPUT D FAULTY CIRCUIT TO OUTPUT E FAULTY CIRCUIT TO OUTPUT F UNUSED UNUSED FAULTY CIRCUIT TO OUTPUT G...

  • Page 20: System Operation

    USB rechargeable internal battery. UNUSED UNUSED AUX ON/OFF SYSTEM OPERATION: Press and hold the power button on the transmitter until both LEDs turn on, then release. The green LED will flash rapidly when communication has been established. When the receiver is off, the red LED will flash slowly indicating this. With the receiver on, press the corresponding buttons on the tranmitter keypad to turn on and off each of the outputs.
  • Page 21 Heavy Duty E/H Power Kit Appendix III See page 46 • Attach adapters to valve and install inside cavity on headache rack. • Attach valve harness per diagram on decal “B” Cartridge • Attach return hose to valve and filter housing. Attach pressure hose from pump.
  • Page 22 • Attach power harness as indicated. • Attach 30-amp fuse holder to positive terminal on battery. Run wire through switch on dash and then to the red wire on the harness. • Attach suction hose and pressure hose to pump with adapters provided. •...
  • Page 23 800/900...
  • Page 24 800/900 RT PARTS 800/900 800/900...
  • Page 25 Table of Contents PARTS SECTION RT Dummy Arms..........Crosstubes & Arms 800 or 900 RT Crosstube & Arms....26-27 Cylinders RT Squeeze Cylinder........RT Lift Cylinder & Linkage........ Hose Routings & Parts RT Lift & Squeeze Routing....... RT 3rd Bank wo/Winder........RT 3rd Bank w/Winder........
  • Page 26 RT DUMMY ARMS NO UPPER TOOLBOX WITH UPPER TOOLBOX W / 24" TBX W / 40" TBX W / 60" TBX W / 40" TBX ITEM PART # DESCRIPTION 110645 Nut, 3/8-16 Wiz Flange 110676 Washer, 3/8" Flat Standard 111268 Bolt, 3/8-16 X 5 Wiz Flange, Gr.
  • Page 27 800/900...
  • Page 28 264136 REV: RT 800 CROSSTUBE & ARMS ITEM QTY PART # DESCRIPTION ITEM QTY PART # DESCRIPTION 110069 Washer, 5/16" Flat Sae 261213 Plate 110426 Bolt, 5/16-18 X 0.5, Wiz Flange 261214 Shield, Crosstube 200190 Decal, Red Reflector, Rectangle 266047 Kit, RT Arm, Left 202117 Decal, Rt (Reel Transport)
  • Page 29 REV: RT 800/900 ARMS & DECALS ITEM QTY PART # DESCRIPTION 202144 Decal, Safe Distance, Horizontal 202145 Decal, Safe Distance, Vertical 202184 Decal, Arm, Left 202185 Decal, Arm, Right 266047 Rt Arm Left 266048 Rt Arm Right 800/900...
  • Page 30 264137 REV: RT 800/900 SQUEEZE CYLINDER SSQ Front of Bed 20.3 20.3 ITEM QTY PART # DESCRIPTION 120319 Adapter, 6mj-6mb 120768 Adapter, 6fj-6mj Live Swivel 223110 Cylinder, Synchronized 2x39.25, Side Port 223123 Hydraulic Hose Kit, RT 20.3 220855 Hose, .375 x 21.5, 6-6fjx/6-8fjx 260111 Mount, Hose Spring 220056...
  • Page 31 264137 REV: RT 800/900 LIFT CYLINDERS & LINKAGE 20.1 NOTES: TORQUE 111216 TO 70 lb-ft ITEM QTY PART # DESCRIPTION 110336 Washer, 1-1/4" Flat Machine 110656 Washer, 3/8" Flat Special 111215 Bolt, 3,8-16 X .50 111216 Bolt, 7/16-14 X 1, Gr8 111217 Washer, 7/16"...
  • Page 32 RT LIFT & SQUEEZE HOSE ROUTING LOAD SQUEEZE & & UNLOAD UNSQUEEZE HOSES: Valve to Cylinder Area ITEM QTY 876, 879, 976, 984 220826 (.375x112,6fjx/6fjx) 220839 (.375x137,6fjx/6fjx) 220825 (.375x138,6-6fjx/6-8mj) 220840 (.375x158,6-6fjx/6-8mj) Common Parts ITEM QTY PART # DESCRIPTION 220824 .375x17, 6fjx/6fjx 120214 Adapter 6mj-6mj-6mj 120319...
  • Page 33 RT 3RD BANK ROUTING RETURN TO TANK 225061 Pg. 36 3rd Bank ASM PRESSURE PARTS LIST ITEM QTY PART # DESCRIPTION 225061 RT 3rd Bank Valve Kit 120288 Adapter, 8mj-8mb90 120581 Coupler, Pioneer Female, Orb 120583 Snap Ring, Orb Pioneer Coupler 132035 Switch Boot 132134...
  • Page 34 RT 3RD BANK ROUTING WITH WINDER 205157 Pg. 61 RETURN TO TANK Winder ASM 225061 214009 Pg. 36 Pg. 64 3rd Bank ASM Valve ASM PRESSURE PARTS LIST PARTS LIST ITEM QTY PART # INCLUDED IN 3RD BANK KIT ITEM QTY PART # ITEMS FROM OTHER ASSEMBLIES 225061 RT 3rd Bank Valve Kit...
  • Page 35 RT Hydraulic Schematic Filter Tank Valve W/ 3rd Bank P/N's 223044 & 223045 Pump Sec. Valve P/N 223072 Winder RT Lift Cylinder RT Lift Cylinder Motor P/N 222129 P/N 222129 P/N 222065 Squeeze Cylinder P/N's 223110 1/29/2025 800/900...
  • Page 36 223044 & 223045 800/900 HYDRAULIC VALVE & 3RD BANK 2 BANK VALVE ADAPTER KIT 225051 2ea. (7)(8), 1ea. (4), 1ea. (3), 1ea. (6), 4ea. (5) 3RD BANK + HOSE KITS Rear: 225061 ITEM QTY PART # DESCRIPTION Valve, Small Monoblock Ver II 223044 223045 Valve, 3rd Bank Add-On...
  • Page 37 REV: 225060 RT VALVE KIT, NON-PROPORTIONAL 2 BANK See Electrical Harness section for details Parts List Kit: 225060 ITEM QTY PART # DESCRIPTION 202189 Decal, Wiring Diagram, RT/XRT Valve 223044 Flatbed Valve, Small, Monoblock Ver II 225051 Adapter Kit, Non-Proportional 2 Bank 232244 Harness, RT/XRT Valve 800/900...
  • Page 38 225061 REV: RT VALVE KIT, 3RD BANK W/REAR COUPLERS Parts List ITEM QTY PART # DESCRIPTION 120288 Adapter, 8mj-8mb90 120581 Coupler, Pioneer Female, Orb 120583 Snap Ring, Orb Pioneer Coupler 132035 Switch Boot 132134 Switch, Toggle, Dpdt, On-Off-On 220697 Hose, .50 X 183.00, 8-8fjx 223045 Valve, 3rd Bank Add On (223044) 420051...
  • Page 39 264032 REV: 800/900 HYDRAULIC RESERVOIR & FILTER 7° 3° 12 ° 3° REF. Reservoir Assembly page for further parts breakdown. 223099_ REF. Filter Assembly page for further parts breakdown. 223105_ TORQUE TO 28 FT-LBS Suction Adapter Kit 225053 7 & 9 GPM TORQUE 120761 20fj 16mj...
  • Page 40 223099 REV: 800/900 RESERVOIR ASSEMBLY ID STICKER (34.985) (21.851) (4.416) PLUG ALL OPEN PORTS Parts List Kit: 223099 ITEM QTY PART # DESCRIPTION 120526 Plug, 8mb, Internal Hex Head 222115 Sight Glass 222116 Cap, Breather 222117 Diffuser 222118 Reservoir, Hydraulic, Service 800/900...
  • Page 41 223105 REV: 800/900 FILTER ASSEMBLY (MEDIUM PRESSURE) NOTES: - PORTS: SAE -12 µ - FILTER RATING: 5 - OPERATING PRESSURE (MAX): 725 PSI - FLOW: 35 GPM - MEDIUM MATERIAL: SYNTHETIC Parts List ITEM QTY PART # DESCRIPTION 222119 Filter Element, Service 222120 Filter Housing, Service 222121...
  • Page 42 235047 REV: 800/900 VALVE SWITCHES KIT Non-Kit Switches Parts List Kit: 235047 ITEM QTY PART # DESCRIPTION 110119 Nut, 10-24 Lock 110264 Bolt, 10-24 X .5 Stainless, Phillips 110753 Plug, 1/2" Button Plastic 132001 Fuse Holder, Atc, 14 Ga., Mini 132002 Fuse, Mini 30 Amp 132035...
  • Page 43 800/900 ELECTRICAL HARNESSES E/H 24V Hybrid E/H 24V HD All Grounds Back to Battery Power to Valve and/or Clutch 230155 Power/Ground for E/H 735022 Hybrid E/H Kit 232236 E/H Adapter 732002 Clutch Control Harness 735001 Clutch Control Assy 232201 232244 870, 871 876,879,976,984 232198 232199...
  • Page 44 Side marker Connect to 232239 blunt cut Ground Work lights Headache Rack Harness Work lights Harness 232201 Side marker 530111 Mini Relay 530111 Mini Relay SPDT 12V SPDT 12V 30/40 amp 30/40 amp To controller plug Blunt cut To lights 20"...
  • Page 45 233012 REV: RT WIRELESS (ENABLE FUNCTION) Parts List ITEM QTY PART # DESCRIPTION 232197 Receiver 233011 Transmitter 233012 Receiver & Transmitter Kit 800/900...
  • Page 46 ITEM DESCRIPTION YEAR Box Delete 232234 Harness Adapter, 2023+ Box Delete 232185 Harness Adapter, 2020-2022 Box Delete 232177 Harness Adapter, 2017-2019 F OR D Box Delete 232160 Harness Adapter, 2011-2016 Box Delete 232176 Harness Adapter, 2008-2010 Cab-chassis 232161 Harness Adapter, 232192 Harness Adapter, Blis 2021+...
  • Page 47 FORD CHEVY OEM to Deweze Adapters OEM to Deweze Adapters Purple wires only for fast flashing issue. See pg. 71 Harness Harness 232234 232238 Harness Harness 232178 232185 232177 232159 232160 232187 Harness Harness 232176 232158 Harness Harness 232161 232174 232163 Harness Harness...
  • Page 48 E/H & E/H HYBRID PARTS: RT VALVE SWITCH KIT VALVE KIT 235047 225060 Pg. 40 Pg. 47 E/H POWER 235052 HARNESS 232244 Pg. 38 See Pg. 43 WIRELESS 233012 HYBRID HYBRID KIT 235053 DECAL MUST BE IN ENCLOSED BATTERY CONTAINER ITEM QTY PART # DESCRIPTION...
  • Page 49 E/H HYBRID INSTRUCTIONS Back of Box 2.75 Top of Box Back of Box .344 3.00 3.625 2.25 Back Wall .391 6.750 3.75 of Box 8.75 Front Front 10.3 .344 Front of Box of Box SWITCH UNIT HOLES Floor of 6.375 Toolbox PUMP MOUNT HOLES BATTERY TRAY...
  • Page 50 264042 REV: 800/900 BED LIGHTS ITEM QTY PART # DESCRIPTION 110069 Washer, 5/16" Flat SAE 110264 Bolt, 10-24 X .5 Stainless, Phillips 110319 Nut, 5/16-18 U-Type .75l 110423 Bolt, 5/16-18 X 1.0 110631 Nut, 10-24 Lock Nylon Insert 110633 Nut, #6/32 Machine Screw 110756 Screw, 6/32 X 1/2 In Pan Head 111261...
  • Page 51 264002 REV: 800/900 HEADACHE RACK LIGHTS Parts List DESCRIPTION ITEM QTY PART # 110069 WASHER, 5/16" FLAT SAE 110319 NUT, 5/16-18 U-TYPE .75L 110423 BOLT, 5/16-18 X 1.0 232209 LIGHT, 6" OVAL STT 232211 GROMMET, 6" OVAL 261156 COVER, LIGHT 264043 REV: 800/900 HEADACHE RACK SWING LIGHT KIT...
  • Page 52 264001 800/900 HEADACHE RACK COVERS (REGULAR) Parts List ITEM PART # DESCRIPTION 110069 Washer, 5/16" Flat Sae 110319 Nut, 5/16-18 U-Type .75l 110422 Bolt, 5/16-18 X .75 110423 Bolt, 5/16-18 X 1.0 110849 Nut, 5/16-18 Rivet Steel 15.8' 200249 Molding, Valve Cover 261104 Cover, Valve 261105...
  • Page 53 264013 REV: 800/900 STANDARD BALL WELL ASSEMBLY TORQUE TO 559 LB-FT Parts List ITEM QTY PART # DESCRIPTION 110244 Bolt, 1/2-1 3 X 1.5 Shcs 110588 Nut, 1/2-1 3 Wiz Flange 110658 Washer, 1/2" Flat Standard 212032 Hitch Ball, 2 5/16 X 1 3/8 X 1 With Hardware 265172 Weldment, Ball Well Door 264068...
  • Page 54 REV: 264006 800/900 REAR PANEL ASSEMBLY Parts List KIT: 264006 ITEM QTY PART # DESCRIPTION 110069 Washer, 5/16" Flat Sae 110319 Nut, 5/16-18 U-Type .75l 110423 Bolt, 5/16-18 X 1.0 264006 Weldment, Rear Panel, No Spike REV: RT ABOVE BED TOOLBOX SELECTION DETAILS BED MODELS 24"...
  • Page 55 RT BELOW BED TOOLBOX SELECTION DETAILS BED MODELS FRONT TOOLBOX REAR TOOLBOX 30” 18” 30” 24” 30” 18” 30” 24” 2 x 30” or 60" 24” 263001 263004 30” 18” 30 x 14 x 13.5” 18 x 14 x 13.5” 263002 24”...
  • Page 56 RT SKIRT SELECTION DETAILS BED MODELS FRONT (1 TBX) FRONT (2 TBX) REAR (w/TBX) REAR (no/TBX) 264062 264062 264053 264062 264062 264054 264062 264062 264053 264062 264062 264054 264088 264049 264062 264054 BRACE KITS have been added to shore up rear skirts. Utilize the hole as shown in the image to the left and drill a hole in the skirt at the appropriate place for your alignment.
  • Page 57 264049 PARTS LIST Rev A Item Part # DESCRIPTION 261115 F DRV or R PSS, 10.3” 261116 R DRV or F PSS, 10.3” 264048 KIT, FILLER SKIRT HARDWARE 24.8” 264047 PARTS LIST Rev B Item Part # DESCRIPTION 261123 R DRV, 24.8” 261124 R PSS, 24.8”...

  • Page 58: Safety Warning

    RT DECALS SAFETY WARNING! It is the owner's responsibility to replace missing or damaged warning decals. Decals are available from your Deweze dealer. MAX TONGUE WEIGHT = 7,500 LBS DO NOT EXCEED VEHICLE GVW AND/OR MAX AXLE WEIGHT PER VEHICLE OWNER’S MANUAL 200472 ITEM QTY...
  • Page 59 205477 205287 275047 REV: REV: REV: RT ARBOR ASSEMBLY 73" & 98" ASSY 205477 ASSY Parts List 205287 ITEM QTY PART # DESCRIPTION 73" 211172 Weldment, Pin, Reel Transport 275034 Weldment, Arbor Retainer 500156 Pin, Hairpin Cotter, 1/8 X 2.375 ASSY 275047 215456...
  • Page 60 205412 REV: RT SPINNER & RISER ASSEMBLY (PAIR) OPTION Parts List ITEM QTY PART # DESCRIPTION 110364 Bolt, 1-8 X 7.0 110601 Nut, 1-8 110649 Washer, 1" Lock 205413 RT Spindle Riser 214004 Spindle & Hub Assembly, RT 214010 Spinner Assembly, RT 202114 Decal, Safe Distance, Horizontal 102124...
  • Page 61 214004 REV: RT SPINDLE & HUB ASSEMBLY 5.75" Wheel Spindle Assy 410512 1ea. (1), 1ea. (2), 1ea. (5), 1ea. (11) Parts List Wheel Spindle Assy ITEM QTY PART # DESCRIPTION 6ea. (3), 6ea. (4), 1ea. (6), 1ea. (7) 413001 110613 Nut, Castle 3/4 - 16 1ea.
  • Page 62 205298 205156 REV: REV: RT BRAKE NOTE: The only difference between "with" winder and "without " winder is the shield (3). 7/8-14 threads Parts List Parts List ITEM QTY PART # DESCRIPTION ITEM QTY PART # DESCRIPTION 110606 Nut, 5/16-18 Wiz Flange 110937 Washer, M14 Lock 202146...
  • Page 63 205157 REV: RT WINDER Parts List Kit: 205157 ITEM QTY PART # DESCRIPTION 102128 Ring, 2"Id X .312, Zinc, Not For Lifting 110442 Bolt, 1/2-13 X 1.25 110606 Nut, 5/16-18 Wiz Flange 110615 Nut, 1/2-13, Unitorque Lock 120288 Adapter, 8mj-8mb90 120581 Coupler, Pioneer Female, Orb 120582...
  • Page 64 214008 REV: RT WINDER: DRIVE SPROCKET ASSEMBLY Parts List ITEM QTY PART # DESCRIPTION 102125 Pin, Lock, .375 X 2.5, Grade 8, Single Wire 110630 Nut, 1/4-20 Lock (Nylon Insert) 110844 Bolt, 1/4-20 X 3 270036 Stop Collar Outer, Drive Bushing, Rt 275022 Weldment, Rt Drive Bushing 275023...
  • Page 65 214011 REV: RT WINDER: DRIVE MOTOR ASSEMBLY Parts List ITEM QTY PART # DESCRIPTION 110535 Bolt, 7/16-14 X 1.5 110610 Nut, 1/2-13 110641 Nut, 7/16-14 110666 Washer, 1/2" Lock 110670 Washer, 7/16" Flat Standard 110671 Washer, 7/16" Lock 111045 Bolt, 1/2-13 X 1.75 Fhcs 112127 Dust Cap, Male Pioneer 120581...
  • Page 66 214009 REV: RT WINDER: VALVE ASSEMBLY Parts List ITEM QTY PART # DESCRIPTION 110400 Bolt, 3/8-16 X 2.0 110618 Nut, 3/8-16 Lock Nylon Insert 120246 Adapter, 8mj-12mb90 120252 Adapter, 8mj-12mb 120270 Adapter, 8mj-8mj-8fjx 120277 Adapter, 8mj-8mb 120288 Adapter, 8mj-8mb90 120535 Valve, Check, 8fj-8mj 220746 Hose, .50 X 10.0 8fjx90/8fjx90...
  • Page 67 205285 REV: RT PRESSURE GUAGE OPTION Parts List ITEM QTY PART # DESCRIPTION 120233 ADAPTER, 4MJ-4MB 120679 Adapter, 8FJX-8MJ-4FB 120736 Adapter, 4mj-4fp, Bulkhead, w/LN 120737 Pressure Gauge, 2.5in, 3000 psi 220750 Hose, .24 x 14.0 4fjx/4fjx90m 800/900...
  • Page 68 205378 REV: RT DUMP BOX Kit: 205378 Parts List ITEM QTY PART # DESCRIPTION 270076 Chain, 3/8 Coil, 15 Links 902208 Carabiner, 3/8", Zinc 205378 RT Dump Box Assy 205383 REV: RT DUMP BOX SPINNER Parts List ITEM QTY PART # DESCRIPTION 102124 Pin, Lock, .50 x 3, Grade 8, Single Wire...
  • Page 69 264044 REV: FRONT TOOLBOX INSTALL KIT Parts List Kit: 264044 ITEM QTY PART # DESCRIPTION 100449 Traction Pad, Flex-Tread 2.75" X 0.75' 202169 Decal, Chip Guard 211109 Step, Toolbox 211119 Tool Box Mat 212003 Gasket, Toolbox Mount 261014 Plate, Chip Guard 264045 Kit, Toolbox Hardware, Front 264050...
  • Page 70 REAR VIEW CAMERA MOUNTING KITS * Chevy 2024(+) CC Chevy 2023(-) CC 205480 Chevy 2020 box Ford box 205143 Ford CC & 2020 Newer Dodge Ram CC 205304 205159 205145 205144 261343 Item Qty Part # DESCRIPTION 205144 DODGE/RAM camera mount kit *Installer note: DewEze does not engineer 205145 FORD camera mount kit...
  • Page 71 BED MOUNTING KITS MAKE PART # YEAR DESCRIPTION 205435 2017+ Ford BTO 871, 876, 976 205441 1996-2016 Ford BTO 871 205432 1999-2016 Ford BTO 876, 976 FORD 205459 2017+ Ford Cab-Chassis 879, 984 205460 1999-2016 Ford Cab-Chassis 879, 984 205461 2017+ Ford Cab-Chassis 988 205462...
  • Page 72 BED STRINGER MEASUREMENTS 25.5 1.875 1.875 25.5 19.5 29.7 STRINGERS FOR: _79, _84, _88 48.0 25.4 1.875 1.875 25.4 19.5 32.7 STRINGERS FOR: _76 48.0 800/900...

  • Page 73: Service Troubleshooting

    SERVICE TROUBLESHOOTING REV: 232238 CHEVY/GMC BD 2024+ Same as Butler GM BD 2024+ MOLEX MOLEX 19164-0013 PURPLE 33472-1306 Leave outside of loom Right 5" Butt Right Connector Molex FORD CONNECTOR: F4UB-14A464-AFA BROWN Connector 4" BLU YEL GREEN Butt Ford Connector Connector 10"...
  • Page 74 NOTES Harper Industries, Inc. Telephone: 620-896-7381 151 E. Highway 160 Toll-Free: 800-835-1042 Harper, KS 67058 Fax: 620-896-7129 Website: www.harperindustries.com E-mail: info@harperindustries.com 800/900...
