Harper DewEze 600 Series Manual

Hide thumbs Also See for DewEze 600 Series:

Advertisement

Table of Contents

600/700 SERIES
PARALLEL SQUEEZE
600/700
1
3-2025

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DewEze 600 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Harper DewEze 600 Series

Summary of Contents for Harper DewEze 600 Series

  • Page 1 600/700 SERIES PARALLEL SQUEEZE 600/700 3-2025...
  • Page 2 600/700...
  • Page 3 Email info@deweze.com Website www.deweze.com © 2025 Harper Industries, Inc. The Harper and DewEze names and the ATM logo are registered trademarks of Harper Industries, Inc. All other brand and product names are trademarks or registered trademarks of their respective companies. 600/700...
  • Page 4 Harper Industries or at the manufacturing plant in Harper, KS. A part will be replaced after inspection discloses it to have been defective. This warranty does not apply to defects caused by damage or unreasonable use (includ- ing failure to provide reasonable and necessary maintenance, or by performing functions without genuine DewEze Flatbed accessories) while in the possession of the consumer.
  • Page 5 Table of Contents Decals OPERATOR SECTION Decals-Safety/Operation........ To the Owner or Operator..........600/700 Series Decals........Warranty Statement............Table of Contents............Accessories Specifications..............Swingout Lights..........Feature Identification............Cargo Lights........... Safety Guidelines LED Swingout Lights........General Equipment Safety....... LED Cargo Lights.......... Flatbed Operation Safety......... Harness Adapters..........

  • Page 6: Specifications

    DewEze flatbeds are specifically designed Specifications to transport and feed round hay bales. Model Specifications MODEL WIDTH 7’ 1” 7’ 1” 7’ 1” 7’ 1” 7’ 1” 7’ 1” 7’ 9” 7’ 9” LENGTH 7’ 2” 7’ 7” 8’ 6” 8’...

  • Page 7: Feature Identification

    Feature Identification A. Headache Rack – protects the rear H. Safety Chain Loops – always use pickup window. The hydraulic oil tank and safety chains when towing. valve are located in the headache rack. I. Gooseneck Hitch – located under a B.
  • Page 8 If you have any questions not answered in contact your dealer or Harper Industries. this manual or require additional copies, contact your dealer or Harper Industries. Flatbed Operation Safety •...
  • Page 9 • Check with truck dealer for any load • Lift the bale onto the truck. limits, additional suspension or tire • Release the bale and repeat the requirements. The flatbed’s lifting operation for the second bale. capability may exceed the truck’s load capacity in some instances.

  • Page 10: Maintenance

    Unrolling (option) SAFETY WARNING! • Use risers and spinners to unroll a bale. Hydraulic fluid escaping under pressure • Position the arms over the bale so the can penetrate the skin and may cause spinners are at the center of the bale. •...
  • Page 11 Hydraulic Oil • For easy hookup of the couplers, turn • Hydraulic fluid selection will affect the the pump switch off and activate the performance of the hydraulic system. control valve switches with the ignition on. This will release pressure in the lines.

  • Page 12: Troubleshooting

    Troubleshooting Problem Symptom Possible Solutions Hydraulic No Oil Flow CHECK OIL LEVEL IN RESERVOIR. If oil level is low, check for Pump leaks in system then re-fill to FULL. CHECK BELT TENSION. Replace tensioner or tighten idlers if needed. Replace belt if worn. CHECK FOR SHEARED KEY ON PUMP SHAFT.
  • Page 13 600/700 SERIES PARTS 600/700...
  • Page 14 Table of Contents Appendices PARTS SECTION Standard Parts GatorHyde Repair......Dual Lift Standard Parts........14-17 600/700 Common Parts........18-19 Remote Control....... 63-64 Parallel Squeeze Crosstube/Arms....2-Bank Wiring - Kar-Tech Remote... 65-68 Squeeze Cylinder Chart........3rd Bank Wiring - Kar-Tech Remote 69-70 2-Bank - Gen 2 w/ Remote....
  • Page 15 DUMMY ARMS & CROSSTUBE CROSSTUBES BED WIDTH BED #’s PART # 85.375 670, 675, 677, & 679 215149 93.0 682, 684, 687 & 688 215162 770, 778, 782, 784, 787, & 788 215138 96.5 STANDARD BEEFCAKE 1000 BEEFCAKE 1500 BEEFCAKE 2000 BED MODELS Drv &...
  • Page 16 600/700...
  • Page 17 600/700...
  • Page 18 600/700...
  • Page 19 600/700...
  • Page 20 600/700...
  • Page 21 600/700...
  • Page 22 600/700...
  • Page 23 Flatbed Squeeze Cylinders Bed Width Model # Squeeze Cylinder Model # 220002 85.375" 220002 91.375" 223032 93.0" 223001 96.5" 223001 85.375 Synchronized Squeeze Cylinder 223026 Part # is available as an option for all beds. 223001. This cylinder is the same length as # Squeeze Cylinder Seal Kit Part # 220056 10/28/2016 600/700...
  • Page 24 600/700...
  • Page 25 600/700...
  • Page 26 600/700...
  • Page 27 600/700...
  • Page 28 600/700...
  • Page 29 600/700...
  • Page 30 600/700...
  • Page 31 600/700...
  • Page 32 600/700...
  • Page 33 600/700...
  • Page 34 600/700...
  • Page 35 Flatbed Non-Proportional Hydraulic Schematic Filter Tank Valve W/ 3rd Bank P/N's 223044 & 223045 Pump Lift Cylinder Lift Cylinder LEFT SMALL RIGHT BIG LEFT BIG RIGHT SMALL Pivot Squeeze Parallel Squeeze Cylinder AUXILIARY Ref. Squeeze Cylinders: Pg. 20 OUTLETS SSQ Squeeze Cylinder 7/31/2024 600/700...
  • Page 36 600/700...
  • Page 37 600/700...
  • Page 38 600/700...
  • Page 39 600/700...
  • Page 40 XRM HYDRAULICS ARM HOSES EXTENSION HOSES CROSSOVER HOSE HYDRAULIC XRM SERIES 6M3K - 6FJX90M / 6FJX 6M3K - 6-4MP / 6MPX 6M3K - 6FJX90M HOSE KIT # 470, 670 2ea 220625 (148in) 4ea 220605 (54.3in) 220601 (79.6in) 223011 2ea 220626 (164in) 4ea 220605 (54.3in) 220601 (79.6in) 475, 675, 676...
  • Page 41 600/700...
  • Page 42 600/700...
  • Page 43 600/700...
  • Page 44 600/700...
  • Page 45 150044 REV: HAND CONTROL & CABLE: 2 BANK Wiring Diagram Switches Shown From Back Side UNLOAD LOAD Parts List Kit: 150044 ITEM QTY PART # DESCRIPTION 130029 Switch, Rocker, DPDT 130065 Switch, Rocker, On-Off-(On) 150001 Top Housing, Hand Control 150002 Switch Plate, Hand Control 150003 Bottom Housing, Hand Control...
  • Page 46 600/700...
  • Page 47 600/700...
  • Page 48 600/700...
  • Page 49 600/700...
  • Page 50 600/700...
  • Page 51 600/700...
  • Page 52 600/700...
  • Page 53 600/700...
  • Page 54 HARNESS ADAPTERS: OEM TO DEWEZE ITEM DESCRIPTION YEAR 232235 Harness Adapter Ford BTO 2023 - 2024 232235 Harness Adapter Ford BTO 2020 - 2022 232119 Harness Adapter Ford BTO 2017 - 2019 FORD 232118 Harness Adapter Ford BTO 2011 - 2016 232046 Harness Adapter Ford BTO 2000 - 2010...
  • Page 55 REAR VIEW CAMERA MOUNTING KITS * Chevy 2024(+) CC Chevy 2023(-) CC 205480 Chevy 2020 box Ford box 205143 Ford CC & 2020 Newer Dodge Ram CC 205304 205159 205145 205144 215400 Item Qty Part # DESCRIPTION 205144 DODGE/RAM camera mount kit *Installer note: DewEze does not engineer 205145 FORD camera mount kit...
  • Page 56 BED MOUNTING KITS * *Installer note: KIts were designed to match specific bed styles to a model of OEM truck. Use best practices & measurements for fitment, or choose the Yellow Bag generic kit. MAKE PART # YEAR DESCRIPTION 205112 2017+ Ford Box Delete 671, 676, 776 205084...
  • Page 57 600/700...
  • Page 58 600/700...
  • Page 59 600/700...
  • Page 60 600/700...
  • Page 61 600/700...
  • Page 62 600/700...
  • Page 63 Flatbed Accessories Spinners & Risers Spinner Assy 16" Pair, XRM, Part #215007 Spinner Assy 16" Pair, Part# 210008 ITEM PART # DESCRIPTION ITEM PART # DESCRIPTION 210006 Pin, Lynch 1/4 x 1 1/2 210006 Pin, Lynch 1/4 x 1 1/2 211509 WELDMENT, SPINNER 16"...
  • Page 64 600/700...
  • Page 65 600/700...
  • Page 66 GatorHyde Protective Coatings, Inc., 2210 South Highway 69, Wagoner, OK 74467 * (918) 485-2835 * www.gatorhyde.com Harper Industries Operator’s Manual 600/700...

  • Page 67: Remote Control

    Appendix II – Remote Control Remote Control TRANSMITTER ERROR CODE CHART SYNCHRONIZING TRANSMITTER AND RECEIVER ERROR PROBABLE CAUSE CODE POWER LOW BATTERY To teach the transmitter ID code to the receiver, use the following procedure: FAULTY CIRCUIT TO OUTPUT A BUTTON 1 1.
  • Page 68 Uses 2 AA Alkaline batteries SYSTEM OPERATION: Press and hold the power button on the transmitter until both LEDs turn on, then release. The green LED will flash rapidly when communication has been established. When the receiver is off, the red LED will flash slowly indicating this. With the receiver on, press the corresponding buttons on the tranmitter keypad to turn on and off each of the outputs.
  • Page 69 2 Bank Wiring, Kar-Tech Remote Decal Part# 202045 Harness Part# 232087 Mini Relay SPDT 12V 530111 BATTERY/ DIAGNOSTIC POWER GREEN TRANSMIT UNLOAD LOAD SQUEEZE UNSQUEEZE 3rd BANK 3rd BANK RETRACT EXTEND FLOAT WORK COILS "C" & "D" LIGHTS 3/11/2011 600/700...
  • Page 70 SOLENOID FIRES UNLOAD LOAD SQUEEZE UNSQUEEZE 3/11/2011 600/700...
  • Page 71 600/700...
  • Page 72 600/700...
  • Page 73 3rd Bank Wiring, Kar-Tech Remote Decal Part# 202046 Harness Part# 232088 BATTERY/ DIAGNOSTIC POWER GREEN TRANSMIT UNLOAD LOAD SQUEEZE UNSQUEEZE 3rd BANK 3rd BANK RETRACT EXTEND FLOAT WORK COILS "C" & "D" LIGHTS 3/11/2011 600/700...
  • Page 74 SOLENOID FIRES FLOAT RETRACT EXTEND 3/11/2011 600/700...
  • Page 75 2 Bank Wiring, Kar-Tech Remote Gen 3 Double Poppet, Deutsch Decal Part# 202053 Harness Part# 232098 Mini Relay SPDT 12V 530111 BATTERY DIAGNOSTIC POWER GREEN TRANSMIT UNLOAD LOAD SQUEEZE UNSQUEEZE 3rd BANK 3rd BANK RETRACT EXTEND FLOAT WORK LIGHTS COILS "C"...
  • Page 76 SOLENOID FIRES UNLOAD LOAD SQUEEZE UNSQUEEZE PAGE 2 9/19/2014 600/700...
  • Page 77 3rd Bank Wiring, Kar-Tech Remote Gen 3 Double Poppet, Deutsch Decal Part# 202054 Harness Part# 232099 BATTERY/DIAGNOSTIC GREEN POWER TRANSMIT UNLOAD LOAD SQUEEZE UNSQUEEZE 3rd BANK 3rd BANK RETRACT EXTEND FLOAT WORK LIGHTS COILS "C" & "D" 9/19/2014 600/700...
  • Page 78 SOLENOID FIRES FLOAT RETRACT EXTEND 9/19/2014 600/700...

  • Page 79: Hydraulic Unit

    Appendix III /Hydraulic Unit Standard E/H Power Kit Electric/Hydraulic Power Unit Harper Industries Operator’s Manual 600/700...
  • Page 80 19)Attach red cable from E/H ontop of “ice cube” fuse. Install rubber cap. 17)Attach 200-amp fuse holder to positive battery terminal. 18)Insert 200-amp fuse. Harper Industries 600 & 700 Series 19)Attach red cable from E/H ontop of “ice cube” fuse. Install rubber cap.
  • Page 81 600/700...
  • Page 82 E/H Wiring, Kar-Tech Remote Decal Part# 202047 Harness Part# 232090 Mini Relay SPDT 12V 530111 BATTERY/DIAGNOSTIC GREEN POWER TRANSMIT Purple switch wire from valve harness UNLOAD LOAD Ground Cable UNSQUEEZE SQUEEZE FLOAT WORK LIGHTS DOWN ONLY Positive Cable -6 Pressure Port -8 Suction Port 4/22/2020 600/700...
  • Page 83 SOLENOID UNLOAD FIRES LOAD SQUEEZE UNSQUEEZE 4/22/2020 600/700...
  • Page 84 600/700...
  • Page 85 E/H Power Kit Black switch wire from hand control harness Ground Cable Positive Cable -6 Pressure Port Red wire fused from hand control harness -8 Suction Port 4/22/2020 600/700...
  • Page 86 Harper Industries 600/700...
  • Page 87 Heavy Duty E/H Power Kit Appendix IV 1. Attach adapters to valve and install inside cavity on headache rack. 2. Attach valve harness per diagram on decal. 3. Attach return hose to valve and filter housing. Attach pressure hose from pump.
  • Page 88 9. Attach power harness as indicated. 10. Attach 30-amp fuse holder to positive terminal on battery, run wire through switch on dash and then to the red wire on the harness. 11. Attach suction hose and pressure hose to pump with adapters provided. 12.
  • Page 89 600/700...
  • Page 90 600/700...
  • Page 91 600/700...
  • Page 92 600/700...
  • Page 93 Mini Relay SPDT 12V 530111 Controlling E/H Solenoid Harness From Flatbed Harness # 232115 To the Switch Post on the E/H Solenoid This Plug to B Coil on Valve Fused and Switched Power Supply Here Plug With Purple Wire From Valve Harness Here Red Wire from Make Sure the Valve Harness Here...
  • Page 94 2 Bank Wiring, Kar-Tech Remote Gen 3 Double Poppet, Deutsch Mini Relay SPDT 12V Decal Part# 202053 Harness Part# 232098 530111 BATTERY DIAGNOSTIC POWER GREEN TRANSMIT UNLOAD LOAD SQUEEZE UNSQUEEZE 3rd BANK 3rd BANK RETRACT EXTEND FLOAT WORK LIGHTS COILS "C"...
  • Page 95 SOLENOID FIRES UNLOAD LOAD SQUEEZE UNSQUEEZE PAGE 2 9/19/2014 600/700...
  • Page 96 3rd Bank Wiring, Kar-Tech Remote Gen 3 Double Poppet, Deutsch Decal Part# 202054 Harness Part# 232099 BATTERY/DIAGNOSTIC GREEN POWER TRANSMIT UNLOAD LOAD SQUEEZE UNSQUEEZE 3rd BANK 3rd BANK RETRACT EXTEND FLOAT WORK LIGHTS COILS "C" & "D" 9/19/2014 600/700...
  • Page 97 SOLENOID FIRES FLOAT RETRACT EXTEND 9/19/2014 600/700...
  • Page 98 Appendix V XRM Adapter Update Kit # 205068 Parts List ITEM PART # DESCRIPTION 100578 Cable Tie 14" Black 50 Lb Tens 120123 ADAPTER, 6FP-6FJX 120271 ADAPTER, 6MP-6FPX 120596 ADAPTER, 6MJ-6MP LONG 90 120597 ADAPTER, 6MJ-6MP XX-LONG 90 5/11/2012 600/700...
  • Page 99 NOTES Harper Industries, Inc. Telephone: 620-896-7381 151 E. Highway 160 Toll-Free: 800-835-1042 Harper, KS 67058 Fax: 620-896-7129 Website: www.harperindustries.com E-mail: info@harperindustries.com 600/700...
